Dagger 1's plus() method is something I used quite often in previous applications, so I understand situations where you might want to have a subcomponent with full access to the parent graphs bindings.
In what situation would it be beneficial to use a component dependency instead of a subcomponent dependency and why?
Component dependencies - Use this when you want to keep two components independent.
Subcomponents - Use this when you want to keep two components coupled.
I will use the below example to explain Component dependencies and Subcomponents. Some points worth noticing about the example are:
SomeClassA1 can be created without any dependency. ModuleA provides and instance of SomeClassA1 via the provideSomeClassA1() method.SomeClassB1 cannot be created without SomeClassA1. ModuleB can provide an instance of SomeClassB1 only if an instance of SomeClassA1 is passed as an argument to provideSomeClassB1() method.@Module
public class ModuleA {
@Provides
public SomeClassA1 provideSomeClassA1() {
return new SomeClassA1();
}
}
@Module
public class ModuleB {
@Provides
public SomeClassB1 provideSomeClassB1(SomeClassA1 someClassA1) {
return new SomeClassB1(someClassA1);
}
}
public class SomeClassA1 {
public SomeClassA1() {}
}
public class SomeClassB1 {
private SomeClassA1 someClassA1;
public SomeClassB1(SomeClassA1 someClassA1) {
this.someClassA1 = someClassA1;
}
}
Dagger will take care of passing the instance of SomeClassA1 as an argument to provideSomeClassB1() method on ModuleB whenever the Component/Subcomponent declaring ModuleB is initialized. We need to instruct Dagger how to fulfill the dependency. This can be done either by using Component dependency or Subcomponent.
Note the following points in the Component dependency example below:
ComponentB has to define the dependency via the dependencies method on @Component annotation. ComponentA doesn't need to declare ModuleB. This keeps the two components independent.public class ComponentDependency {
@Component(modules = ModuleA.class)
public interface ComponentA {
SomeClassA1 someClassA1();
}
@Component(modules = ModuleB.class, dependencies = ComponentA.class)
public interface ComponentB {
SomeClassB1 someClassB1();
}
public static void main(String[] args) {
ModuleA moduleA = new ModuleA();
ComponentA componentA = DaggerComponentDependency_ComponentA.builder()
.moduleA(moduleA)
.build();
ModuleB moduleB = new ModuleB();
ComponentB componentB = DaggerComponentDependency_ComponentB.builder()
.moduleB(moduleB)
.componentA(componentA)
.build();
}
}
Note the following points in the SubComponent example:
ComponentB has not defined the dependency on ModuleA, it cannot live independently. It becomes dependent on the component that will provide the ModuleA. Hence it has a @Subcomponent annotation.ComponentA has declared ModuleB via the interface method componentB(). This makes the two components coupled. In fact, ComponentB can only be initialized via ComponentA.public class SubComponent {
@Component(modules = ModuleA.class)
public interface ComponentA {
ComponentB componentB(ModuleB moduleB);
}
@Subcomponent(modules = ModuleB.class)
public interface ComponentB {
SomeClassB1 someClassB1();
}
public static void main(String[] args) {
ModuleA moduleA = new ModuleA();
ComponentA componentA = DaggerSubComponent_ComponentA.builder()
.moduleA(moduleA)
.build();
ModuleB moduleB = new ModuleB();
ComponentB componentB = componentA.componentB(moduleB);
}
}
According to the documentation:
Component Dependency gives you access to only the bindings exposed as provision methods through component dependencies, i.e. you have access to only types which are declared in parent Component.
SubComponent gives you an access to the entire binding graph from its parent when it is declared, i.e. you have an access to all objects declared in its Modules.
Let's say, you have an ApplicationComponent containing all Android related stuff (LocationService, Resources, SharedPreference, etc). You also want to have your DataComponent where you manage things for persistence along with WebService to deal with APIs. The only thing you lack in DataComponent is Application Context which resides in ApplicationComponent. The simplest way to get a Context from DataComponent would be a dependency on ApplicationComponent. You need to be sure you have a Context explicitly declared in ApplicationComponent because you only have access to declared stuff. In this case, there is no manual work, meaning you don't need to specify Submodules in parent Component and explicitly add your submodule to a parent module like:
MySubcomponent mySubcomponent = myComponent.plus(new ChildGraphModule("child!")); // No need!
Now consider that case where you want to inject WebService from DataComponent and LocationService from ApplicationComponent into your Fragment which binds using the @Submodule plus feature above. The cool thing here is that the component you're binding to (ApplicationComponent) does not need to expose WebService nor LocationService because you have access to the entire graph right away.
Here is the code example with screenshot for more understanding of Component and SubComponent:
Component:
SubComponent:
And the Pictorial Diagram:
Source: link
One other thing that I didn't quite realize until now is that:
@Subcomponent instance has exactly one parent component (although different components can instantiate that same @Subcomponent and be that instance's parent)@Component may have zero, one, or many "parent" components declared through component dependencies
