to show mean value in ggplot box plot

Question

I need to be able to show the mean value in ggplot box plot. Below works for a point but I need the white dashed lines? Any body help?

x

Team     Value
A        10
B        5
C        29
D        35
ggplot(aes(x = Team , y = Value), data = x)
+ geom_boxplot (aes(fill=Team), alpha=.25, width=0.5, position = position_dodge(width = .9))
+ stat_summary(fun.y=mean, colour="red", geom="point")

If you made a [reproducible example](http://stackoverflow.com/questions/5963269/how-to-make-a-great-r-reproducible-example) that demonstrates your question / problem, we would find it easier to answer. — Andrie, Sep 06 '12 at 21:04

score 12 · Answer 1 · edited May 31 '17 at 12:59

Here's my way of adding mean to boxplots:

ggplot(RQA, aes(x = Type, y = engagementPercent)) +
geom_boxplot(aes(fill = Type),alpha = .6,size = 1) +
scale_fill_brewer(palette = "Set2") +
stat_summary(fun.y = "mean", geom = "text", label="----", size= 10, color= "white") +
ggtitle("Participation distribution by type") +
theme(axis.title.y=element_blank()) + theme(axis.title.x=element_blank())

enter image description here

ggplot(df, aes(x = Type, y = scorepercent)) +
geom_boxplot(aes(fill = Type),alpha = .6,size = 1) +
scale_fill_brewer(palette = "Set2") +
stat_summary(fun.y = "mean", geom = "point", shape= 23, size= 3, fill= "white") +
ggtitle("score distribution by type") +
theme(axis.title.y=element_blank()) + theme(axis.title.x=element_blank())

enter image description here

I would caution against using text to this and do geom_line instead as text is offset slightly and gives the wrong portrayal of the mean.

Hey user1471980, I think people are more inclined to help if you have a unique user name but then again you have a lot of points :)

How can you label the mean? – Martin Velez Feb 26 '14 at 04:24 — Martin Velez, Feb 26 '14 at 04:24

score 1 · Accepted Answer · answered Sep 06 '12 at 21:24

this is a hack but does this help:

Value<-c(1,2,3,4,5,6)
Team<-c("a","a","a","b","b","b")
x<-data.frame(Team,Value) #note means for a=2, mean for b=5


ggplot(aes(x = Team , y = Value), data = x) + geom_boxplot (aes(fill=Team), alpha=.25, width=0.5, position = position_dodge(width = .9)) +
annotate(geom="text", x=1, y=2, label="----", colour="white", size=7, fontface="bold", angle=0) +
annotate(geom="text", x=2, y=5, label="----", colour="white", size=7, fontface="bold", angle=0)

enter image description here
