Android - Capture ScreenShot Programmatically without title bar

Question

I am developing an app in that I want to take a screen shot of current screen but with out title bar. I know the code to Capture a ScreenShot, but unable to customize it.

Code:

munchscreen.setOnClickListener(new OnClickListener() {

            @Override
            public void onClick(View v) {
                View v1 = L1.getRootView();
                v1.setDrawingCacheEnabled(true);
                Bitmap bm = v1.getDrawingCache();
                BitmapDrawable bitmapDrawable = new BitmapDrawable(bm);
                image = (ImageView) findViewById(R.id.screenshots);
                image.setBackgroundDrawable(bitmapDrawable);
            }
        });

When I click on Clip then it should capture a screen shot of the screen shown below but should not include the part which I have circled..

XML:

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
android:layout_width="match_parent"
android:layout_height="match_parent"
android:background="#D8D5AA"
>


  <LinearLayout
    android:id="@+id/clip_from_web_linearlayout1"
    android:layout_width="match_parent"
    android:layout_height="50dp"
    android:background="@drawable/header"
    android:orientation="horizontal"
    >
         <TextView
        android:id="@+id/clip_from_web_textview_back"
        android:layout_height="wrap_content"
        android:layout_width="wrap_content"
        android:text="Back"
        android:layout_gravity="center"
        android:layout_marginLeft="5dp"
        android:textColor="#FFFFFF"
        android:textSize="18sp"
        />

    <TextView
        android:id="@+id/clip_from_web_textview_header_title"
        android:layout_height="wrap_content"
        android:layout_width="wrap_content"
        android:text="Clip From Web"
        android:layout_gravity="center"
        android:layout_marginLeft="60dp"
        android:textColor="#FFFFFF"
        android:textSize="18sp"
        />

      <TextView
        android:id="@+id/clip_from_web_textview_clip"
        android:layout_height="wrap_content"
        android:layout_width="wrap_content"
        android:text="Clip"
        android:layout_gravity="center"
        android:layout_marginLeft="60dp"
        android:textColor="#FFFFFF"
        android:textSize="18sp"
        />

    </LinearLayout>


          <Button
             android:layout_width="fill_parent"
             android:layout_height="wrap_content"
             android:text="@string/munch"
             android:id="@+id/munchscreen"
             android:layout_below="@+id/clip_from_web_linearlayout1"
           />
           <ImageView
             android:layout_width="200dp"
             android:layout_height="200dp"
             android:id="@+id/screenshots"
             android:layout_below="@+id/munchscreen"
             android:contentDescription="@string/app_name"
             android:layout_centerInParent="true"

             />

<RelativeLayout
    android:id="@+id/clip_from_web_bottom_bar"
    android:layout_width="match_parent"
    android:layout_height="50dp"
    android:layout_alignParentBottom="true"
    android:background="@drawable/header" >

    <Button
        android:id="@+id/clip_from_web_previous"
        android:layout_width="40dp"
        android:layout_height="40dp"
        android:layout_marginLeft="4dp"
        android:background="@android:drawable/ic_media_previous"
        android:layout_marginTop="2dp"
        />

    <Button
        android:id="@+id/clip_from_web_reload"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_centerHorizontal="true"
        android:background="@android:drawable/ic_menu_rotate"
        android:layout_marginTop="5dp"
        />

    <Button
        android:id="@+id/clip_from_web_next"
        android:layout_width="40dp"
        android:layout_height="40dp"
        android:layout_toRightOf="@+id/clip_from_web_reload"
        android:layout_marginLeft="102dp"
        android:background="@android:drawable/ic_media_next"
        android:layout_marginTop="2dp"
        />

</RelativeLayout>

Image before Capturing screen shot..

enter image description here

Image after Capturing screen shot..

enter image description here

follow http://www.truiton.com/2013/03/android-take-screenshot-programmatically-and-send-email/ and http://stackoverflow.com/questions/7514325/how-to-take-screenshot-programmatically — Jitesh Upadhyay, Jan 20 '14 at 07:21
@Piyush Gupta I can't post my xml. But, I am trying it on demo program so I will post the xml of that program.. — Mitesh Shah, Jan 20 '14 at 07:22
@Piyush Gupta: Please check my updated question. I have posted whole XML and proper screen shot — Mitesh Shah, Jan 20 '14 at 07:55
@JiteshUpadhyay:: Not working.. Please check my updated question — Mitesh Shah, Jan 20 '14 at 07:55
Possible duplicate of [How to programmatically take a screenshot in Android?](http://stackoverflow.com/questions/2661536/how-to-programmatically-take-a-screenshot-in-android) — bummi, Jan 17 '16 at 07:57

score 5 · Accepted Answer · answered Jan 20 '14 at 07:59

5

Take this to another Linear Layout

  <LinearLayout
    android:id="@+id/linear"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:orientation="vertical">

       <Button
         android:layout_width="fill_parent"
         android:layout_height="wrap_content"
         android:text="@string/munch"
         android:id="@+id/munchscreen"

       />
       <ImageView
         android:layout_width="200dp"
         android:layout_height="200dp"
         android:id="@+id/screenshots"
         android:contentDescription="@string/app_name"
         />
  </LinearLayout>

Now find Id for this Linear Layout on oncreate() method making it global variable

 LinearLayout ll;

 ll = (LinearLayout)findViewById(R.id.linear);

now capture this screen

 ll.setDrawingCacheEnabled(true);
 ll.buildDrawingCache(true);
 Bitmap cs = Bitmap.createBitmap(ll.getDrawingCache());
 ll.setDrawingCacheEnabled(false);

Now set this bitmap to your ImageView.

answered Jan 20 '14 at 07:59

Piyush

18,895
5
32
63

What is rel? .. Last line – Mitesh Shah Jan 20 '14 at 08:03
Please edit your code as `ll.setDrawingCacheEnabled(true);` .. You have written false. If I do so then it displays black image. When I make it to true then it works perfect.. :) – Mitesh Shah Jan 20 '14 at 08:09
Just see proper at first line i wrote it..Because its trying to prepare for it and after that capture the screen it should be false..So no need to change – Piyush Jan 20 '14 at 08:11
Ok. Fine. But, I told you the things which I encountered. It is working for me when I make it to true. Thank you.. – Mitesh Shah Jan 20 '14 at 08:13

score 2 · Answer 2 · answered Jan 20 '14 at 07:29

try this...

    munchscreen.setOnClickListener(new View.OnClickListener() {

        @Override
        public void onClick(View v) {
            View contentView = getWindow().getDecorView().findViewById(android.R.id.content);
            contentView.setDrawingCacheEnabled(true);
            contentView.buildDrawingCache();
            Bitmap drawingCache = contentView.getDrawingCache();
            BitmapDrawable bitmapDrawable = new BitmapDrawable(getResources(), drawingCache);
            image = (ImageView) findViewById(R.id.screenshots);
            image.setBackgroundDrawable(bitmapDrawable);
        }
    });

score 2 · Answer 3 · answered May 13 '18 at 18:02

Hey friends I got the solution of above problem.

Follow below steps:-

activity_main.xml

<RelativeLayout
    android:id="@+id/toolbar_rl"
    android:layout_width="match_parent"
    android:layout_height="?android:actionBarSize"
    android:background="@color/header_color"
    android:visibility="visible">

    <LinearLayout
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        android:orientation="horizontal"
        android:weightSum="0"
        tools:ignore="UselessParent">

        <ImageView
            android:layout_width="wrap_content"
            android:layout_height="match_parent"
            android:contentDescription="@string/app_name"
            android:padding="@dimen/_8sdp"
            android:src="@drawable/ic_back_24" />

        <TextView
            android:layout_width="0dp"
            android:layout_height="wrap_content"
            android:layout_gravity="center"
            android:layout_marginEnd="@dimen/_10sdp"
            android:layout_marginStart="@dimen/_20sdp"
            android:layout_weight="1"
            android:gravity="center"
            android:text="@string/one_time"
            android:textColor="@color/white"
            android:textSize="@dimen/_13sdp"
            tools:ignore="RtlHardcoded" />


        <ImageView
            android:layout_width="wrap_content"
            android:layout_height="match_parent"
            android:contentDescription="@string/app_name"
            android:padding="@dimen/_8sdp"
            android:src="@drawable/ic_menu_icon" />


    </LinearLayout>

</RelativeLayout>

<ScrollView
    android:id="@+id/tabScroll"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:fillViewport="true">

    <TableLayout
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:stretchColumns="1">

        <ImageView
            android:layout_width="fill_parent"
            android:layout_height="210dp"
            android:adjustViewBounds="true"
            android:background="@drawable/otp_background"
            android:contentDescription="@string/app_name"
            android:scaleType="fitXY">

        </ImageView>

        <TextView
            android:layout_width="match_parent"
            android:layout_height="wrap_content"
            android:layout_marginTop="@dimen/_16sdp"
            android:background="#fff"
            android:gravity="center"
            android:text="Enter Unique Identification Number"
            android:textColor="@color/header_color"
            android:textSize="@dimen/_16sdp" />

        <LinearLayout
            android:id="@+id/layout_otp"
            android:layout_width="match_parent"
            android:layout_height="wrap_content"
            android:layout_gravity="center"
            android:layout_marginTop="@dimen/_26sdp"
            android:gravity="top|center"
            android:orientation="horizontal">

            <EditText
                android:id="@+id/editTextone"
                android:layout_width="@dimen/_40sdp"
                android:layout_height="@dimen/_42sdp"
                android:inputType="number"
                android:maxLength="1"
                android:nextFocusRight="@+id/editText_two"
                tools:ignore="LabelFor">

                <requestFocus />
            </EditText>

            <EditText
                android:id="@+id/editTexttwo"
                android:layout_width="@dimen/_40sdp"
                android:layout_height="@dimen/_42sdp"
                android:inputType="numberDecimal"
                android:maxLength="1"
                tools:ignore="LabelFor" />

            <EditText
                android:id="@+id/editTextthree"
                android:layout_width="@dimen/_40sdp"
                android:layout_height="@dimen/_42sdp"
                android:inputType="numberDecimal"
                android:maxLength="1"
                tools:ignore="LabelFor" />

            <EditText
                android:id="@+id/editTextfour"
                android:layout_width="@dimen/_40sdp"
                android:layout_height="@dimen/_42sdp"
                android:inputType="numberDecimal"
                android:maxLength="1"
                tools:ignore="LabelFor" />

            <EditText
                android:id="@+id/editTextfive"
                android:layout_width="@dimen/_40sdp"
                android:layout_height="@dimen/_42sdp"
                android:inputType="numberDecimal"
                android:maxLength="1"
                tools:ignore="LabelFor" />

        </LinearLayout>


        <Button
            android:id="@+id/btn_submit"
            android:layout_width="@dimen/_220sdp"
            android:layout_height="@dimen/_40sdp"
            android:layout_gravity="center"
            android:layout_marginBottom="@dimen/_46sdp"
            android:layout_marginLeft="@dimen/_16sdp"
            android:layout_marginRight="@dimen/_16sdp"
            android:layout_marginTop="@dimen/_26sdp"
            android:background="@drawable/editbox_one"
            android:text="@string/capture"
            android:textAllCaps="false"
            android:textColor="#fff"
            android:textSize="@dimen/_16sdp"
            android:typeface="serif" />
    </TableLayout>
</ScrollView>

This xml looks like.

in MainActivity Add some code.

3.1 Declare the Button.
```
  Button button_submit;
```
3.2 Initialize the button.
```
 button_submit = (Button) findViewById(R.id.btn_submit);
```
3.3 Set set OnClickListener to this button and Call one method i.e
```
 takeScreenshot();
```
Note:- When you click on this button that time automatically capture the screen without title bar and it will store in file explore with current date, time and.jpg extension(Ex. Fri May 11 151938 GMT+0530 2018.jpg) and this captured image as a bitmap if you want you can set this bitmap to ImageView .

The Code of takeScreenshot().

 private void takeScreenshot() {

 Date now = new Date();
 android.text.format.DateFormat.format("yyyy-MM-dd_hh:mm:ss", now);

try {

String mPath = Environment.getExternalStorageDirectory().toString() + "/" + now + ".jpg";

View u = findViewById(R.id.tabScroll);
u.setDrawingCacheEnabled(true);
ScrollView z = (ScrollView) findViewById(R.id.tabScroll);
z.setBackgroundColor(getResources().getColor(R.color.white));
int totalHeight = z.getChildAt(0).getHeight();
int totalWidth = z.getChildAt(0).getWidth();
u.layout(0, 0, totalWidth, totalHeight);
u.buildDrawingCache(true);
Bitmap bitmap = Bitmap.createBitmap(u.getDrawingCache());
u.setDrawingCacheEnabled(false);

File imageFile = new File(mPath);

FileOutputStream outputStream = new FileOutputStream(imageFile);
int quality = 100;
bitmap.compress(Bitmap.CompressFormat.JPEG, quality, outputStream);
outputStream.flush();
outputStream.close();

 } catch (Throwable e) {

  e.printStackTrace();
}
}

The output be looks like..

I hope it will helpful for you.
