Android how to display 2 listviews in one activity one after the other

Question

I have used this code to display 2 list view one on top of the other.

<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
android:layout_width="fill_parent"
android:layout_height="fill_parent"
android:orientation="vertical" >

<ListView
    android:id="@+id/listView1"
    android:layout_width="match_parent"
    android:layout_height="fill_parent"
    android:layout_weight="1"
    android:background="#f00" >
</ListView>

<ListView
    android:id="@+id/listView2"
    android:layout_width="match_parent"
    android:layout_height="fill_parent"
    android:layout_weight="1"
    android:background="#0f0" >
</ListView>

The problem is that, this causes the 2 listviews to each occupy half of the screen. I am adding a header to both lists like this.

LevelAdapter adapter = new LevelAdapter(getActivity(),
            R.layout.list_item, weather_data);

    View header = inflater.inflate(R.layout.header2, null);
    View header2 = inflater.inflate(R.layout.header, null);
   lv1.addHeaderView(header);
   lv2.addHeaderView(header2);
    lv1.setAdapter(adapter);
    lv2.setAdapter(adapter);

I would like the header of the second list to appear after the first list is over. How do i do this?How do i make the listviews appear such that the second one starts when the first one is over ? Thanks

Answer 1

activity_main.xml

<ScrollView xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="fill_parent"
    android:layout_height="wrap_content"
    android:fillViewport="true" >

    <LinearLayout
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:orientation="vertical"
        android:padding="10dip" >

        <TextView
            android:layout_width="match_parent"
            android:layout_height="wrap_content"
            android:gravity="center_vertical"
            android:text="ANDROID" />

        <ListView
            android:id="@+id/listView1"
            android:layout_width="match_parent"
            android:layout_height="wrap_content"
            android:layout_marginTop="10dip"
            android:background="#B29090" >
        </ListView>

        <TextView
            android:layout_width="match_parent"
            android:layout_height="wrap_content"
            android:layout_marginTop="10dip"
            android:gravity="center_vertical"
            android:text="IOS" />

        <ListView
            android:id="@+id/listView2"
            android:layout_width="match_parent"
            android:layout_height="wrap_content"
            android:layout_marginTop="10dip"
            android:background="#4A9C67" >
        </ListView>
    </LinearLayout>

</ScrollView>

MainActivity.java

package com.example.listviewin1xmldemo;

import android.os.Bundle;
import android.support.v7.app.ActionBarActivity;
import android.view.View;
import android.view.View.MeasureSpec;
import android.view.ViewGroup;
import android.widget.ArrayAdapter;
import android.widget.ListAdapter;
import android.widget.ListView;

public class MainActivity extends ActionBarActivity {

    private ListView mListView1, mListView2;

    private String [] data1 ={"Hiren", "Pratik", "Dhruv", "Narendra", "Piyush", "Priyank"};
    private String [] data2 ={"Kirit", "Miral", "Bhushan", "Jiten", "Ajay", "Kamlesh"};

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        mListView1 = (ListView)findViewById(R.id.listView1);
        mListView2 = (ListView)findViewById(R.id.listView2);

        mListView1.setAdapter(new ArrayAdapter<String>(this, android.R.layout.simple_list_item_1, data1));
        mListView2.setAdapter(new ArrayAdapter<String>(this, android.R.layout.simple_list_item_1, data2));

        ListUtils.setDynamicHeight(mListView1);
        ListUtils.setDynamicHeight(mListView2);
    }


    public static class ListUtils {
        public static void setDynamicHeight(ListView mListView) {
            ListAdapter mListAdapter = mListView.getAdapter();
            if (mListAdapter == null) {
                // when adapter is null
                return;
            }
            int height = 0;
            int desiredWidth = MeasureSpec.makeMeasureSpec(mListView.getWidth(), MeasureSpec.UNSPECIFIED);
            for (int i = 0; i < mListAdapter.getCount(); i++) {
                View listItem = mListAdapter.getView(i, null, mListView);
                listItem.measure(desiredWidth, MeasureSpec.UNSPECIFIED);
                height += listItem.getMeasuredHeight();
            }
            ViewGroup.LayoutParams params = mListView.getLayoutParams();
            params.height = height + (mListView.getDividerHeight() * (mListAdapter.getCount() - 1));
            mListView.setLayoutParams(params);
            mListView.requestLayout();
        }
    }
}

Answer 2

Use Like this:

Remove Linear layout. use relative layout and inside that place your two list view like this.

<ScrollView xmlns:android="http://schemas.android.com/apk/res/android"
android:layout_width="fill_parent"
android:layout_height="fill_parent"
android:id="@+id/scrollojt"
android:fillViewport="true" >

   <RelativeLayout
android:layout_width="match_parent"
android:layout_height="wrap_content" >

<ListView
android:id="@+id/listView1"
android:layout_width="match_parent"
android:layout_height="wrap_content"
android:background="#f00" >
 </ListView>

 <ListView
android:id="@+id/listView2"
android:layout_width="match_parent"
android:layout_height="wrap_content"
android:layout_below="@+id/listView1"
android:background="#0f0" >
</ListView>
    </RelativeLayout>
  </ScrollView>

add Utility.java

public class Utility {

    public static void setListViewHeightBasedOnChildren(ListView listView) {
        ListAdapter listAdapter = listView.getAdapter();
        if (listAdapter == null) {
            // pre-condition
            return;
        }

        int totalHeight = 0;
        int desiredWidth = MeasureSpec.makeMeasureSpec(listView.getWidth(), MeasureSpec.AT_MOST);
        for (int i = 0; i < listAdapter.getCount(); i++) {
            View listItem = listAdapter.getView(i, null, listView);
            listItem.measure(desiredWidth, MeasureSpec.UNSPECIFIED);
            totalHeight += listItem.getMeasuredHeight();
        }

        ViewGroup.LayoutParams params = listView.getLayoutParams();
        params.height = totalHeight + (listView.getDividerHeight() * (listAdapter.getCount() - 1));
        listView.setLayoutParams(params);
        listView.requestLayout();
    }
}

In your Activity:

 lv1.setAdapter(adapter);
 lv2.setAdapter(adapter);

Utility.setListViewHeightBasedOnChildren(lv1);
Utility.setListViewHeightBasedOnChildren(lv2);

Answer 3

You should use ExpandableListView (http://developer.android.com/reference/android/widget/ExpandableListView.html). You would have two sections instead of two listviews but they (including headers) will be aligned as you described.

Answer 4

It is not a good practice to use more than one ListViews' in a single container. It causes measuring and performance problems. Better is to use single ListView with several view types. In your case view types could be: listview1_viewtype, listview2_viewtype, listview2_header_viewtype. For first ListView's header you can use just header.

Answer 5

when weights are provided height should be provided as 0dp or wrap_content. but you are not doing so. change your xml file as below. I hope it works for you.

as per your comment i am editing my post according to requirement Solution

1- : Create a list view with only 2 row

1.1-: Add a list view as a row child in first listview #1

1.2-: Add another list view as second row child in first listview #1

i hope by this way you can achieve success.

Answer 6

I'm new to Android as well and I got something similar (not exactly but kind of workaround) but much EASIER, by making a layout file and putting the required number of list views in it and another XML layout and wrap the previously made layout in ScrollView.

Suppose you have layout named two_listview_layout.xml defined as

<RelativeLayout
..>
    <ListView
        android:id="@+id/listViewOne"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"/>
    <ListView
        android:id="@+id/listViewTwo"
        android:layout_width="match_parent"
        android:layout_width="wrap_content"/>
</RelativeLayout>

RelativeLayout is not mandatory here but you can play around with your requirements and the layouts.

Now make another layout in which this layout is wrapped in ScrollView. As ScrollView can have only 1 direct child, you'll have this complete layout as its child.

Name this (below) layout as final_layout.xml

<FrameLayout
...>
    <ScrollView
        android:layout_width="match_parent"
        android:layout_height="wrap_content">
        <include layout="@layout/two_listview_layout" />
    </ScrollView>
</FrameLayout>

Now inflate this final_layout.xml in your fragment/activity and use the Id's that were named in the two_listview_layout.xml to access any of the listview.

Output is something like this: (apologies for the bad quality of screen recorder :p ) Trailers and Reviews - both are listviews here.

Answer 7

Try with ScrollView and LinearLayout:

activity_main.xml

 <RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
android:layout_width="match_parent"
android:layout_height="wrap_content">
   <ScrollView
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    android:layout_below="@+id/action_bar1"
    android:fillViewport="true">

    <LinearLayout
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:orientation="vertical"
        android:padding="10dip">

        <ListView
            android:id="@+id/listView1"
            android:layout_width="match_parent"
            android:layout_height="200dip"
            android:layout_margin="10dip"
            android:background="#B29090">
        </ListView>



        <ListView
            android:id="@+id/listview2"
            android:layout_width="match_parent"
            android:layout_height="200dip"
            android:layout_margin="10dip"
            android:background="#4A9C67">
        </ListView>
    </LinearLayout>
</ScrollView>
</RelativeLayout>

MainActivity.java

 private ListView list1, list2;
private String [] data1 ={"H", "P", "D", "N", "P", "P"};
private String [] data2 ={"K", "M", "B", "K", "A", "K"};
 @Override
protected void onCreate(Bundle savedInstanceState) {
    super.onCreate(savedInstanceState);
    setContentView(R.layout.activity_sounds);
    list1 = (ListView) findViewById(R.id.listView1);
    list2 = (ListView) findViewById(R.id.listview2);

    list1.setAdapter(new ArrayAdapter<String>(this,android.R.layout.simple_list_item_1,android.R.id.text1,data1));
    list2.setAdapter(new ArrayAdapter<String>(this,android.R.layout.simple_list_item_1,android.R.id.text1,data2));



}

Answer 8

Adding layout_weight worked for me.

<ListView
    android:id="@+id/excerciseListView"
    android:layout_width="match_parent"
    android:layout_height="0px"
    android:divider="#B6B6B6"
    android:dividerHeight="1sp"
    android:layout_weight="3"></ListView>
<ListView
    android:id="@+id/instructionListView"
    android:layout_width="match_parent"
    android:layout_height="0px"
    android:divider="#B6B6B6"
    android:dividerHeight="1sp"
   android:layout_weight="1"></ListView>

Answer 9

Try with relative layout:

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
 android:layout_width="fill_parent"
 android:layout_height="fill_parent" >

<ListView
 android:id="@+id/listView1"
 android:layout_width="match_parent"
 android:layout_height="fill_parent"
 android:layout_weight="1"
 android:layout_below="@+id/listView1"
 android:background="#f00" >
</ListView>
<ListView
 android:id="@+id/listView2"
 android:layout_width="match_parent"
 android:layout_height="fill_parent"
 android:layout_weight="1"
 android:background="#0f0" >
</ListView>
</RelativeLayout>
