The sandbox is not in sync with the Podfile.lock-ios

Question

I have got the following errors after trying multiple answers from the google.

PhaseScriptExecution Check\ Pods\ Manifest.lock /Users/apple/Library/Developer/Xcode/DerivedData/Build/Intermediates/FoodSpot.build/Debug-
    iphonesimulator/FoodSpotTests.build/Script-36819C3C1B6A30F50091382D.sh
        cd "/Users/apple/Downloads/FoodSpot 2"
        /bin/sh -c /Users/apple/Library/Developer/Xcode/DerivedData/Build/Intermediates/FoodSpot.build/Debug-iphonesimulator/FoodSpotTests.build/Script-36819C3C1B6A30F50091382D.sh

    diff: /../Podfile.lock: No such file or directory
    diff: /Manifest.lock: No such file or directory
    error: The sandbox is not in sync with the Podfile.lock.
    Run 'pod   install' or update your CocoaPods installation.

I have updated and installed many times, but they are of no use.

score 45 · Answer 1 · edited Sep 01 '18 at 12:39

45

For me, the reason was missign User-Defined variables in the Build Settings!

Looking into the issue, the Build Phases tries to diff 2 files.

diff "${PODS_PODFILE_DIR_PATH}/Podfile.lock" "${PODS_ROOT}/Manifest.lock" > /dev/null

Just because of missing PODS_PODFILE_DIR_PATH and PODS_ROOT variables, assumes them as "" so ${PODS_PODFILE_DIR_PATH}/Podfile.lock points to /Podfile.lock and same for the other one.
So it fails in

diff /Podfile.lock and /Manifest.lock

I fixed this by adding 2 User-Defined settings to the Build Settings

PODS_ROOT = ${SRCROOT}/Pods
PODS_PODFILE_DIR_PATH = ${SRCROOT}/.

After hours of searching this is the only solution that worked for me

edited Sep 01 '18 at 12:39

Zoe

27,060
21
118
148

answered Nov 04 '17 at 05:32

Arthur Kazemi

960
1
10
11

2

This is the proper solution to the problem. – Shihab Oct 29 '18 at 03:49
This was my situation also. I found that "pod deintegrate" and then running "pod install" added these settings back in for me so that I didn't need to set these myself explicitly. – mamills Apr 26 '19 at 19:57
I tried before with different solutions but this one is the most accurate. I tried the other solutions I was doing without understanding but now I understand. – soumare May 23 '19 at 16:55
'PODS_ROOT = ${SRCROOT}/Pods' isn't a valid name for a build setting. The first character should be a letter or an underscore, and the remaining characters should be letters, underscores, or numbers. I am receiving this error though I think its a valid name – Muhammad Awais Aug 07 '19 at 10:59
Perfect solution. – Manoj Alwis Dec 10 '20 at 00:45
Where do I set "User-Defined variables" in the "Build Settings" ? I have no such group under my Build Settings in Xcode (12.5). – kris Feb 23 '22 at 00:30
That is not true - I do have a "User-Defined " section - I just can't use the Search at the top of Build Settings to find it for some reason. So to get to User-Defined I scroll to the bottom of Build Settings - OR, I can use the little + button at the top to add a new one. Unfortunately this doesn't fully fix my build as I'm now facing "Runner-Bridging-Header.h:1:9: 'GeneratedPluginRegistrant.h' file not found" – kris Feb 23 '22 at 00:34

score 33 · Answer 2 · answered Feb 17 '16 at 02:28

33

For me, it works after the following:

pod deintegrate --verbose
pod install --verbose

answered Feb 17 '16 at 02:28

chubao

5,871
6
39
64

score 18 · Accepted Answer · edited May 23 '17 at 12:10

18

Run 'pod install' or update your CocoaPods installation.

You have answer in the error itself !

The error message states that you should update your CocoaPods installation.

You could remove libPods in frameworks and libraries and update Cocoapods using pod install.

Also:

clean and build the project

SO references :

CocoaPods Errors on Project Build

Error:"The sandbox is not in sync with the Podfile.lock..." after installing RestKit with cocoapods

edited May 23 '17 at 12:10

Community

1
1

answered Jul 31 '15 at 05:16

Tharif

13,794
9
55
77

2

clean and build the project – Tharif Jul 31 '15 at 06:21
2

For future seekers: Clean and build are both located under the "Product" tab of the main menu. – thumbtackthief Apr 06 '17 at 19:17

Eddie · Answer 4 · 2018-12-13T05:47:11.893

I had been searching for hours and I found solutions as follow:

In my case, method 3 works.

Method 1:

choose the target > go to Build Phrases > click Link Binary With Libraries > remove all libPods.a files
open Terminal > direct to your project > run:
```
 pod install
```
clean and build project

ref.1

Method 2:

open Terminal > direct to your project > run:

pod deintegrate --verbose
pod install --verbose

ref.2

Method 3:

choose the target > go to Build Settings > click "+" sign

add 2 User-Defined Settings: [to the left = to the right]

PODS_ROOT = ${SRCROOT}/Pods

and

PODS_PODFILE_DIR_PATH = ${SRCROOT}/

ref.3

score 5 · Answer 5 · edited Sep 01 '18 at 12:39

Just go to Build phases and click on [CP]check Pods Manifest.lock.

diff "${PODS_PODFILE_DIR_PATH}/Podfile.lock" "${PODS_ROOT}/Manifest.lock" > /dev/null

Both PODS_PODFILE_DIR_PATH and POD_ROOT should define in user-Defined in build settings. POD_ROOT should have correct path to Manifext.lock file and POD_PODFILE_DIR_PATH should have correct path for Podfile.lock

So Add below in build settings.

PODS_ROOT ---- ${SRCROOT}/Pods

PODS_PODFILE_DIR_PATH ---- ${SRCROOT}

Jack Vial · Answer 6 · 2018-10-02T22:27:08.750

3

The problem is Podfile.lock and Manifest.lock cannot be found by the Check Pods Manifest.lock Script in your targets build phase.

This is usually caused by PODS_PODFILE_DIR_PATH and PODS_ROOT variables not being defined.

Go to build settings tab to define them.

You will need to look for Podfile.lock and Manifest.lock in your project and get the the full paths of their directories. The directory paths will be the values you use for PODS_PODFILE_DIR_PATH and PODS_ROOT.

edited Oct 02 '18 at 22:27

answered Oct 02 '18 at 22:19

Jack Vial

2,354
1
28
30

1

Yes, I got the same issue it got fixed by ur answer. – Shakti Jun 08 '20 at 15:25

score 2 · Answer 7 · answered Apr 14 '16 at 13:10

2

Deleting the derived data did the trick for me . I deleted by going into the finder itself.

answered Apr 14 '16 at 13:10

Martin Jacob

356
1
7
16

score 2 · Answer 8 · answered Jun 08 '16 at 08:13

2

Make changes in the podfile as given below:

Older pod file

target :TargetName, :exclusive => true do

Changed pod file

target 'TargetName' do

answered Jun 08 '16 at 08:13

Apurv Pandey

217
2
7

score 2 · Answer 9 · edited Sep 01 '18 at 12:39

2

I'm pretty sure that you have opened your Projects' workspace which you try to install new Pods. So try out the following (for me this worked):

Clean the project
Close the project
Run pod install
Open the project and try re-building it once more

Problem might have been resolved.

edited Sep 01 '18 at 12:39

Zoe

27,060
21
118
148

answered Jul 21 '16 at 09:11

Randika Vishman

7,983
3
57
80

Daniel Douglas · Answer 10 · 2021-06-17T13:32:16.250

Edit

It turned out my issue was due to a new line at the end of the Manifest.lock that was not present in the PodFile.lock file. Running a diff on the two files highlighted the issue.

Adding a new line to the end of the PodFile.lock file solved it.

Original Answer

None of the answers have worked for me so I have just checked the "For install builds only" under "[CP] Check Pods Manifest. lock" which is found in the build phases tab.

I believe this setting means it will only run that check when archiving, allowing me to continue developing as I don't need to archive the app on my machine.

Use with caution though as it may not be the best solution for everyone.

Gurpartap Singh · Answer 11 · 2018-09-03T10:29:55.647

Make sure you add a "pod install" command line build step, before the Xcode Project build step.

The error is coming from the build phase run script in your Xcode project's target, which is unable to find Podfile.lock. This file is generated by CocoaPods, which must be installed in a build step in your TeamCity project.

My build steps look like:

Command line: bundle install --path .bundle (installs cocoapods local to the project using Gemfile).
Command line: bundle exec pod install --verbose (uses Podfile)
Command line: carthage update --platform iOS (uses Cartfile)
Xcode Project
Command line to build an archive
Command line to upload a build

Hope this helps.

score 1 · Answer 12 · edited Sep 01 '18 at 12:39

1

In my case, I got same error after integrating my other targets. To solve problem I needed to add both targets in Podfile:

abstract_target 'myApp' do
   use_frameworks!

   pod 'Alamofire', '~> 3.0'
   pod 'SwiftyJSON'

    target 'myAppOtherTarget'
end

edited Sep 01 '18 at 12:39

Zoe

27,060
21
118
148

answered Oct 06 '16 at 13:08

Phd. Burak Öztürk

1,727
19
29

score 1 · Answer 13 · edited Apr 27 '17 at 11:35

1

This happens if cocoa pods don't install or uninstall properly

If you want to install cocoa pods run

pod install

if you you want to uninstall cocoa pods then run command

pod deintegrate

edited Apr 27 '17 at 11:35

Mad Physicist

107,652
25
181
264

answered Apr 27 '17 at 11:13

Manish

11
3

score 1 · Answer 14 · answered Jul 04 '17 at 01:56

I had the same issue. Turned out the cocoapods version on Manifest.lock was higher than what I had on my mac. I had to do a 'sudo gem install cocoapods', to get the version of the cocoapods upto what was specified on the Manifest.lock file. This fixed the issue and I had no errors on building the project.

score 1 · Answer 15 · answered Sep 18 '17 at 13:52

1

Im facing the same issue now and fixed using this command after navigating to project location in terminal.

pod install --repo-update

answered Sep 18 '17 at 13:52

Gobi M

3,243
5
32
47

score 1 · Answer 16 · edited Sep 01 '18 at 12:37

1

I fixed this by adding 2 User-Defined settings to the Build Settings

PODS_ROOT = ${SRCROOT}/Pods
PODS_PODFILE_DIR_PATH = ${SRCROOT}/.

edited Sep 01 '18 at 12:37

Zoe

27,060
21
118
148

answered Sep 01 '18 at 12:33

Fabio Valencio

11
2

score 0 · Answer 17 · answered Jul 06 '16 at 04:31

0

In my case, the errors were occurring on a _Tests target. I didn't need the _Tests target, and so I deleted it. This resolved the error.

answered Jul 06 '16 at 04:31

Chris Prince

7,288
2
48
66

Deepak Badiger · Answer 18 · 2017-12-06T21:33:38.210

If you happen to move your Podfile like i did and face this issue, the solution discussed below may help -

Delete all of the following - Pods folder, xcworkspace file, podlock file (skip the ones that are not available for subfolders)
delete all steps that has [cp] in it from the build phase tab
repeat step 1 & 2 for all the sub projects that you have in your workspace
open workspace, go into each project and delete framework for pods, and delete the pods folder from each project
close workspace
run pod install

you should now be able to open, build and run the project

score 0 · Answer 19 · answered Aug 16 '19 at 11:14

I just fixed it by updating the Cocoapod, cause before the error there was log where the warning shows we need to upgrade our cocoapods as the pod files are not supported by the current cocoapod version, So clean the project , upgrade cocoapod then install pod.

1. Clean project
2. sudo gem install cocoapods/gem install cocoapods
3. pod install (optional if your project still shows error)

Note: I found this error for my flutter application in iOS platform

score 0 · Answer 20 · edited Feb 15 '20 at 10:25

0

I think you are trying to use your old project pod folder in your current project, you have to copy Manifest.lock file of your current project and replace that file in your old project's pod folder which you added. Manifest.lock file location YourProject->Pods->Manifest.lock Hope This was helpful. worked for me!

edited Feb 15 '20 at 10:25

answered Feb 15 '20 at 06:24

Furkiii

1

Harsha · Answer 21 · 2020-07-08T09:50:19.523

Please check Top Sites - Sandbox Sync iOS for more explanation. I fixed the issue by changing file paths from

diff "${PODS_PODFILE_DIR_PATH}/Podfile.lock" "${PODS_ROOT}/Manifest.lock" > /dev/null

to

diff "${SRCROOT}/Podfile.lock" "${SRCROOT}/Pods/Manifest.lock" > /dev/null

in Xocde -> "Open Your Project" -> "Select Your Project" -> "Select Your Target" -> Build Phases -> Check Pods Manifest.lock

If not, try changing paths as mentioned above, along with Legacy Build System. To change build system Xcode -> File -> Workspace Settings -> Build System -> Legacy Build System

score -1 · Answer 22 · answered Feb 06 '21 at 01:54

I hate to say this, but I just removed the pods/ or didn't include them in the project and it built. I don't know if this will have a long-term effect on the project though.

This is presently my .sh build script for ionic5 for ios. It will probably change in the future.

# BUILDING FOR IOS

##################################
#
#     MAKE SURE YOU UNPLUG ALL DEVICES!!!!!
#
##################################


ionic cordova platform remove ios
ionic cordova prepare ios
ionic cordova platform add ios
ionic cordova build ios --prod --release --buildFlag="-UseModernBuildSystem=0" --verbose
cd platforms
cd ios
open "MyApp.xcworkspace/"
cd ..
cd ..

It had be plaguing my project, so I thought I'd take them out. I am yet to deploy the project so far though... so who knows. BigSur 11.1, XCode 12.4 (12D4e)
