Swift Tableview always showing separator lines

Question

I seem to have a weird problem with one of my tableviews where I can't hide the separator lines ( I think they're separator lines, except that they're centred on the screen instead of hard up against the right hand side ).

I create everything programmatically so no storyboard issues here.

You can see the tiny 1px line above each of the cells below.

I load my table using:

    self.tableView.frame = CGRectMake(0, 0, self.view.frame.width, self.view.frame.height)
    self.tableView.dataSource = self
    self.tableView.delegate = self
    self.tableView.registerClass(UITableViewCell.self, forCellReuseIdentifier: "cell")
    self.tableView.backgroundColor = UIColor.whiteColor()
    self.tableView.scrollEnabled = true
    self.tableView.bounces = false
    self.tableView.separatorStyle = UITableViewCellSeparatorStyle.None
    self.view.addSubview(self.tableView)

I also have a custom header which I implement using the following code:

func tableView(tableView: UITableView, willDisplayHeaderView view: UIView, forSection section: Int) {

    let header:UITableViewHeaderFooterView = view as! UITableViewHeaderFooterView

    header.textLabel.textColor = UIColor.whiteColor()
    header.textLabel.frame = header.bounds
    header.textLabel.textAlignment = NSTextAlignment.Center

    view.tintColor = constants.getTintColor()
    header.textLabel.textColor = UIColor.whiteColor()

}

I've tried loading the table without the willDisplayHeaderView and the issue persists.

I have also tried adding

tableview.separatorStyle = UITableViewCellSeparatorStyle.None

and

tableView.separatorColor = UIColor.clearColor()

to the following methods:

func tableView(tableView: UITableView, willDisplayCell cell: UITableViewCell, forRowAtIndexPath indexPath: NSIndexPath) {

    tableView.separatorStyle = UITableViewCellSeparatorStyle.None

}

func numberOfSectionsInTableView(tableView: UITableView) -> Int {

    tableView.separatorStyle = UITableViewCellSeparatorStyle.None

    return self.boards.count
}

func tableView(tableView: UITableView, numberOfRowsInSection section: Int) -> Int
{
    tableView.separatorStyle = UITableViewCellSeparatorStyle.None

    return self.boards[section].items.count
}

func tableView(tableView: UITableView, titleForHeaderInSection section: Int) -> String?
{
    tableView.separatorStyle = UITableViewCellSeparatorStyle.None

    return self.boards[section].name
}

EDIT:

The cells are standard UITableViewCells with alternating colors for the cells, this is being set through:

func tableView(tableView: UITableView, cellForRowAtIndexPath indexPath: NSIndexPath) -> UITableViewCell
{

    let cell:UITableViewCell = tableView.dequeueReusableCellWithIdentifier("cell", forIndexPath: indexPath) as! UITableViewCell

    cell.selectionStyle = UITableViewCellSelectionStyle.None

    if indexPath.row % 2 == 0 {
        // Even
        cell.backgroundColor = constants.UIColorFromRGB(0x1EACE0)
    } else {
        // Odd
        cell.backgroundColor = constants.UIColorFromRGB(0x6FBEE5)
    }

    cell.textLabel?.textColor = UIColor.whiteColor()
    cell.textLabel?.text = self.boards[indexPath.section].items[indexPath.row].title

    return cell
}

EDIT 2:

I've now added separator lines in and these aren't separators because you can still see them below the separator line.

HELP! I'm confused. I have a number of other tableviews setup the same (as far as I can see) and they work fine.

Thanks SO!

Answer 1

You can either use the Table View property for the seperatorStyle and use the property as such UITableViewCellSeparatorStyleNone

or use remove the separator from the StoryBoard

Set the property of the Seperator to None

Or one thing more while you are using header and Footer so the separator line would be Zero but there might be a extra separator or header and footer so refer to this link Eliminate extra separators below UITableView

Answer 2

in your viewDidLoad() function, add this:

tableView.tableFooterView = UIView()

Answer 3

Since you are not using custom cell's you need to do the following.

Create cell's as let cell : UITableViewCell = UITableViewCell(style:UITableViewCellStyle.Subtitle, reuseIdentifier:"cell")

and remove self.tableView.registerClass(UITableViewCell.self, forCellReuseIdentifier: "cell")

Answer 4

Here's a little additional information about eliminating the spurious separators that might be helpful. The solution that the originator said worked was this one that creates a new cell:

let cell : UITableViewCell = UITableViewCell(style:UITableViewCellStyle.Subtitle, reuseIdentifier:"cell")

But the originator did not say how he worked this into his code, whose original version used the two argument version of dequeueReusableCellWithIdentifier:

let cell : UITableViewCell = tableView.dequeueReusableCellWithIdentifier("cell", forIndexPath: indexPath) as! UITableViewCell

I experienced the same problem of spurious separators and found that using the single argument version of dequeueReusableCellWithIdentifier also fixes the problem:

let cell : UITableViewCell = tableView.dequeueReusableCellWithIdentifier("cell") as! UITableViewCell

Answer 5

I ran into same issue recently, and finally fixed by this in cell's init:

self.contentView.backgroundColor = UIColor.AppBgColor;
self.backgroundColor = UIColor.AppBgColor;

If you look closely in View Hierarchy, the cell's background and it's contentView's background are not same, which leads to this issue.
