Android Text Alignment - Pixel Perfect

Question

In the screenshot below, I am attempting to get the text in the blue box to be aligned in the centre. It is to low down and needs to be lifted a pixel or two. I have been playing with the padding but it does not seem to have any effect.

enter image description here

The layout XML is here :

<RelativeLayout  xmlns:tools="http://schemas.android.com/tools"
android:orientation="horizontal"
android:layout_width="match_parent"
android:layout_height="match_parent"
android:layout_marginRight="5dp"
xmlns:android="http://schemas.android.com/apk/res/android">

        <TextView android:id="@+id/tvName"
        android:layout_width="60dp"
        android:layout_height="20dp"
        android:layout_marginLeft="10dp"
        android:layout_marginRight="10dp"
        android:layout_marginTop="3dp"
        android:background="@drawable/rectanglesegment"
        android:gravity="center"
        android:paddingBottom="2dp"
        android:text="XXX" android:textSize="16sp"
        android:textAppearance="?android:attr/textAppearanceMedium"/>

Any suggestions?

After feedback from @Snicolas I now have the following :

enter image description here

With this layout

<TextView android:id="@+id/tvName"
android:layout_width="60dp"
android:layout_height="fill_parent"
android:layout_marginLeft="10dp"
android:layout_marginRight="10dp"
android:layout_marginTop="2dp"
android:layout_marginBottom="2dp"
android:background="@drawable/rectanglesegment"
android:gravity="center"
android:text="abv" android:textSize="16sp"
android:textAppearance="?android:attr/textAppearanceMedium"/>

This thread is for you : http://stackoverflow.com/questions/432037/how-do-i-center-text-horizontally-and-vertical-in-a-textview-in-android — Snicolas, Dec 30 '12 at 15:52
What did you try in the edit, it's not clear ? And did you see I suggested a negative top padding ? — Snicolas, Dec 30 '12 at 16:07
@Snicola The paddingTop -2 (with the negative) did not seem to have any effect at all. The link to the stackoverflow.com/questions/432037/… pointed me in the right direction by having android:layout_height="fill_parent" and then that seemed to let the existing android:gravity="center" work. — BENBUN Coder, Dec 30 '12 at 16:10
So you can accept your own answer and accept it. That's fine and will be more usefull for other people with same question. — Snicolas, Dec 30 '12 at 16:36

score 2 · Answer 1 · answered Dec 30 '12 at 15:59

2

It looks like the extra room on top is just font padding(for accents, etc). Try this:

<TextView
    ...
    android:includeFontPadding="false"
/>

answered Dec 30 '12 at 15:59

Geobits

22,218
6
59
103

score 0 · Answer 2 · answered Dec 30 '12 at 15:50

How about playing with android:lineSpacingExtra or android:lineSpacingMultiplier? These XML attributes call setLineSpacing().

public void setLineSpacing (float add, float mult)

Sets line spacing for this TextView. Each line will have its height multiplied by mult and have add added to it.

score 0 · Answer 3 · answered Dec 30 '12 at 15:51

0

You should look at the background image - rectanglesegment. It is probably 9 patch image and needs adjustment.

answered Dec 30 '12 at 15:51

Vasudev

1,936
19
17
