"Density" curve overlay on histogram where vertical axis is frequency (aka count) or relative frequency?

Question

Is there a method to overlay something analogous to a density curve when the vertical axis is frequency or relative frequency? (Not an actual density function, since the area need not integrate to 1.) The following question is similar: ggplot2: histogram with normal curve, and the user self-answers with the idea to scale ..count.. inside of geom_density(). However this seems unusual.

The following code produces an overinflated "density" line.

df1            <- data.frame(v = rnorm(164, mean = 9, sd = 1.5))
b1             <- seq(4.5, 12, by = 0.1)
hist.1a        <- ggplot(df1, aes(v)) +
                    stat_bin(aes(y = ..count..), color = "black", fill = "blue",
                             breaks = b1) +
                    geom_density(aes(y = ..count..))
hist.1a

plot

Pat W. · Accepted Answer · 2014-12-23T15:21:29.283

@joran's response/comment got me thinking about what the appropriate scaling factor would be. For posterity's sake, here's the result.

When Vertical Axis is Frequency (aka Count)

density

Thus, the scaling factor for a vertical axis measured in bin counts is

bincount

In this case, with N = 164 and the bin width as 0.1, the aesthetic for y in the smoothed line should be:

y = ..density..*(164 * 0.1)

Thus the following code produces a "density" line scaled for a histogram measured in frequency (aka count).

df1            <- data.frame(v = rnorm(164, mean = 9, sd = 1.5))
b1             <- seq(4.5, 12, by = 0.1)
hist.1a        <- ggplot(df1, aes(x = v)) +
                    geom_histogram(aes(y = ..count..), breaks = b1,
                                   fill = "blue", color = "black") +
                    geom_density(aes(y = ..density..*(164*0.1)))
hist.1a

plot

When Vertical Axis is Relative Frequency

relfreq

Using the above, we could write

hist.1b        <- ggplot(df1, aes(x = v)) +
                    geom_histogram(aes(y = ..count../164), breaks = b1,
                                   fill = "blue", color = "black") +
                    geom_density(aes(y = ..density..*(0.1)))
hist.1b

relf

When Vertical Axis is Density

hist.1c        <- ggplot(df1, aes(x = v)) +
                    geom_histogram(aes(y = ..density..), breaks = b1,
                                   fill = "blue", color = "black") +
                    geom_density(aes(y = ..density..))
hist.1c

dens

Is it possible to extract the value of this ```..density..```? — amrrs, Oct 16 '17 at 14:15
@amrrs, See here on how to extract the histogram values. Similar hackery will get you the density (but there may be an easier way). https://stackoverflow.com/questions/7740503/getting-frequency-values-from-histogram-in-r/47137411#47137411 — PatrickT, Jan 30 '18 at 17:29
@Pat W. This is a great answer. A very minor comment: to get the density curve without the vertical bits on the edges and the horizontal line contour, here's a way: ``geom_line(aes(y = ..density..), stat = "density", lwd=1)``, where ``lwd`` can be tweaked to thicken the line, if so desired. — PatrickT, Jan 30 '18 at 17:31
You can also use something like `geom_density(aes(y = ..count..*0.1))`, where you only need the bin width, not the number of bins — ColinTea, Aug 10 '22 at 12:55

score 7 · Answer 2 · answered Dec 22 '14 at 22:49

7

Try this instead:

ggplot(df1,aes(x = v)) +
   geom_histogram(aes(y = ..ncount..)) +
   geom_density(aes(y = ..scaled..))

answered Dec 22 '14 at 22:49

joran

169,992
32
429
468

1

Would you know how to do it if we didn't want to scale the count to 1? – Pat W. Dec 22 '14 at 22:56
3

@PatW. A smooth density estimate and binned counts are not on the same scale (as you observed in your first attempt). To align them, you'll have to place them on the same scale. You can adjust that scale to be whatever you like, but some adjustment will be required. – joran Dec 22 '14 at 22:58

score 2 · Answer 3 · answered Jan 28 '19 at 17:44

library(ggplot2)
smoothedHistogram <- function(dat, y, bins=30, xlabel = y, ...){
  gg <- ggplot(dat, aes_string(y)) +
    geom_histogram(bins=bins, center = 0.5, stat="bin",
                   fill = I("midnightblue"), color = "#E07102", alpha=0.8)
  gg_build <- ggplot_build(gg)
  area <- sum(with(gg_build[["data"]][[1]], y*(xmax - xmin)))
  gg <- gg +
    stat_density(aes(y=..density..*area),
                 color="#BCBD22", size=2, geom="line", ...)
  gg$layers <- gg$layers[2:1]
  gg + xlab(xlabel) +
    theme_bw() + theme(axis.title = element_text(size = 16),
                       axis.text = element_text(size = 12))
}

dat <- data.frame(x = rnorm(10000))
smoothedHistogram(dat, "x")
