iOS ViewController subview moving when keyboard is presented

Question

I have a UITableView which is a property of my view controller. This view controller is positioned 40 pixels below the top of the screen using autolayout + storyboard constraints. I recently added a label and textfield that are initially hidden in storyboard and constrained to be directly behind the tableview.

I added a method to display these fields:

-(void)showNeighborhoodFilter { [UIView animateWithDuration:.5 animations:^{ if (self.neighborhoodLabel.hidden) { self.neighborhoodLabel.hidden=NO; self.neighborhoodSelector.hidden=NO; self.tableView.frame = CGRectMake(0, self.tableView.frame.origin.y+40, self.tableView.frame.size.width, self.tableView.frame.size.height-40); } else{ self.neighborhoodLabel.hidden=YES; self.neighborhoodSelector.hidden=YES; self.tableView.frame = CGRectMake(0, self.tableView.frame.origin.y-40, self.tableView.frame.size.width, self.tableView.frame.size.height+40); } }]; }

This seems to work fine except when I tap the textfield, it moves the tableview back up above the hidden textfield. I am at a loss for what's going on.

Why are you editing the frame if you're using constraints? – Wain Dec 04 '15 at 00:06 — Wain, Dec 04 '15 at 00:06

score 1 · Accepted Answer · edited May 23 '17 at 12:15

For changing text filed height declare NSLayoutConstraint variable constraint in your controller.

In .h file:

    __weak IBOutlet NSLayoutConstraint *heightConstraintOfMyView;//height of the view
    __weak IBOutlet NSLayoutConstraint *verticalspaceConstraintOfMyViewWithTopView;//space between myview and the view just above it
    __weak IBOutlet NSLayoutConstraint *verticalSpaceConstraintOfMyViewWithBottomView;//space between myview and the view just below it

In your storyboard

Connected

Vary the frame using constraints.

if (myConditionTrueForShowingView) {
        //setting the constraint to update height
        heightConstraintOfMyView = 40;
        verticalspaceConstraintOfMyViewWithTopView.constant=20;
        verticalSpaceConstraintOfMyViewWithBottomView.constant=80;
     }
  else{
        //setting the constraint to update height
        heightConstraintOfMyView = 0;
        verticalspaceConstraintOfMyViewWithTopView.constant=20;
        verticalSpaceConstraintOfMyViewWithBottomView.constant=0;
     }

You can also register for keyboard notifications.

- (void)registerForKeyboardNotifications
{
    [[NSNotificationCenter defaultCenter] addObserver:self
                                             selector:@selector(keyboardWasShown:)
                                                 name:UIKeyboardDidShowNotification object:nil];

    [[NSNotificationCenter defaultCenter] addObserver:self
                                             selector:@selector(keyboardWillBeHidden:)
                                                 name:UIKeyboardWillHideNotification object:nil];

}

And Handle the height changes in the notifications call back-

@property (weak, nonatomic) IBOutlet NSLayoutConstraint *tableBottomSpaceConstrain;

-(void)keyboardWasShown:(NSNotification*)aNotification
{
    self.view.translatesAutoresizingMaskIntoConstraints = YES;
    if (self.tableBottomSpaceConstrain.constant) {//
        return;
    }
    self.tableBottomSpaceConstrain.constant = 216;// Default Keyboard height is 216, varies for third party keyboard
    [self.view setNeedsUpdateConstraints];
    [self.view updateConstraints];
    [self.view layoutIfNeeded];
    [self.view setNeedsLayout];

    [self.view setNeedsUpdateConstraints];
}

- (void)keyboardWillBeHidden:(NSNotification*)aNotification
{
    self.tableBottomSpaceConstrain.constant =0;
    [self.view layoutIfNeeded];
    [self.view setNeedsLayout];
    [self.view updateConstraints];
}

Learn more about NSLayoutConstraint Implementing AutoLayout Constraints in Code

See Apple Doc

You can use some third party code if textfield is part of tableviewTPKeyboardAvoiding

See this link: How to make a UITextField move up when keyboard is present?

Making a UITableView scroll when text field is selected

score 0 · Answer 2 · answered Dec 04 '15 at 00:06

0

If you use auto-layout, you cannot move a view that has constraints, it will be moved again any time iOS decides to recompute the constraints.

You need to either change the constraints (you can change the constant), or enable/disable constraints.

answered Dec 04 '15 at 00:06

jcaron

17,302
6
32
46

I hate constraints. Views ware a lot more easier to manage in code on iOS 6. – m.ding Dec 04 '15 at 00:09
