How to replicate foreign key of another table in one to many relationship

Question

I have a three table structure: tournament, group and team. The tournament and group tables have a one-to-many relation, and group and team have a one-to-many relation as shown below.

How do i replicate the value of the tournament_id from group table into the group_tournament_id of team table?

i'm looking for an answer which will achieve this using the create statement like

create table team (
    id serial primary key,
    group_id int references group,
    group_tournament_id int references group(tournament_id)
);

of course this would not work because in order to reference something it has to be unique, in this case tournament_id is not unique

i need a standard way to copy over the value of tournament_id from group into 'team' table's group_tournament_id when ever i insert group_id inside team table

edit: no longer need answer in symfony, just postgreSQL would be fine

Here you have how to relation entities :http://doctrine-orm.readthedocs.org/projects/doctrine-orm/en/latest/reference/association-mapping.html, and here symfony docs about mapping : http://symfony.com/doc/current/book/doctrine.html#add-mapping-information — fito, Jan 13 '16 at 16:48
I think it would help if your question were a little more specific in what you are trying to do and contained some code that you might have tried. — Jason Roman, Jan 22 '16 at 15:17
Normally, the `team` table should have only `group_id` and should **not** have `tournament_id` at all. I don't understand why you de-normalize your schema. — Vladimir Baranov, Feb 01 '17 at 11:50
in a scenario where we want to apply constraints on multiple columns a replicated foreign key would be very helpful and actually reduce the amount of relationships and simplify query a lot eg:- we want to make the combination of group_id and tournament_id [from group table] unique so that the same groups are't added to the tournament multiple times — some_groceries, Feb 01 '17 at 18:26

score 5 · Accepted Answer · answered Feb 01 '17 at 11:42

You should use the reference directly from teams to tournaments. Use a trigger to automatically obtain the appropriate reference from groups. (Note however that the reference is not necessary as you can always get tournament_id from groups in a query. I assume that this reference is to simplify some queries).

I've slightly modified the names of tables and columns (group cannot be a name of a table).

Tables:

create table tournaments (
    tournament_id serial primary key);

create table groups (
    group_id serial primary key,
    tournament_id int references tournaments);

create table teams (
    team_id serial primary key,
    group_id int references groups,
    tournament_id int references tournaments);

Trigger:

create or replace function before_insert_or_update_on_teams()
returns trigger language plpgsql as $$
begin
    new.tournament_id = (
        select tournament_id
        from groups
        where group_id = new.group_id
        limit 1);
    return new;
end $$;

create trigger before_insert_or_update_on_teams
before insert or update on teams
for each row execute procedure before_insert_or_update_on_teams();

Test:

insert into tournaments values (default), (default);
insert into groups values (default, 2);
insert into teams values (default, 1, null);

select * from teams;

 team_id | group_id | tournament_id
---------+----------+---------------
       1 |        1 |             2
(1 row)

any other ways to achieve this without triggers? OP asked alternatives to triggers — some_groceries, Feb 01 '17 at 18:54
Oh, yes, I haven't read the bounty note. If I saw it I would not post the answer. But ... what's wrong with a trigger? This is the most natural and standard solution in cases like this. — klin, Feb 01 '17 at 19:29

score 3 · Answer 2 · edited May 23 '17 at 12:17

You can just use identifying relationships:

This produces keys which "propagate" all the way down, so you get team.tournament_id which is guaranteed to point to the same tournament as the parent group.

Note that I used group_no (not group_id), as a naming convention to indicate it doesn't identify the group alone, but in combination with the tournament_id. Ditto for team_no.

This complicates insertion, though. You can no longer just let the database generate the next auto-incremented ID for your group or team (because you are now identifying it with a combination of values, not just one value), but you can easily do it manually - e.g. when inserting into group, assign SELECT MAX(group_no) + 1 FROM group WHERE tournament_id = ... to the new group_no, and similar for the team.

BTW, this can be done in addition to surrogate keys (the id in your diagram), if you still need them.

score 1 · Answer 3 · answered Feb 08 '17 at 08:25

You can use a SELECT to feed a value with INSERT or UPDATE:

INSERT INTO "teams" ("group_id", "tournament_id")
SELECT $1, "groups"."tournament_id"
  FROM "groups" WHERE ("groups"."id" = $1)
RETURNING "id"

This is what I am using to let Postgres insert ids for foreign keys without the (unconsistent) double query (select from groups, insert into teams).
