Android Keyboard hides EditText

Question

When I try to write something in an EditText which is at the bottom of the screen, the soft keyboard hides the EditText. How can I resolve this issue? Below is my xml code. I'm using this in a Fragment.

<ScrollView xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:orientation="vertical" >

    <RelativeLayout
        android:layout_width="fill_parent"
        android:layout_height="wrap_content" >


        <LinearLayout
            android:id="@+id/linearLayoutTopDetails"
            android:layout_width="fill_parent"
            android:layout_height="wrap_content"
            android:layout_below="@+id/linearLayoutTop"
            android:layout_marginLeft="6dp"
            android:layout_marginRight="6dp"
            android:layout_marginTop="6dp"
            android:orientation="vertical" >

            <LinearLayout
                android:layout_width="fill_parent"
                android:layout_height="wrap_content"
                android:background="@drawable/list_design1"
                android:orientation="vertical" >

                <LinearLayout
                    android:layout_width="fill_parent"
                    android:layout_height="80dp"
                    android:layout_weight="100"
                    android:orientation="horizontal" >

                    <ImageView
                        android:id="@+id/ImageViewProfImagePostDetail"
                        android:layout_width="0dp"
                        android:layout_height="fill_parent"
                        android:layout_marginTop="2dp"
                        android:layout_weight="24.84"
                        android:paddingLeft="5dp"
                        android:paddingRight="5dp"
                        android:paddingTop="5dp" />

                    <LinearLayout
                        android:layout_width="0dp"
                        android:layout_height="wrap_content"
                        android:layout_weight="60"
                        android:orientation="vertical" >

                        <TextView
                            android:id="@+id/textViewNamePostDetail"
                            android:layout_width="wrap_content"
                            android:layout_height="wrap_content"
                            android:text="Robin"
                            android:textSize="17sp" />

                        <TextView
                            android:id="@+id/textViewLocationPostDetail"
                            android:layout_width="wrap_content"
                            android:layout_height="wrap_content"
                            android:layout_marginTop="1dp"
                            android:drawableLeft="@drawable/location"
                            android:text="beijing, China" />

                        <TextView
                            android:id="@+id/textViewTimeAgoPostDetail"
                            android:layout_width="wrap_content"
                            android:layout_height="wrap_content"
                            android:text=" 18min ago" />
                    </LinearLayout>

                    <LinearLayout
                        android:layout_width="0dp"
                        android:layout_height="fill_parent"
                        android:layout_weight="15"
                        android:orientation="horizontal" >

                        <TextView
                            android:id="@+id/textViewReportAbusePostDetail"
                            android:layout_width="wrap_content"
                            android:layout_height="wrap_content"
                            android:layout_gravity="center"
                            android:background="@drawable/flag"
                            android:paddingLeft="5dp" />

                        <TextView
                            android:id="@+id/textViewDeletePostDetail"
                            android:layout_width="wrap_content"
                            android:layout_height="wrap_content"
                            android:layout_gravity="center"
                            android:layout_marginLeft="15dp"
                            android:background="@drawable/delete"
                            android:visibility="gone" />
                    </LinearLayout>
                </LinearLayout>

                <TextView
                    android:id="@+id/textViewDescriptionPostDetail"
                    android:layout_width="wrap_content"
                    android:layout_height="wrap_content"
                    android:layout_marginLeft="20dp"
                    android:layout_marginTop="2dp"
                    android:singleLine="false"
                    android:text="Description or caption of the post"
                    android:textSize="17sp" />
            </LinearLayout>

            <ImageView
                android:id="@+id/feedPostedImagePostDetail"
                android:layout_width="fill_parent"
                android:layout_height="200dp"
                android:layout_marginTop="5dp"
                android:scaleType="fitCenter"
                android:visibility="gone" />

            <LinearLayout
                android:id="@+id/linearLayoutOptions"
                android:layout_width="fill_parent"
                android:layout_height="33dp"
                android:layout_marginTop="2dp"
                android:layout_weight="100"
                android:background="@drawable/bar"
                android:orientation="horizontal" >

                <TextView
                    android:id="@+id/textViewShakePostDetail"
                    android:layout_width="0dp"
                    android:layout_height="fill_parent"
                    android:layout_marginLeft="15dp"
                    android:layout_weight="25"
                    android:drawableLeft="@drawable/like"
                    android:gravity="center"
                    android:singleLine="true"
                    android:text="Shake"
                    android:textSize="12sp" />

                <TextView
                    android:id="@+id/textViewCommentPostDetail"
                    android:layout_width="0dp"
                    android:layout_height="fill_parent"
                    android:layout_weight="41"
                    android:drawableLeft="@drawable/comment"
                    android:gravity="center"
                    android:paddingLeft="20dp"
                    android:text="Comment" />

                <TextView
                    android:id="@+id/textViewSharePostDetail"
                    android:layout_width="0dp"
                    android:layout_height="fill_parent"
                    android:layout_weight="33"
                    android:drawableLeft="@drawable/share"
                    android:gravity="center"
                    android:paddingLeft="20dp"
                    android:text="Spread" />
            </LinearLayout>
        </LinearLayout>

        <ListView
            android:id="@+id/listViewFeedsDetail1"
            android:layout_width="fill_parent"
            android:layout_height="wrap_content"
            android:layout_below="@+id/linearLayoutTopDetails"
            android:layout_marginBottom="4dp"
            android:layout_marginLeft="6dp"
            android:layout_marginRight="6dp"
            android:layout_marginTop="6dp" >
        </ListView>

        <LinearLayout
            android:id="@+id/linearLayoutPostcomment"
            android:layout_width="fill_parent"
            android:layout_height="wrap_content"
            android:layout_below="@+id/listViewFeedsDetail1"
            android:background="#FFFFFF"
            android:orientation="horizontal"
            android:weightSum="100" >

            <EditText
                android:id="@+id/editTextComment"
                android:layout_width="0dp"
                android:layout_height="wrap_content"
                android:layout_weight="80" />

            <Button
                android:id="@+id/buttonPostComment"
                android:layout_width="0dp"
                android:layout_height="wrap_content"
                android:layout_weight="20"
                android:background="#F0F8FF"
                android:text="Post" >
            </Button>
        </LinearLayout>
    </RelativeLayout>
</ScrollView>

I have tried to resolve this issue by adding changes through code but no success.

Below is the image before and after clicking on the EditText.

screenshot without soft keyboard, EditText visible

screenshot with soft keyboard, EditText hidden

Add this properties : android:windowSoftInputMode="adjustPan|adjustResize" to your Activity tag in AndroidManifest.xml — Haresh Chhelana, Jun 17 '14 at 11:34
possible duplicate of [Android soft keyboard covers edittext field](http://stackoverflow.com/questions/3295672/android-soft-keyboard-covers-edittext-field) — Lamorak, Aug 19 '15 at 17:03
@HareshChhelana I think either of adjustPan or adjustResize should be used, and not both at a time. They are contrary to each other — Shirish Herwade, Nov 27 '15 at 11:46
This seems to be a bug in android when `adjustPan` mode is set Try this Custom `EditText` with workaround for this problem https://gist.github.com/Arjun-sna/768de4ca141798c59a8166a2e5d4a743 — arjun, Feb 21 '17 at 12:01

score 100 · Answer 1 · edited Sep 03 '21 at 12:54

100

In manifest add this line on the particular activity tag:

 android:windowSoftInputMode="adjustPan"

edited Sep 03 '21 at 12:54

Aniruddh Parihar

3,072
3
21
39

answered Jun 17 '14 at 11:22

Kishan Dhamat

3,746
2
26
36

11

I've tried this but no success. android:windowSoftInputMode="adjustPan|adjustResize" This code is still in my manifest.but is still hiding editText. – Robin Royal Jun 17 '14 at 11:23
2

@RobinRoyal JFTR, adjustPan|adjustResize is NOT the same than adjustPan alone. In fact, if what other user has said later is true, you should never ever mix two adjust* states. – Fran Marzoa Nov 13 '19 at 10:59

score 22 · Answer 2 · answered Jun 17 '14 at 11:23

22

For that you have to declared in your activity manifeast

         <activity
            android:name=".activityname"
            android:label="@string/app_name"
            android:windowSoftInputMode="adjustPan|adjustResize" >
            <intent-filter>
                <action android:name="android.intent.action.MAIN" />

                <category android:name="android.intent.category.LAUNCHER" />
            </intent-filter>
        </activity>

answered Jun 17 '14 at 11:23

This is my activity manifest code. This is still hiding editText. – Robin Royal Jun 17 '14 at 11:25
1

It is fragment not an activity.Where should I do that? I've already placed this code in activity in which fragment is placed. – Robin Royal Jun 17 '14 at 11:32
10

@RobinRoyal may be I'm late, but(my be useful for others) use either adjustPan or adjustResize, not both at a time – Shirish Herwade Nov 27 '15 at 11:45
2

Don't set two "adjust..." values together as document says: The setting must be one of the values listed in the following table, or a combination of one "state..." value plus one "adjust..." value. Setting multiple values in either group — multiple "state..." values, for example — has undefined results. – EmJiHash Nov 22 '16 at 08:34
Here's doc for more info : https://developer.android.com/training/keyboard-input/visibility – Hanako Jan 05 '21 at 17:25

score 16 · Answer 3 · answered Apr 26 '17 at 11:48

Here is simple solution for Android EditText issue of hiding behind SoftKeypad. Use the code in AndroidManifest.xml file of the project module.

<activity
        android:name="com.example.MainActivity"
        android:label="@string/activity_main"
        android:windowSoftInputMode="adjustResize|stateHidden" />

This code worked for me.
Inside the manifest file in activity tag add this attribute:

android:windowSoftInputMode="adjustResize|stateHidden"

There are more such values for this attribute (android:windowSoftInputMode) which will come as recommendation list. You can check with them also.

score 10 · Answer 4 · answered Nov 09 '16 at 12:12

Declare windowSoftInputMode="adjustResize" in manifest.xml file

<activity
        android:name=".example"
        android:theme="@style/AppTheme.NoActionBar"
        android:windowSoftInputMode="adjustResize" />

provide scroll view to the xml layout file

<RelativeLayout
         xmlns:android="http://schemas.android.com/apk/res/android"
         xmlns:app="http://schemas.android.com/apk/res-auto"
         xmlns:tools="http://schemas.android.com/tools"
         android:layout_width="match_parent"
         android:layout_height="match_parent"
         android:paddingBottom="16dp"
         android:paddingLeft="16dp"
         android:paddingRight="16dp"
         android:paddingTop="16dp"
         android:fitsSystemWindows="true">

<ScrollView
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:fillViewport="true"
        android:isScrollContainer="false">

   // add edittext here...

 </ScrollView>
 </RelativeLayout>

Ramakishna Balla · Answer 5 · 2014-06-17T12:19:37.533

3

Use the below code where:

InputMethodManager ipmm = (InputMethodManager) getSystemService(Context.INPUT_METHOD_SERVICE);
                ipmm.hideSoftInputFromWindow(url.getWindowToken(), 0);

where url in my code is:

url = (EditText) findViewById(R.id.eT_webbrowser);

or Try this:

InputMethodManager ipmm = (InputMethodManager) getSystemService(Context.INPUT_METHOD_SERVICE);
                    ipmm.hideSoftInputFromWindow(null, 0);

As another option try this: This always hides the soft input mode such that your EditText is visible

this.getWindow().setSoftInputMode(WindowManager.LayoutParams.SOFT_INPUT_STATE_ALWAYS_HIDDEN);

edited Jun 17 '14 at 12:19

answered Jun 17 '14 at 11:41

Ramakishna Balla

1,020
1
8
12

@Robin Royal - If it works for you, please accept it as an answer. – Ramakishna Balla Jun 17 '14 at 12:10
I didn't get you. But, did you also try with 'null' as an option to check ? – Ramakishna Balla Jun 17 '14 at 12:13
Yes I tried it.When I click on the EditText to write something.Soft Keyboard shows but it hides the EditText.Actually EditText is not scrolling up on the Soft Keyboard.EditText stays at the bottom of the screen. – Robin Royal Jun 17 '14 at 12:17
Try this. Also edited in my answer : this.getWindow().setSoftInputMode(WindowManager.LayoutParams.SOFT_INPUT_STATE_AL‌WAYS_HIDDEN); – Ramakishna Balla – Ramakishna Balla Jun 17 '14 at 12:21
Still nothing happend.Thanks anyway – Robin Royal Jun 17 '14 at 12:27
Npbs..strange..why don't your show up your code and the screen shot of what's exactly happening ? That will help SO to guide you better – Ramakishna Balla Jun 17 '14 at 12:28
I have posted my screenshots. Please give a look on it.Thank You – Robin Royal Jun 19 '14 at 05:31
I used getWindow().setSoftInputMode(WindowManager.LayoutParams.SOFT_INPUT_STATE_HIDDEN); and that worked! Thanks Ramakishna Balla! – Amy McBlane Apr 02 '15 at 22:24

score 2 · Answer 6 · answered Nov 25 '19 at 06:36

I handled that by adding ScrollView around View with EditText inside.

<ScrollView
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        >
        // Other views
        <EditText ... />
</ScrollView>

Adding tags to Android Manifest didn't help me.

score 0 · Answer 7 · answered Jul 13 '20 at 13:02

Put this line in your application tag:-

android:windowSoftInputMode="stateHidden|adjustPan"

example:-

<application
    android:name=".application.MyApplication"
    android:allowBackup="false"
    android:icon="@mipmap/ic_launcher"
    android:label="@string/app_name"
    android:largeHeap="true"
    android:networkSecurityConfig="@xml/network_security_config"
    android:roundIcon="@mipmap/ic_launcher_round"
    android:supportsRtl="false"
    android:theme="@style/AppTheme"
    android:windowSoftInputMode="stateHidden|adjustPan"
    tools:ignore="GoogleAppIndexingWarning"
    tools:replace="android:supportsRtl,android:allowBackup"
    tools:targetApi="n">

score 0 · Answer 8 · answered Feb 04 '21 at 07:53

0

Add this line on your manifest file on your activity and see the magic.

android:windowSoftInputMode="stateAlwaysHidden|adjustResize"

answered Feb 04 '21 at 07:53

Vijendra patidar

1,444
1
14
24

score 0 · Answer 9 · answered Nov 07 '21 at 07:20

0

Try this, it might be help you.

Add the following line to your EditText

android:paddingVertical="16dp"

answered Nov 07 '21 at 07:20

Razz

452
6
9

score 0 · Answer 10 · answered Jul 05 '23 at 14:52

For users using adjustPan and Fullscreen below is the answer.

// Set the OnApplyWindowInsetsListener to handle window insets changes

    ViewCompat.setOnApplyWindowInsetsListener(binding.root) { view, insets ->

        // Check if the bottom inset (keyboard) is non-zero and adjust the layout accordingly

        if (insets.isVisible(WindowInsetsCompat.Type.ime())) {
// Keyboard height if you need

    //          val keyboardHeight = insets.getInsets(WindowInsetsCompat.Type.ime()).bottom
                val windowRect = Rect()
                view.getWindowVisibleDisplayFrame(windowRect)

        val editTextRect = Rect()
        mEditText.getGlobalVisibleRect(editTextRect)

        // Calculate the difference between the bottom of the editText and the windowRect
        val diff = editTextRect.bottom - windowRect.bottom

        if (diff > 0) {
            view.scrollBy(0, diff.plus(SET_YOUR_DESIRE_MARGIN_HERE))
        }
    } else {
        view.scrollTo(0, 0)
    }

    // Return the insets to keep the system default behavior
    insets
}

For API level 29 and below you have to set SOFT_INPUT_ADJUST_RESIZE in your Activity or Fragment. You can reset it in lifecycle event call back based on your need. Like below for Fragment, set it in onAttach ->

override fun onAttach(context: Context) {
        super.onAttach(context)
        if(Build.VERSION.SDK_INT<Build.VERSION_CODES.R)
            requireActivity().window.setSoftInputMode(WindowManager.LayoutParams.SOFT_INPUT_ADJUST_RESIZE)
    }

and reset it in onDetach.

override fun onDetach() {
        if(Build.VERSION.SDK_INT<Build.VERSION_CODES.R)
            requireActivity().window.setSoftInputMode(WindowManager.LayoutParams.SOFT_INPUT_ADJUST_PAN)
        super.onDetach()
    }

Hope this will help future users.

score -1 · Answer 11 · answered Apr 25 '18 at 13:43

-1

The solution for me was, simply, adding this to the parent layout : android:fitsSystemWindows="true"

answered Apr 25 '18 at 13:43

Hichem Laroussi

17
3

Android Keyboard hides EditText

11 Answers11

Linked

Related
