create below layout Android

Question

I want to create below layout in XML. I am able to create circle but I don't know how to connect them by a horizontal line:

Put a generic View in between the TextViews, with a fixed height of 1dp (or what you see fit). And as a background, use a color. — Phantômaxx, Sep 09 '15 at 10:23
Draw a line like @FrankN.Stein said, refer this http://stackoverflow.com/questions/19115332/android-draw-a-horizontal-line-between-views — Emil, Sep 09 '15 at 10:25

score 1 · Answer 1 · answered Sep 09 '15 at 10:27

1

You can do it by using LinearLayout

<LinearLayout
.......
......>
       <CircleView..../>
       <View
          android:layout_width="50dp"
          android:layout_height="2dp"
          android:background="@color/circle_color"/>
       <CircleView..../>

       <View
          android:layout_width="50dp"
          android:layout_height="2dp"
          android:background="@color/circle_color"/>

       <CircleView..../>


</LinearLayout>

answered Sep 09 '15 at 10:27

N J

27,217
13
76
96

Can you give some more piece of code for clarity – user3154663 Sep 09 '15 at 10:45
you can create circle drawable for normal and selected view take checkbox instead of CircleView apply selector to checkbox, sma you can do to line selector – N J Sep 09 '15 at 10:52

score 0 · Answer 2 · answered Sep 09 '15 at 10:29

0

Generally these (step-by-step) indicators are implemented using different images loaded via single ImageView. Just load the appropriate drawable for a particular step. This way you need not worry about writing/arranging lot of UI widgets in xml.

I am attaching sample images for your reference:

step 1 of 4:

step 2 of 4:

step 3 of 4:

step 4 of 4:

answered Sep 09 '15 at 10:29

Gagan

1,497
1
12
27

Can i do this by xml without using images? – user3154663 Sep 09 '15 at 10:31
You surely can but you will have to write quite a lot views for that (5 views for a 3 step process) and arranging those horizontal connectors between the circular views will take some time. Moreover, if you choose to change the layout in future then it will be a complete rework. :) – Gagan Sep 09 '15 at 10:36
