Battery
Tools
These are some common tools used to work on this device. You might not need every tool for every procedure.
Background
The ASUS ROG Raikiri Pro is a controller for Xbox One and X|S made by the Taiwanese company ASUS. ASUS is a company that sells electronics products. The company has a US store but can also ship internationally. Users should double-check the ASUS website if the company can ship to their country.
ASUS ROG Raikiri Pro is designed to be innovative and customizable than your average Xbox controller including the ROG Raikiri. Currently, the device is still in stock and being released. Although the controller is for Xbox it is compatible with Windows 10 and 11. The difference between the ROG Raikiri and Raikiri Pro is that the regular Raikiri requires a USB Type-C cable and the Raikiri Pro has a tri-mode connectivity. This tri-mode connectivity allows the user to connect either using Bluetooth, wireless connection, or a wired connection.
Identification
The ASUS ROG Raikiri Pro can be distinguished from other game controllers by the four rear buttons, OLED Display, the circular D-pad, as well as the options of full and short trigger modes. You can find the model number (GD300X) and serial number printed on the back of the controller.
Technical Specifications
Built-in OLED display: Create a unique look with customizable animations, view status indicators, and 1.3” with 128 x 40 resolution, 2 grey level
Versatile tri-mode connectivity: Use low-latency 2.4 GHz RF, Bluetooth®, or wired USB-C® to play on PC; plus certified for Xbox via USB-C connection
Intuitive rear controls: Four left and right buttons can be programmed for in-game commands or for on-the-fly joystick sensitivity shifts
Selectable step triggers: Left and right triggers can be set to short- or full-range modes, with dead zones customizable in Armoury Crate
Premium sound: Built-in ESS DAC for immersive audio; plus 3.5 mm earphone jack, and a mute button
Extensive customization: Remap buttons, change joystick sensitivity, or make other adjustments via Armoury Crate
Extensive battery life: Up to 48-hour battery life enables nonstop gaming
Compatibility: Windows 10, Windows 11, Xbox Series X|S, Xbox One
Connectivity: Wired RF2.4Ghz, Bluetooth (Download driver required)
Weight: 330g (include cable)
Dimensions: 103(W) x 64(H) x 155(L) mm
I/O Port: USB-C, 3.5 mm jack
Microphone & Audio Input: 3.5 mm analog audio port compatible for Xbox and PC
Cable: 3m USB-C to A detachable cable
