X-axis tick marks in ggplot2

Question

Here I've got a data-frame consisted of 3264 normalized datapoint for 34 samples (3264 x 34). I have generated a ggplot using the following script:

cl21  <- geom_line(aes(y=CL021, col="CL"))
cl22  <- geom_line(aes(y=CL022, col="CL"))
cl24  <- geom_line(aes(y=CL024, col="CL"))
cl25  <- geom_line(aes(y=CL025, col="CL"))
cl27  <- geom_line(aes(y=CL027, col="CL"))
cl28  <- geom_line(aes(y=CL028, col="CL"))
cl30  <- geom_line(aes(y=CL030, col="CL"))
cl33  <- geom_line(aes(y=CL033, col="CL"))
cl35  <- geom_line(aes(y=CL035, col="CL"))
cl36  <- geom_line(aes(y=CL036, col="CL"))
cl37  <- geom_line(aes(y=CL037, col="CL"))
cl38  <- geom_line(aes(y=CL038, col="CL"))
cl39  <- geom_line(aes(y=CL039, col="CL"))
cl40  <- geom_line(aes(y=CL040, col="CL"))
ng172  <- geom_line(aes(y=NG172, col="NG"))
ng176  <- geom_line(aes(y=NG176, col="NG"))
ng178  <- geom_line(aes(y=NG178, col="NG"))
ng190  <- geom_line(aes(y=NG190, col="NG"))
ng191  <- geom_line(aes(y=NG191, col="NG"))
ng195  <- geom_line(aes(y=NG195, col="NG"))
ng218  <- geom_line(aes(y=NG218, col="NG"))
ng232  <- geom_line(aes(y=NG232, col="NG"))
ng244  <- geom_line(aes(y=NG244, col="NG"))
ng264  <- geom_line(aes(y=NG264, col="NG"))
ng285  <- geom_line(aes(y=NG285, col="NG"))
ng289  <- geom_line(aes(y=NG289, col="NG"))
ng299  <- geom_line(aes(y=NG299, col="NG"))
ng302  <- geom_line(aes(y=NG302, col="NG"))
ng306  <- geom_line(aes(y=NG306, col="NG"))
ng318  <- geom_line(aes(y=NG318, col="NG"))
ng320  <- geom_line(aes(y=NG320, col="NG"))
ng335  <- geom_line(aes(y=NG335, col="NG"))
ng338  <- geom_line(aes(y=NG338, col="NG"))
ng367  <- geom_line(aes(y=NG367, col="NG"))
gplot(normDF, aes(x=pos, y= value))+ cl21 +cl22  +cl24 +cl25 +cl27 +cl28 +cl30 +cl33 +cl35 +cl36 +cl37 +cl38 +cl39 +cl40 + ng172+ ng176+ ng178+ ng190+ ng191+ ng195+ ng218+ ng232+ ng244+ ng264+ ng285+ ng289+ ng299+ ng302+ ng306+ ng318+ ng320+ ng335+ ng338+ ng367  -> p

I tried to add customized tick marks along the x axis by defining breaks and labels:

p + xlab("FGD1 exons")+ ylab('Normalized Depth')+ scale_alpha_discrete(breaks= c("327","492","675","822","945","997","1098","1212","1380","1460","1620","1798","1968","2079","2542","2741","2936","3263"), labels= c("1","2","3","4","5","6","7","8","9","10","11","12","13","14","15","16","17","18"))+ theme(axis.text.x  = element_text(angle=90,vjust=0.5, size=15,hjust=1))

but ticks are not appearing on my plot! I was wondering if anyone here can advice me on this!

http://stackoverflow.com/questions/5963269/how-to-make-a-great-r-reproducible-example — shayaa, Jul 25 '16 at 19:29
why are you using `scale_alpha_discrete` to control the x axis? — bouncyball, Jul 25 '16 at 19:30
without `normDF` it is really hard to help you. Also, this example is probably not the simplest example you could come up with that reproduces your issue. Also, that is probably not the the easiest way to add a bunch of different lines to a plot (see the `group` argument) — Chris, Jul 25 '16 at 19:31

Mark Peterson · Answer 1 · 2016-07-26T12:09:01.283

I think you need to be using scale_x_continuous since your values are continuous.

Here is an example, including an MWE, showing how to do speed up your process a bit using melt from the reshape2 package to simplify things:

library(reshape2)
library(ggplot2)

df <-
  data.frame(
    x = 1:100
    , ya = 1:100
    , yb = seq(1,50, length.out = 100)
    , yc = seq(1,25, length.out = 100)
    , yd = seq(1,10, length.out = 100)
  )

melted <-
  melt(df, id.vars ="x")

melted$set <-
  ifelse(melted$variable %in% c("ya","yb")
         , "set A"
         , "set B")

head(melted)

ggplot(melted
       , aes(x, value
             , group = variable
             , col = set)) +
  geom_line() +
  scale_x_continuous(breaks = c(1, 20, 55, 80)
                     , labels = c(1,2,3,4))

I had missed that the column names contain the color information in your original set, you can do even automate the colors using substr:

df <-
  data.frame(
    x = 1:100
    , CLa = 1:100
    , CLb = seq(1,50, length.out = 100)
    , NGc = seq(1,25, length.out = 100)
    , NGd = seq(1,10, length.out = 100)
  )

melted <-
  melt(df, id.vars ="x")

melted$set <-
  substr(melted$variable, 1, 2)

head(melted)

ggplot(melted
       , aes(x, value
             , group = variable
             , col = set)) +
  geom_line() +
  scale_x_continuous(breaks = c(1, 20, 55, 80)
                     , labels = c(1,2,3,4))

Thank you Mark, This is really helpful! – RJF Jul 26 '16 at 15:25 — RJF, Jul 26 '16 at 15:25
