What is the difference between 'SAME' and 'VALID' padding in tf.nn.max_pool of tensorflow?
In my opinion, 'VALID' means there will be no zero padding outside the edges when we do max pool.
According to A guide to convolution arithmetic for deep learning, it says that there will be no padding in pool operator, i.e. just use 'VALID' of tensorflow.
But what is 'SAME' padding of max pool in tensorflow?
If you like ascii art:
"VALID" = without padding:
inputs: 1 2 3 4 5 6 7 8 9 10 11 (12 13)
|________________| dropped
|_________________|
"SAME" = with zero padding:
pad| |pad
inputs: 0 |1 2 3 4 5 6 7 8 9 10 11 12 13|0 0
|________________|
|_________________|
|________________|
In this example:
Notes:
"VALID" only ever drops the right-most columns (or bottom-most rows)."SAME" tries to pad evenly left and right, but if the amount of columns to be added is odd, it will add the extra column to the right, as is the case in this example (the same logic applies vertically: there may be an extra row of zeros at the bottom).Edit:
About the name:
"SAME" padding, if you use a stride of 1, the layer's outputs will have the same spatial dimensions as its inputs."VALID" padding, there's no "made-up" padding inputs. The layer only uses valid input data.
When stride is 1 (more typical with convolution than pooling), we can think of the following distinction:
"SAME": output size is the same as input size. This requires the filter window to slip outside input map, hence the need to pad. "VALID": Filter window stays at valid position inside input map, so output size shrinks by filter_size - 1. No padding occurs.
I'll give an example to make it clearer:
x: input image of shape [2, 3], 1 channelvalid_pad: max pool with 2x2 kernel, stride 2 and VALID padding.same_pad: max pool with 2x2 kernel, stride 2 and SAME padding (this is the classic way to go)The output shapes are:
valid_pad: here, no padding so the output shape is [1, 1]same_pad: here, we pad the image to the shape [2, 4] (with -inf and then apply max pool), so the output shape is [1, 2]x = tf.constant([[1., 2., 3.],
[4., 5., 6.]])
x = tf.reshape(x, [1, 2, 3, 1]) # give a shape accepted by tf.nn.max_pool
valid_pad = tf.nn.max_pool(x, [1, 2, 2, 1], [1, 2, 2, 1], padding='VALID')
same_pad = tf.nn.max_pool(x, [1, 2, 2, 1], [1, 2, 2, 1], padding='SAME')
valid_pad.get_shape() == [1, 1, 1, 1] # valid_pad is [5.]
same_pad.get_shape() == [1, 1, 2, 1] # same_pad is [5., 6.]
The TensorFlow Convolution example gives an overview about the difference between SAME and VALID :
For the SAME padding, the output height and width are computed as:
out_height = ceil(float(in_height) / float(strides[1]))
out_width = ceil(float(in_width) / float(strides[2]))
And
For the VALID padding, the output height and width are computed as:
out_height = ceil(float(in_height - filter_height + 1) / float(strides[1]))
out_width = ceil(float(in_width - filter_width + 1) / float(strides[2]))
Complementing YvesgereY's great answer, I found this visualization extremely helpful:
Padding 'valid' is the first figure. The filter window stays inside the image.
Padding 'same' is the third figure. The output is the same size.
Found it on this article
Visualization credits: vdumoulin@GitHub
Padding is an operation to increase the size of the input data. In case of 1-dimensional data you just append/prepend the array with a constant, in 2-dim you surround matrix with these constants. In n-dim you surround your n-dim hypercube with the constant. In most of the cases this constant is zero and it is called zero-padding.
Here is an example of zero-padding with p=1 applied to 2-d tensor:
You can use arbitrary padding for your kernel but some of the padding values are used more frequently than others they are:
k
k, this padding is equal to k - 1.To use arbitrary padding in TF, you can use tf.pad()
Quick Explanation
VALID: Don't apply any padding, i.e., assume that all dimensions are valid so that input image fully gets covered by filter and stride you specified.
SAME: Apply padding to input (if needed) so that input image gets fully covered by filter and stride you specified. For stride 1, this will ensure that output image size is same as input.
Notes
NO_PADDING instead.AUTO_PADDING instead.SAME (i.e. auto-pad mode), Tensorflow will try to spread padding evenly on both left and right.VALID (i.e. no padding mode), Tensorflow will drop right and/or bottom cells if your filter and stride doesn't full cover input image.
I am quoting this answer from official tensorflow docs https://www.tensorflow.org/api_guides/python/nn#Convolution For the 'SAME' padding, the output height and width are computed as:
out_height = ceil(float(in_height) / float(strides[1]))
out_width = ceil(float(in_width) / float(strides[2]))
and the padding on the top and left are computed as:
pad_along_height = max((out_height - 1) * strides[1] +
filter_height - in_height, 0)
pad_along_width = max((out_width - 1) * strides[2] +
filter_width - in_width, 0)
pad_top = pad_along_height // 2
pad_bottom = pad_along_height - pad_top
pad_left = pad_along_width // 2
pad_right = pad_along_width - pad_left
For the 'VALID' padding, the output height and width are computed as:
out_height = ceil(float(in_height - filter_height + 1) / float(strides[1]))
out_width = ceil(float(in_width - filter_width + 1) / float(strides[2]))
and the padding values are always zero.
There are three choices of padding: valid (no padding), same (or half), full. You can find explanations (in Theano) here: http://deeplearning.net/software/theano/tutorial/conv_arithmetic.html
The valid padding involves no zero padding, so it covers only the valid input, not including artificially generated zeros. The length of output is ((the length of input) - (k-1)) for the kernel size k if the stride s=1.
The same padding makes the size of outputs be the same with that of inputs when s=1. If s=1, the number of zeros padded is (k-1).
The full padding means that the kernel runs over the whole inputs, so at the ends, the kernel may meet the only one input and zeros else. The number of zeros padded is 2(k-1) if s=1. The length of output is ((the length of input) + (k-1)) if s=1.
Therefore, the number of paddings: (valid) <= (same) <= (full)
VALID padding: this is with zero padding. Hope there is no confusion.
x = tf.constant([[1., 2., 3.], [4., 5., 6.],[ 7., 8., 9.], [ 7., 8., 9.]])
x = tf.reshape(x, [1, 4, 3, 1])
valid_pad = tf.nn.max_pool(x, [1, 2, 2, 1], [1, 2, 2, 1], padding='VALID')
print (valid_pad.get_shape()) # output-->(1, 2, 1, 1)
SAME padding: This is kind of tricky to understand in the first place because we have to consider two conditions separately as mentioned in the official docs.
Let's take input as
, output as
, padding as
, stride as
and kernel size as
(only a single dimension is considered)
Case 01:
:
Case 02:
:
is calculated such that the minimum value which can be taken for padding. Since value of is known, value of
can be found using this formula
.
Let's work out this example:
x = tf.constant([[1., 2., 3.], [4., 5., 6.],[ 7., 8., 9.], [ 7., 8., 9.]])
x = tf.reshape(x, [1, 4, 3, 1])
same_pad = tf.nn.max_pool(x, [1, 2, 2, 1], [1, 2, 2, 1], padding='SAME')
print (same_pad.get_shape()) # --> output (1, 2, 2, 1)
Here the dimension of x is (3,4). Then if the horizontal direction is taken (3):
If the vertial direction is taken (4):
Hope this will help to understand how actually SAME padding works in TF.
To sum up, 'valid' padding means no padding. The output size of the convolutional layer shrinks depending on the input size & kernel size.
On the contrary, 'same' padding means using padding. When the stride is set as 1, the output size of the convolutional layer maintains as the input size by appending a certain number of '0-border' around the input data when calculating convolution.
Hope this intuitive description helps.
Based on the explanation here and following up on Tristan's answer, I usually use these quick functions for sanity checks.
# a function to help us stay clean
def getPaddings(pad_along_height,pad_along_width):
# if even.. easy..
if pad_along_height%2 == 0:
pad_top = pad_along_height / 2
pad_bottom = pad_top
# if odd
else:
pad_top = np.floor( pad_along_height / 2 )
pad_bottom = np.floor( pad_along_height / 2 ) +1
# check if width padding is odd or even
# if even.. easy..
if pad_along_width%2 == 0:
pad_left = pad_along_width / 2
pad_right= pad_left
# if odd
else:
pad_left = np.floor( pad_along_width / 2 )
pad_right = np.floor( pad_along_width / 2 ) +1
#
return pad_top,pad_bottom,pad_left,pad_right
# strides [image index, y, x, depth]
# padding 'SAME' or 'VALID'
# bottom and right sides always get the one additional padded pixel (if padding is odd)
def getOutputDim (inputWidth,inputHeight,filterWidth,filterHeight,strides,padding):
if padding == 'SAME':
out_height = np.ceil(float(inputHeight) / float(strides[1]))
out_width = np.ceil(float(inputWidth) / float(strides[2]))
#
pad_along_height = ((out_height - 1) * strides[1] + filterHeight - inputHeight)
pad_along_width = ((out_width - 1) * strides[2] + filterWidth - inputWidth)
#
# now get padding
pad_top,pad_bottom,pad_left,pad_right = getPaddings(pad_along_height,pad_along_width)
#
print 'output height', out_height
print 'output width' , out_width
print 'total pad along height' , pad_along_height
print 'total pad along width' , pad_along_width
print 'pad at top' , pad_top
print 'pad at bottom' ,pad_bottom
print 'pad at left' , pad_left
print 'pad at right' ,pad_right
elif padding == 'VALID':
out_height = np.ceil(float(inputHeight - filterHeight + 1) / float(strides[1]))
out_width = np.ceil(float(inputWidth - filterWidth + 1) / float(strides[2]))
#
print 'output height', out_height
print 'output width' , out_width
print 'no padding'
# use like so
getOutputDim (80,80,4,4,[1,1,1,1],'SAME')
Padding on/off. Determines the effective size of your input.
VALID: No padding. Convolution etc. ops are only performed at locations that are "valid", i.e. not too close to the borders of your tensor.
With a kernel of 3x3 and image of 10x10, you would be performing convolution on the 8x8 area inside the borders.
SAME: Padding is provided. Whenever your operation references a neighborhood (no matter how big), zero values are provided when that neighborhood extends outside the original tensor to allow that operation to work also on border values.
With a kernel of 3x3 and image of 10x10, you would be performing convolution on the full 10x10 area.
Here, W and H are width and height of input, F are filter dimensions, P is padding size (i.e., number of rows or columns to be padded)
For SAME padding:
For VALID padding:
Tensorflow 2.0 Compatible Answer: Detailed Explanations have been provided above, about "Valid" and "Same" Padding.
However, I will specify different Pooling Functions and their respective Commands in Tensorflow 2.x (>= 2.0), for the benefit of the community.
Functions in 1.x:
tf.nn.max_pool
tf.keras.layers.MaxPool2D
Average Pooling => None in tf.nn, tf.keras.layers.AveragePooling2D
Functions in 2.x:
tf.nn.max_pool if used in 2.x and tf.compat.v1.nn.max_pool_v2 or tf.compat.v2.nn.max_pool, if migrated from 1.x to 2.x.
tf.keras.layers.MaxPool2D if used in 2.x and
tf.compat.v1.keras.layers.MaxPool2D or tf.compat.v1.keras.layers.MaxPooling2D or tf.compat.v2.keras.layers.MaxPool2D or tf.compat.v2.keras.layers.MaxPooling2D, if migrated from 1.x to 2.x.
Average Pooling => tf.nn.avg_pool2d or tf.keras.layers.AveragePooling2D if used in TF 2.x and
tf.compat.v1.nn.avg_pool_v2 or tf.compat.v2.nn.avg_pool or tf.compat.v1.keras.layers.AveragePooling2D or tf.compat.v1.keras.layers.AvgPool2D or tf.compat.v2.keras.layers.AveragePooling2D or tf.compat.v2.keras.layers.AvgPool2D , if migrated from 1.x to 2.x.
For more information about Migration from Tensorflow 1.x to 2.x, please refer to this Migration Guide.
valid padding is no padding. same padding is padding in a way the output has the same size as input.
