How to make fragment overlay toolbar in navigation drawer

Question

I have a material design navigation drawer i created from this tutorial.

It works perfect with toolbar and all. I can click on an item in the drawer and the respective fragment is displayed plus the title.

However i would like to make the toolbar on one fragment to be transparent so that the background image is displayed like in the image below:

PROBLEM: My problem is the fragment doesnt seem to start over the toolbar but below it.This is the result:

I dont know how to fix this.Any suggestions will be welcomed.

[How do I use DrawerLayout to display over the ActionBar/Toolbar and under the status bar? - Stack Overflow][1] [1]: http://stackoverflow.com/questions/26440879/how-do-i-use-drawerlayout-to-display-over-the-actionbar-toolbar-and-under-the-st — kris larson, Sep 20 '15 at 02:11
I know how to do what you have suggested above.But the problem is not with the drawe but with the fragment displayed. — Steve Kamau, Sep 20 '15 at 09:01
@SteveKamau I am having the exact same problem! Can you tell me if you have resolved it and if so how? — amateur programmer, Sep 02 '18 at 00:18
@amateurprogrammer simply create a transparent toolbar, then toggle the background from transparent to your primary colour on the appropriate fragment. — Steve Kamau, Sep 02 '18 at 15:50
@SteveKamau I tried that but I wasn't getting the result, can you post what you came up with as an answer to this question? — amateur programmer, Sep 02 '18 at 16:34

score 0 · Answer 1 · answered Sep 20 '15 at 23:23

Use this for toolbar.xml:

<?xml version="1.0" encoding="utf-8"?>
<FrameLayout
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:local="http://schemas.android.com/apk/res-auto"
    android:layout_width="match_parent"
    android:layout_height="wrap_content">

    <ImageView
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:adjustViewBounds="true"
        android:src="@drawable/toolbar_image"/>

    <android.support.v7.widget.Toolbar
        android:id="@+id/toolbar"
        android:layout_width="match_parent"
        android:layout_height="?attr/actionBarSize"
        local:theme="@style/ThemeOverlay.AppCompat.Dark.ActionBar"
        local:popupTheme="@style/ThemeOverlay.AppCompat.Light" />

</FrameLayout>

Of course, you'll need to change "@drawable/toolbar_image" to the drawable that you want to use for the background image.
