Angular 2 chatbox message from bottom to top

Question

I'm new using typescript, I'm working in an angular 2 project and I'm trying to do a chatbox where the new messages should be in the bottom and the old ones go one line up instead of this:

Also, I wanted them to don't leave the div and when it's full and instead of that, I wanted just to use the scroll to view the old messages...

This is what I have:

chatroom.component.html:

<h2>Player Notifications</h2>
  <p *ngFor="let m of playersChannel">{{m}}</p>

<h2>Chat history</h2>
<div class='chatbox'>
  <p *ngFor="let m of chatChannel">{{m}}</p>
</div>

chatroom.component.css:

.chatbox{
    width: 100%;
    height: 500px;
}

.chatbox p{
    text-align: bottom;

}

chatroom.component.ts:

import { Component, OnInit } from '@angular/core';

import {WebSocketService } from './websocket.service';

@Component({
    moduleId: module.id,
    selector: 'chat',
    styleUrls: [ 'chatroom.component.css' ],
    templateUrl: 'chatroom.component.html'
})
export class ChatroomComponent implements OnInit {
    playersChannel: string[] = [];
    chatChannel: string[] = [];

    constructor(private websocketService: WebSocketService){
    }

    ngOnInit() {
        this.websocketService
            .getChatMessages()
            .subscribe((m:any) => this.chatChannel.push(<string>m));
        this.websocketService
            .getPlayersMessages()
            .subscribe((m:any) => this.playersChannel.push(<string>m));
    }

}

websocket.service.ts:

import { Injectable } from '@angular/core';
import { Http, Response } from '@angular/http';

import {Observable} from 'rxjs/Observable';

import * as io from 'socket.io-client';

@Injectable()
export class WebSocketService {
    private socket: SocketIOClient.Socket;
    constructor() {
        if (!this.socket) {
            this.socket = io(`http://${window.location.hostname}:${window.location.port}`);
        }
    }

    sendChatMessage(message: any) {
        this.socket.emit('chat', this.getUserTime() + message);
    }

    getPlayersMessages(): Observable<any> {
        return this.createObservable('players');
    }

    getChatMessages(): Observable<any> {
        return this.createObservable('chat');
    }

     getUserTime(){
         let now = Date.now();
         let date = new Date(now);
         let hours = date.getHours();
         let mins = date.getMinutes();
         let secs = date.getSeconds();
        return hours + ":" + mins + ":" + secs + ": ";
    }

    private createObservable(channel: string): Observable<any> {
        return new Observable((observer:any) => {
            this.socket.on(channel, (data:any) => {
                observer.next(data);
            });
            return () => this.socket.disconnect();
        });

    }
}

server.websocket.ts:

const io = require('socket.io');

export class WebSocketServer {
    public io: any;




    public init = (server: any) => {
        this.io = io.listen(server);
        this.io.sockets.on('connection', (client: any) => {
            client.emit('players', Date.now() + ': Welcome to battleship');
            client.broadcast.emit('players', Date.now() + ': A new player has arrived');
            client.on('chat', (data) => this.io.emit('chat', data));

        });
    };
   public notifyAll = (channel: string, message: any) => {
        this.io.sockets.emit(channel, message);
    };


};

Answer 1

You can invert the order of the messages by simply sorting the array using something like added date, array index e.t.c or replacing push with unshift to add new messages to the beginning of the array.

See this for a simple order pipe: angular 2 sort and filter

Aligning the messages themselves to the bottom of screen or container (use css)

.chatbox{
  display:table;
}
.chatbox p{
  display:table-cell;
  vertical-align:bottom;
}

Answer 2

This should be a plain CSS solution. Set a fixed height to div.chatbox and add overflow-y: auto. As for the messages to stay at the bottom, you can add position: relative to div.chatbox and position: absolute; bottom: 0 to div.chatbox > p.

Like this:

.chatbox {
    height: 400px; /* reasonable estimate */
    overflow-y: auto; /* show scrollbar only when text overflows vertically */
    position: relative;
}

.chatbox > p {
    position: absolute;
    bottom: 0;
}

EDIT: To reverse the order, you can either create a custom pipe or use a prebuilt pipe from the ng-pipes module (Angular 2 ngFor - reverse order of output using the index)

Custom (courtesy of http://www.devsplanet.com/question/35703258):

@Pipe({
  name: 'reverse'
})
export class ReversePipe {
  transform(value) {
    return value.slice().reverse();
  }
}

Cheers!
