strange issue when opening jquery dialog for first time (within asp.net gridview)

Question

I have a gridview inside an updatepanel. One of the fields in the gridview is an ASP.net linkbutton like so:

 <ItemTemplate>
       <asp:LinkButton ID="hlSortOrder" runat="server" CssClass="hlDialog" OnClick="LoadLog"
        Text='<%# DataBinder.Eval(Container, "DataItem.SortOrder") %>'></asp:LinkButton>
  </ItemTemplate>

When someone clicks the linkbutton I call the OnClick method that I created called LoadLog. LoadLog looks like this:

protected void LoadLog(object sender, EventArgs e)
        {
            GridViewRow gr = (GridViewRow)((DataControlFieldCell)((LinkButton)sender).Parent).Parent;
            Label l = (Label)gr.FindControl("lblID");
            DataSet ds;

            ds = BL.GetRunoffAnswerLog(Convert.ToInt64(l.Text));

            if (ds != null)
            {
                if (ds.Tables[0].Rows.Count == 0)
                {
                    gvLog.Visible = false;
                    gvLog.DataSource = null;
                    lblRowsCount.Text = "No log for this record!";
                }
                else
                {
                    lblRowsCount.Text = ds.Tables[0].Rows.Count.ToString() + " row(s) found for this record.";
                    gvLog.DataSource = ds.Tables[0];
                    gvLog.DataBind();
                    gvLog.Visible = true;
                }
            }
            ScriptManager.RegisterClientScriptBlock(this, this.GetType(), "openDialog", "$('#dialog').dialog({draggable: true, modal: true, height: 500, width: 750, title: 'Log', open: function (type, data) {$(this).parent().appendTo('form');}});", true);
        }

Basically it gets a handle of the grid view row, pulls some data back from the database and assigns it to the gvLog source. After that notice the line at the end:

ScriptManager.RegisterClientScriptBlock(this, this.GetType(), "openDialog", "$('#dialog').dialog({draggable: true, modal: true, height: 500, width: 750, title: 'Log', open: function (type, data) {$(this).parent().appendTo('form');}});", true);

I have to do this so that I can open up my dialog box. When I click a row in my gridview ONLY the first time I get this:

Notice it only really shows the title...weird. But once I click that same row again it shows the entire dialog:

It only happens on the first click, if I keep clicking different rows it works fine. I should add that I had to add the following jquery code:

 <script type="text/javascript">
        $(document).ready(function () {
            var prm = Sys.WebForms.PageRequestManager.getInstance();

            prm.add_endRequest(function () {
                $("#dialog").hide();
                // re-bind your jQuery events here
           });
        ....more code...

Based on this discussion: jQuery $(document).ready and UpdatePanels?

If I do not have that code the minute a post back happens the entire div that this dialog is inside always gets shown on my page and I dont want that...

As one of the members below has mentioned. I believe what is happening is the first time you click the linkbutton the client side event is happening first which is opening the actual open dialog, even though I raise this event in server side code...as you see above only when you click the "LoadLog" event click do I register this jquery opendialog. But it appears that this still opens the dialog the first time and once you click it the second time only then is the data shown.

Answer 1

I have had a lot of issues with jQuery awesomeness and UpdatePanels. Try this approach:

1. Place the div that you are using for your dialog outside of your update panel. Don't create your dialog in code behind. Instead create your dialog on page load. Since your dialog is outside the updatepanel it won't get clobbered. Make sure to not auto-open it.
2. Add an additional div to your dialog div to hold your content.
3. Create a javascript function that
   • clears the contents of the content div in your dialog of any previous content
   • appends the gvLog control to the dialog content div, something like $('#dialogContent').append($('#<%= gvLog.ClientID %>'));
   • shows the dialog
4. Now in your code behind tweak the RegisterClientScriptBlock to call this new javascript function.

Example Code
Code Behind:

public partial class _Default : System.Web.UI.Page
{
    protected void Page_Load(object sender, EventArgs e)
    {
        if (!Page.IsPostBack)
        {
            //load in some dummy data
            Dictionary<int, string> vals = new Dictionary<int, string>()
            {
                {1, "ONE"},
                {2, "TWO"},
                {3, "THREE"},
                {4, "FOUR"},
                {5, "FIVE"},
                {6, "SIX"}
            };

            gvData.DataSource = vals;
            gvData.DataBind();
        }
    }

    protected void LoadLog(object sender, EventArgs e)
    {
        LinkButton lb = (LinkButton)sender;
        var key = lb.CommandArgument;

        Random r = new Random();
        Dictionary<int, int> dict = new Dictionary<int, int>();

        for (int i = 0; i <= r.Next(5, 20); i++)
        {
            dict.Add(r.Next(), r.Next());
        }

        gvLog.DataSource = dict;
        gvLog.DataBind();

        //show log in dialog on client
        ScriptManager.RegisterStartupScript(up, up.GetType(), "openDialog", "showLog();", true);
    }
}

Designer Code:

<%@ Page Language="C#" AutoEventWireup="true"  CodeFile="Default.aspx.cs" Inherits="_Default" %>

<!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN" "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">

<html xmlns="http://www.w3.org/1999/xhtml">
<head runat="server">
    <title></title>
    <script src="Scripts/jquery-1.7.2.min.js" type="text/javascript"></script>
    <script src="Scripts/jquery-ui-1.8.21.custom.min.js" type="text/javascript"></script>
    <link href="ui-lightness/jquery-ui-1.8.21.custom.css" rel="stylesheet" type="text/css" />

    <script type="text/javascript">
        $(function () {
            //setup dialog
            $('#dialog').dialog({draggable: true,
                                modal: true,
                                height: 500,
                                width: 750,
                                title: 'Log',
                                autoOpen: false});
        });

        function showLog() {
            //clear any old log data
            $('#dvContent').empty();
            //append current log
            $('#<%= gvLog.ClientID %>').appendTo($('#dvContent'));
            //show dialog
            $('#dialog').dialog('open');
        }
    </script>
</head>

<body>
    <form id="form1" runat="server">
    <asp:ScriptManager ID="sp" runat="server" />
    <div>
        <asp:UpdatePanel ID="up" runat="server">
            <ContentTemplate>
                <asp:GridView ID="gvData" runat="server">
                    <Columns>
                        <asp:TemplateField>
                            <ItemTemplate>
                                <asp:LinkButton ID="lbShowLog" runat="server" Text="Show Log"
                                    OnClick="LoadLog" CommandArgument='<%# Eval("Key") %>' />
                            </ItemTemplate>
                        </asp:TemplateField>
                    </Columns>
                </asp:GridView>

                <div style="display:none;">
                    <asp:GridView ID="gvLog" runat="server">
                    </asp:GridView>
                </div>
            </ContentTemplate>
        </asp:UpdatePanel>
    </div>

    <div id="dialog" style="display:none;">
        <div id="dvContent">

        </div>
    </div>
    </form>
</body>
</html>

Answer 2

See this

Try adding a call to $('#dialog').dialog('open')

your first call to $('#dialog').dialog([Parmas]) may be creating it but not opening it.

Something like this:

 ScriptManager.RegisterClientScriptBlock(this, this.GetType(), "openDialog", "$('#dialog').dialog({draggable: true, modal: true, height: 500, width: 750, title: 'Log', open: function (type, data) {$(this).parent().appendTo('form');}});$('#dialog').dialog('open');", true);

HTH

Answer 3

Try modifying your DOM before opening the dialog

In code :

ScriptManager.RegisterClientScriptBlock(this, this.GetType(), "openDialog", "$(this).parent().appendTo('form');

In JS :

$('#dialog').dialog({draggable: true, modal: true, height: 500, width: 750, title: 'Log', true);

Answer 4

There is a very tricky solution for your problem that will save you from all the hassle of the update panel and the jquery.

First, we will not depend on the RegisterClientScriptBlock function and instead everything will be done through hidden fields.

1. Create a hidden field that will flag if the show dialog to be show or not.
2. Create a javascript function that check if hidden field has value or not. If the hidden field had value, display the show dialog and depend on hidden fields to get the data else don't show the dialog, this will fix the problem of the post back show dialog issue.
3. add an animation extender to the update panel

<cc1:UpdatePanelAnimationExtender ID="UpdatePanelAnimationExtender1" TargetControlID="UpdatePanel1" runat="server"> <Animations> <OnUpdated> <Parallel duration="0">
<ScriptAction Script="YouFunctionCall();" /> </Parallel> </OnUpdated> </Animations> </cc1:UpdatePanelAnimationExtender>

and at the end of this javascript function clear the hidden field.

So what will happen, at post back the javascript will run to check if the flag is set or not and it will find that the flag is empty and when you click inside the update panel, your server side code will run and set the hidden field flag and any other information needed then the update panel animation extender will run the javascript function after the update panel have been updated and will check the hidden field and find it filled with data and will trigger the show dialog and then reset the flag so any other post back will not show the dialog.
