Keyboard overlapping issue on EditText with adjustpan not working

Question

I am using this code But the keyboard is still overlapping EditText. what can be done

    <android.support.v4.widget.SwipeRefreshLayout
        android:id="@+id/swipeContainer"
        android:layout_below="@+id/optionsBar"
        android:layout_above="@+id/bottomBar"
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        >

            <ListView
                android:id="@+id/listView"
                android:layout_width="match_parent"
                android:layout_height="match_parent"
                android:animationCache="false"
                android:divider="@null"
                android:scrollbars="none"
                android:overScrollMode="never"
                android:dividerHeight="0dp"
                android:listSelector="#00000000"
                android:fadingEdge="none"
                android:scrollingCache="false"
                 />

    </android.support.v4.widget.SwipeRefreshLayout>

        <RelativeLayout
            android:layout_alignParentBottom="true"
            android:layout_width="match_parent"
            android:layout_height="40dp"
            android:id="@+id/bottomBar"
            android:background="@drawable/top_bar_bg"
            >

            <EditText
                android:layout_width="match_parent"
                android:layout_height="30dp"
                android:inputType="text"
                android:paddingLeft="10dp"
                android:paddingRight="43dp"
                android:layout_marginRight="5dp"
                android:layout_centerVertical="true"
                android:maxLines="1"
                android:hint="Your Message"
                android:textColorHint="@android:color/white"
                android:layout_marginLeft="5dp"
                android:textColor="@android:color/white"
                android:textSize="12sp"
                android:id="@+id/chatBox"
                android:background="@drawable/message_type_area"
                 />

            <Button
                android:gravity="center"
                android:layout_height="23dp"
                android:layout_width="37dp"
                android:contentDescription="@null"
                android:background="@drawable/send_btn"
                android:layout_centerVertical="true"
                android:layout_alignParentRight="true"
                android:layout_marginRight="5dp"
                android:id="@+id/sendBtn"/>

        </RelativeLayout>

</RelativeLayout>

 <activity
            android:name=".ChatActivity"
            android:windowSoftInputMode="adjustPan"
            android:screenOrientation="portrait" >
        </activity>

enter image description here

do you, by any chance, have transparent status bar, navigation bar or full screen activity? — Zielony, Jan 25 '15 at 19:23

score 1 · Answer 1 · edited May 23 '17 at 11:33

1

Full screen disables soft input adjustment modes. See:

Android How to adjust layout in Full Screen Mode when softkeyboard is visible

https://issues.apache.org/jira/browse/CB-4404

https://groups.google.com/forum/#!msg/android-developers/T193nVgXDSA/O6UZmDqskFYJ

edited May 23 '17 at 11:33

Community

1
1

answered Jan 25 '15 at 19:28

Zielony

16,239
6
34
39

score 1 · Accepted Answer · edited May 23 '17 at 12:26

1

adjustResize fails to work when you use a FullScreenActivity. One solution would be to contain the whole layout in a ScrollView and scroll it to position editText.getY() + editText.getMeasuredHeight() when the editText gains focus.

Or, if you want a quick fix to the problem, have at look at this solution on a similar question here.

edited May 23 '17 at 12:26

Community

1
1

answered Jan 25 '15 at 19:28

Swayam

16,294
14
64
102

score 0 · Answer 3 · answered Feb 13 '17 at 12:43

The property android:windowSoftInputMode="adjustResize" doesn't work with full screen activity, you have to remove activity full screen flags in order to get advantage of adjust resize.

see this: A fullscreen window will ignore a value of SOFT_INPUT_ADJUST_RESIZE for the window's softInputMode field; the window will stay fullscreen and will not resize.

score 0 · Answer 4 · answered Feb 13 '17 at 12:50

0

android:maxLines="1" in your xml file and use in mainfiest file.

        <activity
        android:name="Logintab"

        android:windowSoftInputMode="adjustPan"
        android:label="@string/app_name"></activity>

answered Feb 13 '17 at 12:50

android_jain

788
8
19
