Add white rectangle above a screenshot in a Graphics object (java)

Question

I've got a method that's supposed to add some text to screenshots. The screenshot is fed into this method as a File object like this:

private void modifyScreenshot(File file) throws Exception {

    String textToAdd = "Something something";

    BufferedImage image = ImageIO.read(file);

    Graphics g = image.getGraphics();

At this point, adding the text via g.drawString is easy to do. However, I want the text to not cover any of the actual screenshot, but be in a white area "above" the screenshot.

What I mean is, at this point, this is what the Graphics object looks like when it gets saved to file:

enter image description here

However, I want it to look like this instead, with the "Some text some text" being the string I specify in the code.

enter image description here

So, how would I be able to add white rectangle above the image where the text can be written?

EDIT: Note, this is not simply adding a string to an image. This involves "enlarging" the canvas to have white space for the string, so that the string is not over the actual image.

have you tried composing your text and image into a new image (and its graphics object)? — BeyelerStudios, Jun 11 '15 at 15:57
related http://stackoverflow.com/questions/2658554/using-graphics2d-to-overlay-text-on-a-bufferedimage-and-return-a-bufferedimage/2658663#2658663 — Madhawa Priyashantha, Jun 11 '15 at 15:58
I wouldn't consider this as a duplicate of the linked question. Here, there should be a title added (this means that, e.g. the target image has to be made larger (how much? See my answer...)). I'd vote for reopen (if I couldn't reopen it just so...) — Marco13, Jun 17 '15 at 22:21

score 3 · Accepted Answer · answered Jun 11 '15 at 15:59

Here's the rough idea:

BufferedImage image = ImageIO.read(file);
int whiteSpaceHeight = 20;
BufferedImage result = new BufferedImage(image.getWidth(),
      image.getHeight()+whiteSpaceHeight, image.getType());
Graphics graphics = result.getGraphics();
graphics.drawImage(image, 0, whiteSpaceHeight, null);
graphics.drawString(textToAdd, 0, whiteSpaceHeight/2);

Marco13 · Answer 2 · 2015-06-11T16:40:51.970

_{(Edit: Answer was rewritten - see history for details)}

The task that is indicated in the example image may in fact be a bit tricky: Namely, having multi-line text. But one simple solution here is to use a JLabel and a CellRendererPane for rendering the text, because it also supports HTML. So for a title like

String title =
    "<html><font size=4>This <font color=#FF0000><b>Text</b></font><br>" +
    "with line breaks<br>" +
    "will be the title</font></html>");

with line breaks and colors and a dedicated font size, one can obtain the appropriate image:

Titled image

Here is an example showing how this may be achieved:

import java.awt.Color;
import java.awt.Graphics2D;
import java.awt.image.BufferedImage;
import java.io.FileInputStream;
import java.io.FileOutputStream;
import java.io.IOException;
import java.io.InputStream;
import java.io.OutputStream;

import javax.imageio.ImageIO;
import javax.swing.CellRendererPane;
import javax.swing.ImageIcon;
import javax.swing.JFrame;
import javax.swing.JLabel;
import javax.swing.SwingUtilities;

public class TitleAdder
{
    public static void main(String[] args)
    {
        addTitle("yS2aQ.png", "output.png",
            "<html><font size=4>This <font color=#FF0000><b>Text</b></font><br>" +
            "with line breaks<br>" +
            "will be the title</font></html>");
    }

    private static void addTitle(
        String inputFileName, String outputFileName, String title)
    {
        try (InputStream in = new FileInputStream(inputFileName);
             OutputStream out = new FileOutputStream(outputFileName))
        {
            BufferedImage sourceImage = ImageIO.read(in);
            BufferedImage targetImage =
                addTitle(sourceImage, title);
            ImageIO.write(targetImage, "png", out);

            // Show the image, for testing
            show(targetImage);
        }
        catch (IOException e)
        {
            e.printStackTrace();
        }
    }

    private static BufferedImage addTitle(
        BufferedImage sourceImage, String title)
    {
        JLabel label = new JLabel(title);
        label.setBackground(Color.WHITE);
        label.setForeground(Color.BLACK);
        label.setOpaque(true);
        int titleHeight = label.getPreferredSize().height;
        int height = sourceImage.getHeight() + titleHeight;
        BufferedImage targetImage = new BufferedImage(
            sourceImage.getWidth(), height, BufferedImage.TYPE_INT_ARGB);
        Graphics2D g = targetImage.createGraphics();
        SwingUtilities.paintComponent(g, label, new CellRendererPane(),
            0, 0, sourceImage.getWidth(), titleHeight);
        g.drawImage(sourceImage, 0, titleHeight, null);
        g.dispose();

        return targetImage;
    }

    private static void show(final BufferedImage image)
    {
        SwingUtilities.invokeLater(new Runnable()
        {

            @Override
            public void run()
            {
                JFrame f = new JFrame();
                f.getContentPane().add(new JLabel(new ImageIcon(image)));
                f.pack();
                f.setLocationRelativeTo(null);
                f.setVisible(true);
            }
        });
    }
}
