subplots with different colormaps matlab

Question

I am trying to make a graph with two different contourf subplots that use completely different colormaps. However with the code I currently have (which creates a custom colormap for one of the subplots), the subplots come out with the same colormap. Any ideas how to fix this?

h = figure;
subplot(2,1,1)
title('GEFS 20 Member Mean Vorticity');
axesm('eqdcylin','maplonlimit',[-180 179],'maplatlimit',[0 90]);
%eqdcylin
contourm(gLat, gLon, squeeze(meanhx(x,:,:))', 16,'Color',[0.05 0.05 0.05],'LineWidth',2);
hold on
contourfm(gLat, gLon, squeeze(vmeanx(x,:,:))', 30, 'LineStyle', 'none');
shading flat;
lm=worldlo('POline');
  for i=1:length(lm);
  lm(i).otherproperty = {'color','m','LineWidth',1.5};
  end
displaym(lm);
gridm on;
tightmap;
set(h, 'Position', [1 1 2200 1100]);
colormap(b2r(-5*10^-5, 5*10^-5));
freezeColors;
cbfreeze(colorbar)




%caxis([-5*10^-5 5*10^-5])

colorbar;


subplot(2,1,2)
title('GEFS 20 Member Vorticity Variance');
axesm('eqdcylin','maplonlimit',[-180 179],'maplatlimit',[0 90]);
%eqdcylin
contourm(gLat, gLon, squeeze(meanhx(x,:,:))', 16,'Color',[0.05 0.05 0.05],'LineWidth',2);
hold on
contourfm(gLat, gLon, squeeze(vvarx(x,:,:))', 30, 'LineStyle', 'none');
shading flat;
lm=worldlo('POline');
  for i=1:length(lm);
  lm(i).otherproperty = {'color','m','LineWidth',1.5};
  end
displaym(lm);
gridm on;
tightmap;
set(h, 'Position', [1 1 2200 1100]);

mycmap = [
0.9961    0.9961    0.9961;
0.6641    0.6641    0.9974;
0.3320    0.3320    0.9987;
     0         0    1.0000;
     0    0.2500    1.0000;
     0    0.5000    1.0000;
     0    0.7500    1.0000;
     0    1.0000    1.0000;
0.2000    1.0000    0.8000;
0.4000    1.0000    0.6000;
0.6000    1.0000    0.4000;
0.8000    1.0000    0.2000;
1.0000    1.0000         0;
1.0000    0.9333         0;
1.0000    0.8667         0;
1.0000    0.8000         0;
1.0000    0.7333         0;
1.0000    0.6667         0;
1.0000    0.6000         0;
1.0000    0.5333         0;
1.0000    0.4667         0;
1.0000    0.4000         0;
1.0000    0.3333         0;
1.0000    0.2667         0;
1.0000    0.2000         0;
1.0000    0.1333         0;
1.0000    0.0667         0;
1.0000         0         0;
0.9854         0         0;
0.9708         0         0;
0.9561         0         0;
0.9415         0         0;
0.9269         0         0;
0.9123         0         0;
0.8977         0         0;
0.8830         0         0;
0.8684         0         0;
0.8538         0         0;
0.8392         0         0;
0.8246         0         0;
0.8099         0         0;
0.7953         0         0;
0.7807         0         0;
0.7661         0         0;
0.7515         0         0;
0.7368         0         0;
0.7222         0         0;
0.7092         0         0;
0.6961         0         0;
0.6830         0         0;
0.6699         0         0;
0.6569         0         0;
0.6438         0         0;
0.6307         0         0;
0.6176         0         0;
0.6046         0         0;
0.5915         0         0;
0.5784         0         0;
0.5654         0         0;
0.5523         0         0;
0.5392         0         0;
0.5261         0         0;
0.5131         0         0;
0.5000         0         0;
];

colormap(mycmap);






freezeColors;
cbfreeze(colorbar);


set(gcf, 'renderer', 'zbuffer');

not minimal nor reproducible; did you go through the examples in freezeColors? — rozsasarpi, Nov 12 '14 at 17:24
[This](http://stackoverflow.com/questions/5963269/how-to-make-a-great-r-reproducible-example) is related to R, but equally valid for Matlab and any programming question. A google search would give you hundreds of hits.. Additionally take a look at SO's [help](http://stackoverflow.com/help/how-to-ask). — rozsasarpi, Nov 12 '14 at 17:31
I have repeatedly searched google, and continue to come back with the same issue as there does not seem to be a solution that directly solves this problem. Otherwise I wouldn't be asking here. Additionally, I'm not sure what exactly it is that makes this not reproducible, there is nothing here that is not reproducible, and the code is simply a cluttered (with mapping lines) contourf plot. — agold2121, Nov 12 '14 at 17:38
It is not so simple to solve, have a look here for a solution: http://stackoverflow.com/a/39741044/2627163 and if you can make a sand-alone code that I can run, I will add 2 colormaps to it. — EBH, Nov 05 '16 at 23:20

Lucius II. · Answer 1 · 2015-08-27T13:37:17.540

3

EDIT: it seems, that the documentation is wrong! See comments!

By using the second argument of the colormap function, one should be able to assign a specific colormap to a specific (sub-)plot or axes, if you want to call it like that:

Referring to TMW: colormap:

Be aware that the first argument is the handle to the axes!

colormap(ax,map)

sets the colormap for the axes specified by ax. Each axes within a figure can have a unique colormap. After you set an axes colormap, changing the figure colormap does not affect the axes.

How to get the handle of the axes?:

when plotting with plot(x,y..) you get it as the return-value. Catch it with:

ax = plot(x,y..)

For other plot-functions, as you seem to use, you should find some info about that within the doku.

edited Aug 27 '15 at 13:37

answered Nov 13 '14 at 10:33

Lucius II.

1,832
12
19

this is wrong. The question is about multiple colormaps in a subplot. The above only works when each plot is in a different figure. Even if you get the axis handle for a single subplot, setting its colormap will change the colormap of all other axis in the figure. – carandraug Aug 26 '15 at 20:15
gosh, it seems that you are right. I just got this form the documentation. Did I got this wrong?-> "Each axes within a figure can have a unique colormap" or is there something wrong with the documentation..? :o – Lucius II. Aug 27 '15 at 09:02
1

apparently yes. It's very easy to test, `data = randi (64, 10); hax1 = subplot (1, 2, 1); image (data); colormap (hax1, jet); hax2 = subplot (1, 2, 2); image (data); colormap (hax2, hot);` Mathwork's solution for this is an [absolute joke](http://www.mathworks.com/matlabcentral/answers/101346-how-do-i-use-multiple-colormaps-in-a-single-figure). You must create a colormap that is the concatenation of each subplot colormap and adjust the values on each accordingly. And if you want colorbars, you need to set their ranges manually too. – carandraug Aug 27 '15 at 11:58

score 2 · Answer 2 · answered Apr 21 '17 at 17:18

2

If you upgrade to MATLAB 2017a, you can assign a colormap to each axes object using the syntax colormap(axesHandle, cMap)

answered Apr 21 '17 at 17:18

user2831602

138
6

score 0 · Answer 3 · edited May 23 '17 at 11:54

0

If you have the Image Processing toolbox, you can use the function subimage to display images with their respective colormaps:

X1=imread('http://upload.wikimedia.org/wikipedia/commons/5/5c/Burosch_Blue-Only_Test_pattern.jpg');
X2=imread('http://upload.wikimedia.org/wikipedia/commons/e/ea/Romsey_River_Test.jpg');
subplot(1,2,1), subimage(X1)
subplot(1,2,2), subimage(X2)

Result:

two images in one figure

Edit there is a more complete answer to this question here.

edited May 23 '17 at 11:54

Community

1
1

answered Nov 12 '14 at 17:50

Cape Code

3,584
3
24
45

I'm not loading in images though, I'm calculating contourf plots. Would this work similarly? – agold2121 Nov 12 '14 at 17:53
@agold2121 I just realized it only works for images (i.e matrices), check the link for ways to do it with plots. – Cape Code Nov 12 '14 at 17:57
@agold2121 `freezeColors` is not solving your issue? – Cape Code Nov 12 '14 at 18:12
No, its actually freezing the same colors to both subplots. – agold2121 Nov 12 '14 at 18:45
