How do i combine two text field

Question

I need help with combining two text view to complete my spelling bee interface. As shown below my underscore and the text it separated with a huge gap. What can i do to merge them?

As requested below contains my xml codes for the text view. I put them both in a linear layout to try to center them both together. The only problem seems to be only the gap.

<LinearLayout
    android:orientation="vertical"
    android:layout_width="fill_parent"
    android:layout_height="wrap_content"
    android:layout_marginTop="28dp"
    android:gravity="center_horizontal"
    android:layout_below="@+id/btnSound"
    android:layout_alignParentRight="true"
    android:layout_alignParentEnd="true">

    <TextView android:text="@string/randomwords" android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:id="@+id/RandomWords"
        android:textSize="25sp"
        android:layout_below="@+id/btnSound"
        android:layout_centerHorizontal="true" />

    <TextView
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:textSize="25sp"
        android:textAppearance="?android:attr/textAppearanceLarge"
        android:id="@+id/lblUnderscore"
        android:gravity="top" />
</LinearLayout>

Answer FOUND!! Using FRAMELAYOUT.

It's close but not perfect.

yes, this cant be answered without knowing at least the type of layout — Nick Cardoso, Aug 05 '15 at 06:33
If you want superimposed `TextView`, why not use `FrameLayout` ? — Mithun, Aug 05 '15 at 06:39

score 0 · Answer 1 · answered Aug 05 '15 at 06:36

Just switching to a relative layout and adding a layout_below should fix things:

<RelativeLayout
    android:layout_width="fill_parent"
    android:layout_height="wrap_content"
    android:layout_marginTop="28dp"
    android:gravity="center_horizontal"
    android:layout_below="@+id/btnSound"
    android:layout_alignParentRight="true"
    android:layout_alignParentEnd="true">

    <TextView android:text="@string/randomwords"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:id="@+id/RandomWords"
        android:textSize="25sp"
        android:layout_below="@+id/btnSound"
        android:layout_centerHorizontal="true" />

    <TextView android:layout_below="@id/RandomWord"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:textSize="25sp"
        android:textAppearance="?android:attr/textAppearanceLarge"
        android:id="@+id/lblUnderscore"
        android:gravity="top" />
</RelativeLayout>

You could also put the underlines first (so it ends up behind) and on the randomwords use layout_bottom to get the letters to overline the underscores slightly if thats what you want

What didnt work? what did it do? Is there more in this layout you havent included? — Nick Cardoso, Aug 05 '15 at 06:47

score 0 · Answer 2 · answered Aug 05 '15 at 06:53

How about do like this with one textview?

Textview tv= (TextView)findViewById(R.id.randomwords);
tv.setText(Html.fromHtml(test("prospective")));

.............

public String test(String str) {
    char [] charArr = str.toCharArray();
    String htmlStr = "";
    for (int i = 0; i < charArr.length; i++) {
        htmlStr += "<u>" + charArr[i] + "</u>"+" ";
    }
    return htmlStr;
}
