Error in Protocol Mapping While hosting a WCF service in IIS

Question

I developed a simple WCF service with VS 2010. And i hosted in the default website in IIS by Adding Application and set the Physical Path

And i tried to browse the .svc file it gives me the following error:

"The configuration section 'protocolMapping' cannot be read because it is missing a section declaration"

Protocol Mapping Error

and I tried many solutions but it doesn't work

I Created WCF Service Library has an App.config with this:

<?xml version="1.0" encoding="utf-8" ?>
<configuration>

  <appSettings>
    <add key="aspnet:UseTaskFriendlySynchronizationContext" value="true" />
  </appSettings>
  <system.web>
    <compilation debug="true" />
  </system.web>
  <!-- When deploying the service library project, the content of the config file must be added to the host's
  app.config file. System.Configuration does not support config files for libraries. -->
  <system.serviceModel>
    <services>
      <service name="EvalServiceLibrary.EvalService">
        <clear />
        <endpoint address="basic" binding="basicHttpBinding" contract="EvalServiceLibrary.IEvalService"
          listenUriMode="Explicit">
          <identity>
            <dns value="localhost" />
            <certificateReference storeName="My" storeLocation="LocalMachine"
              x509FindType="FindBySubjectDistinguishedName" />
          </identity>
        </endpoint>
        <endpoint address="mex" binding="mexHttpBinding" contract="IMetadataExchange"
          listenUriMode="Explicit">
          <identity>
            <dns value="localhost" />
            <certificateReference storeName="My" storeLocation="LocalMachine"
              x509FindType="FindBySubjectDistinguishedName" />
          </identity>
        </endpoint>
        <endpoint address="ws" binding="wsHttpBinding" contract="EvalServiceLibrary.IEvalService"
          listenUriMode="Explicit">
          <identity>
            <dns value="localhost" />
            <certificateReference storeName="My" storeLocation="LocalMachine"
              x509FindType="FindBySubjectDistinguishedName" />
          </identity>
        </endpoint>
        <endpoint address="net.tcp://localhost:8888/evalservice" binding="netTcpBinding"
          contract="EvalServiceLibrary.IEvalService" listenUriMode="Explicit">
          <identity>
            <dns value="localhost" />
            <certificateReference storeName="My" storeLocation="LocalMachine"
              x509FindType="FindBySubjectDistinguishedName" />
          </identity>
        </endpoint>
        <endpoint address="net.pipe://localhost/evalservice" binding="netNamedPipeBinding"
          bindingConfiguration="" contract="EvalServiceLibrary.IEvalService" />
        <host>
          <baseAddresses>
            <add baseAddress="http://localhost:8080/evalservice" />
          </baseAddresses>
        </host>
      </service>
    </services>
    <behaviors>
      <serviceBehaviors>
        <behavior>
          <!-- To avoid disclosing metadata information,
          set the values below to false before deployment -->
          <serviceMetadata httpGetEnabled="True" httpsGetEnabled="True"/>
          <!-- To receive exception details in faults for debugging purposes,
          set the value below to true.  Set to false before deployment
          to avoid disclosing exception information -->
          <serviceDebug includeExceptionDetailInFaults="False" />
        </behavior>
      </serviceBehaviors>
    </behaviors>
  </system.serviceModel>
</configuration>

and i Hosted the WCF Service Library application in WCF website (My Client) has an Web.config with this:

<?xml version="1.0"?>
<configuration>

  <appSettings>
    <add key="aspnet:UseTaskFriendlySynchronizationContext" value="true" />
  </appSettings>
  <system.web>
    <compilation debug="false" targetFramework="4.5" />
    <httpRuntime targetFramework="4.5"/>
  </system.web>
  <system.serviceModel>
    <services>
      <service name="EvalServiceLibrary.EvalService">
        <endpoint address="" binding="wsHttpBinding" bindingConfiguration="" contract="EvalServiceLibrary.IEvalService" />
        <endpoint address="mex" binding="mexHttpBinding" bindingConfiguration="" contract="IMetadataExchange" />
        <endpoint address="basic" binding="basicHttpBinding" bindingConfiguration="" contract="EvalServiceLibrary.IEvalService" />
      </service>
    </services>
    <behaviors>
      <serviceBehaviors>
        <behavior>
          <!-- To avoid disclosing metadata information, set the values below to false before deployment -->
          <serviceMetadata httpGetEnabled="true" httpsGetEnabled="true"/>
          <!-- To receive exception details in faults for debugging purposes, set the value below to true.  Set to false before deployment to avoid disclosing exception information -->
          <serviceDebug includeExceptionDetailInFaults="false"/>
        </behavior>
      </serviceBehaviors>
    </behaviors>
    <protocolMapping>
      <add binding="basicHttpsBinding" scheme="https" />
    </protocolMapping>
    <serviceHostingEnvironment aspNetCompatibilityEnabled="true" multipleSiteBindingsEnabled="true" />
  </system.serviceModel>
  <system.webServer>
    <modules runAllManagedModulesForAllRequests="true"/>
    <!--
        To browse web app root directory during debugging, set the value below to true.
        Set to false before deployment to avoid disclosing web app folder information.
      -->
    <directoryBrowse enabled="true"/>
  </system.webServer>
</configuration>

Iain · Accepted Answer · 2012-10-29T16:44:50.533

64

Amr,

This sounds like you may have permission issues in the folder you .svc is running from, please can you check and see if the following permissions are there:

\IIS_IUSERS
\IIS_IUSR ---If running webservice in Anonymous Mode

For the issue with protocol Mapping, please ensure that the app Pool you are using for the IIS site is setup to use .net 4, as from what I understand protocol mapping is only available in .net 4.

Hope this helps

edited Oct 29 '12 at 16:44

answered Oct 29 '12 at 14:58

Iain

6,392
2
30
50

permission issue solved. but now i'm trying to solve Protocol Mapping error – Amr Ramadan Oct 29 '12 at 15:13
5

For me, adding the extra permissions was not necessary--just fixing the app pool as you directed was enough to fix the problem. Thanks. – David Dec 03 '13 at 20:31
@AmrRamadan any ***final solution*** about `Protocol Mapping error` ? – Kiquenet Apr 27 '16 at 09:57

score 26 · Answer 2 · edited Apr 27 '16 at 09:56

26

I had the same issue, but finally figured out that you have to set the DEFAULT application pool to .Net 4.0, not just the Application Pool for the individual website.

edited Apr 27 '16 at 09:56

Kiquenet

14,494
35
148
243

answered Feb 12 '13 at 13:58

Valerie

659
6
14

score 24 · Answer 3 · answered Sep 04 '15 at 05:47

24

For the issue with protocol Mapping, please ensure that the app Pool you are using for the IIS site is setup to use .net 4.

answered Sep 04 '15 at 05:47

Jaydeep Shil

1,894
22
21

score 6 · Answer 4 · answered Oct 28 '13 at 05:36

6

I have face the same issue. By changing application pool .net framework from 2.0 to 4.o was solved my problem

answered Oct 28 '13 at 05:36

Ravin singh D

61
1
2

score 0 · Answer 5 · answered Mar 28 '20 at 09:43

0

.

I also had the same issue, but finally I could solve it by turning some windows features on.

answered Mar 28 '20 at 09:43

Hamid Noahdi

1,585
2
11
18

score 0 · Answer 6 · answered Jun 30 '20 at 12:11

<configSections>
    <sectionGroup name="system.serviceModel" type="System.ServiceModel.Configuration.ServiceModelSectionGroup, System.ServiceModel, Version=4.0.0.0, Culture=neutral, PublicKeyToken=b77a5c561934e089">
        <section name="protocolMapping" type="System.ServiceModel.Configuration.ProtocolMappingSection, System.ServiceModel, Version=4.0.0.0, Culture=neutral, PublicKeyToken=b77a5c561934e089" />
    </sectionGroup>
</configSections>

Adding to the web.config file solved for me
