Electronic devices have significantly influenced the development of many aspects of modern society, such as telecommunications, entertainment, education, health care, industry, and security. The main driving force behind the advancement of electronics is the semiconductor industry, which continually produces ever-more sophisticated electronic devices and circuits in response to global demand. The semiconductor industry is one of the global economy's largest and most profitable industries, with annual revenues exceeding $481 billion in 2018. The electronics industry also encompasses other branches that rely on electronic devices and systems, such as e-commerce, which generated over $29 trillion in online sales in 2017. (Full article...)
Good articles -
These are Good articles, which meet a core set of high editorial standards.
Image 1
m-derived filters or m-type filters are a type of electronic filter designed using the image method. They were invented by Otto Zobel in the early 1920s. This filter type was originally intended for use with telephone multiplexing and was an improvement on the existing constant k type filter. The main problem being addressed was the need to achieve a better match of the filter into the terminating impedances. In general, all filters designed by the image method fail to give an exact match, but the m-type filter is a big improvement with suitable choice of the parameter m. The m-type filter section has a further advantage in that there is a rapid transition from the cut-off frequency of the passband to a pole of attenuation just inside the stopband. Despite these advantages, there is a drawback with m-type filters; at frequencies past the pole of attenuation, the response starts to rise again, and m-types have poor stopband rejection. For this reason, filters designed using m-type sections are often designed as composite filters with a mixture of k-type and m-type sections and different values of m at different points to get the optimum performance from both types. (Full article...)
Image 2
First-generation "chrome bumper" Naim NAITThe Naim NAIT (acronym for "Naim Audio Integrated amplifier") is an integrated amplifier from the British hi-fi manufacturer, Naim Audio. The original NAIT is one of the most recognisable pieces of hi-fi equipment ever made. Hi-fi critic Lucio Cadeddu recognised its legendary status, referring to it as "one of the most controversial and famous integrated amps in the history of HiFi".
Having already made their name producing solid-state pre-amplifier and power-amplifier separates, Naim launched a low-powered integrated amplifier that embodies the qualities of its amplifiers, aimed at cost-conscious audiophiles. (Full article...)
Image 3
The Nakamichi Dragon is an audio cassette deck that was introduced by Nakamichi in 1982 and marketed until 1994. The Dragon was the first Nakamichi model with bidirectional replay capability and the world's first production tape recorder with an automatic azimuth correction system; this feature, which was invented by Philips engineers and improved by Niro Nakamichi, continuously adjusts the azimuth of the replay head to minimize apparent head skew and correctly reproduce the treble signal present on the tape. The system allows the correct reproduction of mechanically skewed cassettes and recordings made on misaligned decks. Apart from the Dragon, similar systems have only been used in the Nakamichi TD-1200 car cassette player and the Marantz SD-930 cassette deck.
At the time of its introduction, the Dragon had the lowest-ever wow and flutter and the highest-ever dynamic range, losing marginally to the former Nakamichi flagship the 1000ZXL in frequency response. Competing models by Sony, Studer, Tandberg and TEAC that were introduced later in the 1980s sometimes surpassed the Dragon in mechanical quality and feature set but none could deliver the same mix of sound quality, flexibility and technological advancement. The Dragon, despite inherent issues with long-term reliability, remained the highest point of compact cassette technology. (Full article...)
Image 4
The Electro-Dynamic Light Company of New York was a lighting and electrical distribution company organized in 1878. The company held the patents for the first practical incandescent electric lamp and electrical distribution system of incandescent electric lighting. They also held a patent for an electric meter to measure the amount of electricity used. The inventions were those of Albon Man and William E. Sawyer. They gave the patent rights to the company, which they had formed with a group of businessmen. It was the first company in the world formally established to provided electric lighting and was the first company organized specifically to manufacture and sell incandescent electric light bulbs.
Man, an attorney from New York City, supplied money for experimentation to Sawyer, an electrical engineer. This partnership developed into the Electro-Dynamic Light Company that brought in other investors that became partners. Sawyer devised a unique electrical distribution system where electrical power could be obtained anywhere in the city from an electrical generator with the turn of a switch to light up electric lamps to produce glowing light like a gas lamp. It was unique in that it produced this power without consumers having to maintain local galvanic batteries and at a fraction of the cost of producing the same lighting as from gas lamps. Other features of the system were that safety devices were built in to prevent the early destroying of the other electric lamps in the circuit should there be a power surge due to a lamp burning up early and leaving the distribution circuit. The patents for the Man and Sawyer system were in place before any other electrical companies had similar systems. (Full article...)
Image 5
Telephone cable containing multiple twisted-pair lines The primary line constants are parameters that describe the characteristics of conductive transmission lines, such as pairs of copper wires, in terms of the physical electrical properties of the line. The primary line constants are only relevant to transmission lines and are to be contrasted with the secondary line constants, which can be derived from them, and are more generally applicable. The secondary line constants can be used, for instance, to compare the characteristics of a waveguide to a copper line, whereas the primary constants have no meaning for a waveguide.
The constants are conductor resistance and inductance, and insulator capacitance and conductance, which are by convention given the symbols R, L, C, and G respectively. The constants are enumerated in terms of per unit length. The circuit representation of these elements requires a distributed-element model and consequently calculus must be used to analyse the circuit. The analysis yields a system of two first order, simultaneous linear partial differential equations which may be combined to derive the secondary constants of characteristic impedance and propagation constant. (Full article...)
Image 6
Figure 1. Waveguide slotted line Slotted lines are used for microwave measurements and consist of a movable probe inserted into a slot in a transmission line. They are used in conjunction with a microwave power source and usually, in keeping with their low-cost application, a low cost Schottky diode detector and VSWR meter rather than an expensive microwave power meter.
Slotted lines can measure standing waves, wavelength, and, with some calculation or plotting on Smith charts, a number of other parameters including reflection coefficient and electrical impedance. A precision variable attenuator is often incorporated in the test setup to improve accuracy. This is used to make level measurements, while the detector and VSWR meter are retained only to mark a reference point for the attenuator to be set to, thus eliminating entirely the detector and meter measurement errors. The parameter most commonly measured by a slotted line is SWR. This serves as a measure of the accuracy of the impedance match to the item under test. This is especially important for transmitting antennas and their feed lines; high standing wave ratio on a radio or TV antenna can distort the signal, increase transmission line loss and potentially damage components in the transmission path, possibly even the transmitter. (Full article...)
Image 7
The Linn Isobarik DMS (with in-built crossover) in a domestic setting The Linn Isobarik, nicknamed "Bariks" or "Briks", is a loudspeaker designed and manufactured by Linn Products. The Isobarik is known for both its reproduction of low bass frequencies and being very demanding on amplifiers.
Launched in 1973, the Isobarik DMS, Linn's maiden and flagship loudspeaker was based on and named for the isobaric loading principle invented in the 1950s. The speaker exists also as the Isobarik PMS – destined for the professional market. Although discontinued in 1992, it remains popular among audiophiles. (Full article...)
Image 8
The iPhone 6 and iPhone 6 Plus are smartphones that were developed and marketed by Apple Inc. They are the eighth generation of the iPhone, succeeding the iPhone 5, iPhone 5c and iPhone 5s, and were announced on September 9, 2014, and released on September 19, 2014. The iPhone 6 and iPhone 6 Plus jointly were themselves replaced as the flagship devices of the iPhone series by the iPhone 6s and iPhone 6s Plus on September 9, 2015. The iPhone 6 and 6 Plus respectively include larger 4.7-inch and 5.5-inch displays, a faster processor, upgraded cameras, improved LTE and Wi-Fi connectivity and support for a near-field communications-based mobile payments offering.
The iPhone 6 and 6 Plus received positive reviews, with critics regarding their redesign, specifications, camera, price point, and battery life as being improvements over previous iPhone models. However, aspects of the design of iPhone 6 were also criticized, including plastic strips on the rear of the device for its antenna that disrupted the otherwise metal exterior, and the screen resolution of the standard-sized iPhone 6 being lower than other devices in its class. The iPhone 6 sold extremely well, making it the best-selling iPhone model and the most successful smartphone to date. (Full article...)
Image 9
Constant k filters, also k-type filters, are a type of electronic filter designed using the image method. They are the original and simplest filters produced by this methodology and consist of a ladder network of identical sections of passive components. Historically, they are the first filters that could approach the ideal filter frequency response to within any prescribed limit with the addition of a sufficient number of sections. However, they are rarely considered for a modern design, the principles behind them having been superseded by other methodologies which are more accurate in their prediction of filter response. (Full article...)
The iPhone 5s has almost the same external design as well as the same 4-inch screen as its predecessor, the iPhone 5. The 5s received a new white/gold color scheme in addition to white/silver and space gray/black. The 5s features upgrades mostly in the form of internal hardware; it introduced the Apple A764-bit dual-core system-on-chip, the first 64-bit processor to be used on a smartphone, accompanied by the M7 "motion co-processor". A redesigned home button with Touch ID – a fingerprint recognition system which can be used to unlock the phone and authenticate App Store and iTunes Store purchases – was also introduced. The camera was updated with a larger aperture and a dual-LED flash optimized for different color temperatures. EarPods, which were introduced the year prior and had been shipping with the iPhone 5, were included in the box. (Full article...)
Image 11
Sinclair Executive Type 1
The Sinclair Executive was the world's first "slimline" pocket calculator, and the first to be produced by Clive Sinclair's company Sinclair Radionics. Introduced in 1972, the calculator was produced in at least two versions with different keyboard markings; a variant called the Sinclair Executive Memory was introduced in 1973.
Its small size was made possible by pulsing current to the Texas Instruments TMS1802 "calculator on a chip" integrated circuit, reducing the power consumption more than tenfold. The Executive was highly successful, making £1.8 million of profit for Sinclair and winning a Design Council Award for Electronics. (Full article...)
Image 12
The ZenFone 6 is a 2019 Android-based smartphone that was manufactured, released, and marketed by Asus. It is the only release in Asus' sixth-generation ZenFone lineup and directly succeeds the ZenFone 5Z. Asus chairman Jonney Shih unveiled the ZenFone 6 on 16 May 2019 in Valencia, Spain, and it was released in Spain the following day.
The ZenFone 6 has a larger 6.4-inch (160 mm) display, a faster processor, and upgraded cameras than the ZenFone 5Z. The ZenFone 6's flip-up camera module doubles as a front-facing camera. It is the first mobile device Asus released after restructuring its smartphone division in late 2018. The ZenFone 6 was released in the Indian market as the "Asus 6Z". (Full article...)
Image 13
NAD 3020 integrated amplifier
The NAD 3020 is a stereo integrated amplifier by NAD Electronics, considered to be one of the most important components in the history of high fidelity audio. Launched in 1978, this highly affordable product delivered a good quality sound, which acquired a reputation as an audiophile amplifier of exceptional value. By 1998, the NAD 3020 had become the most well known and best-selling audio amplifier in history. (Full article...)
Image 14
Staggered tuning is a technique used in the design of multi-stage tuned amplifiers whereby each stage is tuned to a slightly different frequency. In comparison to synchronous tuning (where each stage is tuned identically) it produces a wider bandwidth at the expense of reduced gain. It also produces a sharper transition from the passband to the stopband. Both staggered tuning and synchronous tuning circuits are easier to tune and manufacture than many other filter types.
The function of stagger-tuned circuits can be expressed as a rational function and hence they can be designed to any of the major filter responses such as Butterworth and Chebyshev. The poles of the circuit are easy to manipulate to achieve the desired response because of the amplifier buffering between stages. (Full article...)
Image 15
The Revox B215 is a cassette deck manufactured by Studer from 1985 until around 1990. A professional version with different control layout and audio path electronics was manufactured concurrently as the Studer A721. A later improved version was marketed as the Revox B215S. Because it was expensive compared to other consumer models and had exceptionally good mechanical performance and durability, the B215 was used primarily by professional customers—radio stations, recording studios and real-time cassette duplicators.
The B215 used a proven, reliable four-motor tape transport derived from the earlier B710 model. The B215 differed from the B710 and competing decks of the period in having an unusual, computer-like control panel and elaborate automation performed by three Philipsmicrocontrollers. The deck was equipped with automatic tape calibration, microcontroller-assisted setting of recording levels, and non-volatile memory. (Full article...)
Selected image
Credit: User:Fastfission MRI sections through the Z-axis in a normal human adult.
Although much of Zobel's work has been superseded by more modern filter designs, it remains the basis of filter theory and his papers are still referenced today. Zobel invented the m-derived filter
and the constant-resistance filter, which remain in use. (Full article...)
Related portals
Selected article
Ohm's law states that, in an electrical circuit, the current passing through a conductor, from one terminal point to another, is directly proportional to the potential difference (i.e. voltage drop or voltage) across the two terminal points and inversely proportional to the resistance of the conductor between the two terminal points. The SI unit of current is the ampere; that of potential difference is the volt; and that of resistance is the ohm, equal to one volt per ampere.
In mathematical terms, this is written as:
,
where I is the current, V is the potential difference, and R is a constant called the resistance.
Did you know (auto-generated) -
... that in 2019, Chinese electronics company Xiaomi posted a video of their third-quarterly financial report featuring a parody of the anime song "Renai Circulation"?
... that in Yugoslavia, Rudi Čajavec, the electronics company that produced various components of the M-84 tank, also made guitar amplifiers?
ASIMO is a humanoid robot created by Honda Motor Company. The robot resembles a small astronaut wearing a backpack and can walk on two feet in a manner resembling human locomotion. ASIMO was created at Honda's Research & Development Wako Fundamental Technical Research Center in Japan. It is the current model in a line of eleven that began in 1986 with E0. As of 2002, there were 20 ASIMO units in existence. Each one costs less than $1 million to manufacture, and some units are available to be hired out for $150,000 per month.
