JPQL Right Join

Question

After search I came to know that there is no Right Join in JPQL. I saw there is another way to achieve it using JPA bidirectional (not right join but using pojo object ) but one thing I noticed in console that it make many calls to database for eg see below table.

       Flat Table                   UserToFlat                    User
| Flat_ID  |  Flat No  |      | ID   |  Flat_ID | User_ID |    | User_ID | Name |
|  1       |    101    |      | 1    |    1     |  1      |    |   1     | XYZ  |
|  2       |    102    |      | 2    |    2     |  2      |    |   2     | PQR  |
|  3       |    103    |      | 3    |    3     |  3      |    |   3     | ABC  |
|  4       |    104    |

I want all rows from flat table and only matching rows from User table

// below query do not work as flat is having primary key and usertoflat having foreign key
select f, u from FlatEntity f left join f.userToFlatEntity uf join uf.user u;

// now if I try right join then jpql throws exception
select f from UserToFlatEntity uf right join uf.flatEntity f;

Now if I use jpql birectional and fetch using object for eg

// suppose I have FlatEntity Object
flatEntity.getUserToFlatEntity();

above code will hits database for every flat no with where condition flat_ID = ? (4 times in this case ) and I think this not good performance wise.

So is there any way I can JPQL achieve right join with out effecting performance.

Entity Configuration

public class FlatEntity {
    @OneToOne(mappedBy = "flatEntity")
    private UserToFlatEntity userToFlatEntity;

   // getter setter
}

public class UserToFlatEntity {
    @ManyToOne
    @JoinColumn(name = "flatId", insertable = false, updatable = false)
    private FlatEntity flatEntity;
}

public class UserEntity {
    @OneToMany(mappedBy = "userEntity")
    private Set<UserToFlatEntity> userToFlatEntitySet;
}

Exception
 Path expected for join!
 at org.hibernate.hql.internal.ast.HqlSqlWalker.createFromJoinElement(HqlSqlWalker.java:369)

@DraganBozanovic Can you please give me some example because I am getting error. I am posting my mapping configuration. — pise, Feb 06 '16 at 18:27
I don't see any `from` clauses in your queries. I suggest you go through some Hibernate/JPA tutorials first. — Dragan Bozanovic, Feb 06 '16 at 19:49
@DraganBozanovic it was my typing error not having from clause — pise, Feb 10 '16 at 19:00
Ok, could you then please post the errors you get with right join? — Dragan Bozanovic, Feb 10 '16 at 19:01
@DraganBozanovic JPQL query `select f from UserToFlatEntity uf right join uf.flatEntity ` error I am getting `No data type for node: org.hibernate.hql.internal.ast.tree.IdentNode \-[IDENT] IdentNode: 'f' {originalText=f}` — pise, Feb 10 '16 at 19:03
@DraganBozanovic I was f alias to flatEntity in query and because of that it was throughing error. — pise, Feb 10 '16 at 19:09
@DraganBozanovic is there any Jpql eclipse tool where I can directly run JPQL query. — pise, Feb 10 '16 at 19:10
[What topics can I ask about here?](http://stackoverflow.com/help/on-topic) _"4. Questions asking us to recommend or find a book, tool, software library, tutorial or other off-site resource are off-topic for Stack Overflow as they tend to attract opinionated answers and spam."_ — Dragan Bozanovic, Feb 10 '16 at 19:14

score 5 · Accepted Answer · edited May 23 '17 at 12:30

5

You should make the Flat table the owner side of the relationship (which make more logical sense IMO). Then you can use a LEFT JOIN instead of a RIGHT JOIN.

SELECT uc, MAX(ua.accessTs) FROM Flat Table uc LEFT JOIN uc.User Table ua

Here's why left join on UserTable works:

for more detail visit here : RIGHT JOIN in JPQL

edited May 23 '17 at 12:30

Community

1
1

answered Feb 17 '16 at 13:18

Harshad

1,344
1
10
25

score 4 · Answer 2 · answered Feb 13 '16 at 23:28

4

RRIGHT JOINS aka RRIGHT OUTER JOINS is the same as

SLEFT JOINR aka SLEFT OUTER JOINR.

answered Feb 13 '16 at 23:28

philipxy

14,867
6
39
83

score 0 · Answer 3 · answered Feb 15 '16 at 18:21

You won't find any (working) examples of a right join in JPQL. As mentioned in this EclipseLink forum post, the JPA specification does not include a right join:

The JPA spec only defines a Left Outer Join. Feel free to file an EclipseLink enhancement or request its inclusion in the JPA specification.

Maybe you can resort to a native query?
