In prototype inheritance program when a property not found in a specified object

Question

All, After reading this post, and did some test based on it .

        function Shape() {
            this.x = 0;
            this.y = 0;
        };

        Shape.prototype.move = function(x, y) {
            this.x += x;
            this.y += y;
            console.log("Shape moved.");
        };

        // Rectangle - subclass
        function Rectangle() {
            //Shape.call(this); //call super constructor.
        };

        Rectangle.prototype = Object.create(Shape.prototype);

        var rect = new Rectangle();
                    alert(rect.x);

If I commented the code Shape.call(this); in the Rectangle, I found the rect.x is underfined instead of the value 0.

And What make me confused is that I found in the best answer of the Post said:

"In javascript, every object has a secret link to the object which created it,forming a chain. When an object is asked for a property that it does not have,its parent object is asked... continually up the chain until the property is found or until the root object is reached."

So I can't understand why the rect can't found x in the prototype chain. The rect is already inherited form Shape. If the x doesn't exist in the rect, It supposed be found in his parent. right ? And in my understanding .If using Shape.call(this); , It just add a new x property to the rect, well ,that would not be a code reusing the original x from parents. It just like the override property in the classical inheritance . that is add a new property into the sub class which have the same name and type as the one in the base class..I don't know if my understanding is right , if not . please correct me .Or was I missing something I didn't noticed ? thanks.

Edit

Below is my understanding based on the Thilo and Arun P Johny 's answers. please correct me if it is not right.

Before inheritance happen.

After inheritance executed.

So the x only belong to the instance constructed by Shape. thanks

Answer 1

If you don't call the super constructor, then this.x = 0 is not executed so x remains undefined.

If you wanted it to appear in the prototype, you'd have to say Shape.prototype.x = 0, I think.

So I can't understand why the rect can't find x in the prototype chain.

It's because the prototype does not have x either. It only has move. The x gets assigned to individual instances in the constructor (but only if you call it).

Answer 2

Arun P Johny is right (you should read his comment!)

Try this:

    function Shape() {
        this.x = 0;
        this.y = 0;
    };

    Shape.prototype.move = function(x, y) {
        this.x += x;
        this.y += y;
        console.log("Shape moved.");
    };


    // Rectangle - subclass
    function Rectangle() {
    };

    Rectangle.prototype = new Shape();
    var rect = new Rectangle();
    alert(rect.x);

You can call Shape.call(this); like you did (commented) in your code, but this way it's not a "real" inheritance since you won't be able to use move() in Rectangle.

But the code above is a mishmash of "new" and prototypes and hence very confusing. I guess that what you really want to do is something like this:

   var Shape = {
        x: 0,
        y: 0,
        move: function(x, y) {
            this.x += x;
            this.y += y;
            alert("Shape moved: ["+this.x+","+this.y+"]");
        }
    };

    var rect = Object.create(Shape);
    alert(rect.x);
    rect.move(2,3);
    rect.move(1,1);
