Show up-Button in actionBar in subscreen preferences

Question

I've implemented my preferences like shown in the official guidelines.

I have a PreferenceActivity which creates the PreferenceFragment like this:

 @Override
 protected void onCreate(Bundle savedInstanceState)
 {
      super.onCreate(savedInstanceState);

      Bundle extras = getIntent().getExtras();
      if (extras != null)
      {
          Bundle bundle = new Bundle();
          _widgetID = extras.getInt(GlobalSettings.EXTRA_WIDGET_ID);
          bundle.putInt(GlobalSettings.EXTRA_WIDGET_ID, _widgetID);

          WidgetSettingsFragment fragment = new WidgetSettingsFragment();
          fragment.setArguments(bundle);

          getFragmentManager().beginTransaction().replace(android.R.id.content,
                        fragment).commit();
      }

 }

The PreferenceFragment loads the preferences from the resources and they contain a preference subscreen like this:

<PreferenceScreen  xmlns:android="http://schemas.android.com/apk/res/android">
    <!-- opens a subscreen of settings -->
    <PreferenceScreen
        android:key="button_voicemail_category_key"
        android:title="@string/voicemail"
        android:persistent="false">
        <ListPreference
            android:key="button_voicemail_provider_key"
            android:title="@string/voicemail_provider" ... />
        <!-- opens another nested subscreen -->
        <PreferenceScreen
            android:key="button_voicemail_setting_key"
            android:title="@string/voicemail_settings"
            android:persistent="false">
            ...
        </PreferenceScreen>
        <RingtonePreference
            android:key="button_voicemail_ringtone_key"
            android:title="@string/voicemail_ringtone_title"
            android:ringtoneType="notification" ... />
        ...
    </PreferenceScreen>
    ...
</PreferenceScreen>

This works well so far, but now I'd like to have an up-Button in the actionBar when the preferences subscreen is shown. Any idea how to accomplish that?

I have tried to set setDisplayHomeAsUpEnabled(true) in my activity but then the up-Button is only shown in the main preferences (where it should not) and not in the subscreen.

I'm wondering that even in the official docs the subscreen is shown without an active up-Button: Setting subscreens

Link to the docs: Settings

Any help is really welcome

Afaik, according to Google's design advice, the system Back button is preferable to up-navigation for such situations. Otherwise, if you create your own new Activity, you could very well make do with getActionBar().setDisplayHomeAsUpEnabled(true) for *that* particular subscreen Activity. — webuster, Feb 04 '14 at 13:31
There is this almost exact same question: http://stackoverflow.com/questions/11971800/sethomebuttonenabled-on-preferenceactivity-and-nested-preference — Mdlc, Feb 04 '14 at 13:53
The Problem is that I only have one `PreferenceFragment` which shows the preferences and automatically the subscreen of the preferences. I have no activity or fragment class for the subscreen. I have no clue how to check if the subscreen is shown in order to call `setDisplayHomeAsUpEnabled(true)` as there is no interface or callback for this that I'm aware of. — user1567896, Feb 04 '14 at 14:22

score 13 · Accepted Answer · edited May 23 '17 at 12:09

I finally got it to work :D. It's quite hacky but it works.

The problem is, that using subscreens in xml-layouts results in some 'code magic'. A new activity/dialog is started for the subscreen and you don't have direct access to it.

To get access to the actionbar and the OnClickListener of the home/up-button you need to get a reference to your PreferenceScreen and get its parent Dialog in order to access the actionbar and its home/up button.

This is how it is done inside my PreferenceFragment:

 @Override
 public void onCreate(Bundle savedInstanceState)
 {
...

 final PreferenceScreen preferenceScreen = (PreferenceScreen) findPreference(getString(R.string.keyPrefScreenDynamicWidgetDetails));
  preferenceScreen.setOnPreferenceClickListener(new OnPreferenceClickListener()
  {
       public boolean onPreferenceClick(Preference preference)
       {
           preferenceScreen.getDialog().getActionBar().setDisplayHomeAsUpEnabled(true);
           final Dialog dialog = preferenceScreen.getDialog();

           View homeBtn = dialog.findViewById(android.R.id.home);
           if (homeBtn != null)
           {
               OnClickListener dismissDialogClickListener = new OnClickListener()
               {
                   @Override
                   public void onClick(View v)
                   {
                      dialog.dismiss();
                   }
               };

               // Prepare yourselves for some hacky programming
               ViewParent homeBtnContainer = homeBtn.getParent();

               // The home button is an ImageView inside a FrameLayout
               if (homeBtnContainer instanceof FrameLayout) {
                   ViewGroup containerParent = (ViewGroup) homeBtnContainer.getParent();

                   if (containerParent instanceof LinearLayout) {
                       // This view also contains the title text, set the whole view as clickable
                       ((LinearLayout) containerParent).setOnClickListener(dismissDialogClickListener);
                   } else {
                       // Just set it on the home button
                       ((FrameLayout) homeBtnContainer).setOnClickListener(dismissDialogClickListener);
                   }
               } else {
                   // The 'If all else fails' default case
                   homeBtn.setOnClickListener(dismissDialogClickListener);
               }
           }
           return true;
       }
  });
...

}

Following link gave me the final hints and code to solve my problem:

Action Bar Home Button not functional with nested PreferenceScreen

Clever but hacky and possibly not portable. It relies on implementation details of a dialog you don't control. — Eric Woodruff, Feb 10 '14 at 22:14

score 3 · Answer 2 · edited May 23 '17 at 11:53

I do this per the Android docs in the "Supporting older versions with preference headers" section http://developer.android.com/guide/topics/ui/settings.html#BackCompatHeaders. Using the legacy PreferenceActivity, you specify a Preference in the xml that launches an intent to the same preference activity class. The activity checks the intent action and determines if it is nested or not (to show the up button) and which preference xml to inflate in the screen.

Of course, I intend to support older devices as well. I have found that the PreferenceFragment is only useful for large tablets that use preference headers.

To reuse preferences between phones and tablets I came up with this solution https://stackoverflow.com/a/20806812/1139784

score -5 · Answer 3 · answered Feb 05 '14 at 07:59

To enable the up action do the following:

getSupportActionBar().setDisplayHomeAsUpEnabled(true);
getSupportActionBar().setDisplayUseLogoEnabled(true);

this will give you the icon.

then add

@Override
public boolean onOptionsItemSelected(MenuItem item) {
    switch (item.getItemId()) {
        // Respond to the action bar's Up/Home button
        case android.R.id.home:
            finish();
            return true;
    }
    return super.onOptionsItemSelected(item);
}

you can alter this to go where you need to. As another option you can use the navigateUpTo(Intent intent) and the onSupportNavigateUpTo(Intent intent) methods and specify the intent you want to return to.

Thanks for the answer but this is not an answer to my question — user1567896, Feb 05 '14 at 10:26
