Scrollview doesn't cover all width

Question

I have a ScrollView combined with a PageControll and it contains 5 images which I want them to scroll. My problem is that the ScrollView width even if it is 320 in simulator it doesn't show covering the all width.

enter image description here

This is my code:

override func viewDidLoad() {
    super.viewDidLoad()

    images.append(UIImage(named: "one.jpg")!)
    images.append(UIImage(named: "two.jpg")!)
    images.append(UIImage(named: "three.jpg")!)
    images.append(UIImage(named: "four.jpg")!)
    images.append(UIImage(named: "five.jpg")!)

    for var i = 0; i < images.count; i++ {
        var frame: CGRect = CGRectMake(0, 0, 0, 0)
        frame.origin.x = self.scrollView.frame.size.width * CGFloat(i)
        frame.origin.y = 0;
        frame.size = self.scrollView.frame.size;

        var imageView: UIImageView = UIImageView(frame: frame)
        imageView.image = images[i]
        self.scrollView.addSubview(imageView)
    }

    self.scrollView.contentSize = CGSizeMake(scrollView.frame.size.width * CGFloat(images.count), scrollView.frame.size.height)
}

That is because iPhone 6 width is 375 and you didn't have any constraints of ScrollView. — gabbler, Jan 03 '15 at 14:37

max_ · Accepted Answer · 2015-01-03T15:14:25.783

1

Most likely, the scroll view's width is the correct size, but the content-mode of the UIImageView is set incorrectly such that as a result of the image being displayed having a smaller size than the scroll view, it will not fill the whole of the image view as you wanted.

imageView.contentMode = UIViewContentModeScaleAspectFill;

// Swift

imageView.contentMode = .ScaleAspectFit

edited Jan 03 '15 at 15:14

answered Jan 03 '15 at 14:48

max_

24,076
39
122
211

score 0 · Answer 2 · answered Jan 03 '15 at 14:39

0

Try adding constraints to your image in your interface builder.

answered Jan 03 '15 at 14:39

Maxime Defauw

190
9

score 0 · Answer 3 · answered Jan 03 '15 at 14:43

0

Put Constraints: Main.storyboard -> UIImageView (for each UIImageView) -> Editor -> Pin -> Select leading,top space, bottom and trailing space to superview.

answered Jan 03 '15 at 14:43

The UIImageView is created programatically. – Adrian Jan 03 '15 at 14:44
http://stackoverflow.com/questions/26180822/swift-adding-constraints-programmatically – Jan 03 '15 at 14:45

score 0 · Answer 4 · answered Jan 03 '15 at 15:11

0

Your scrollView doesn't have constraints

answered Jan 03 '15 at 15:11

Jakub Truhlář

20,070
9
74
84
