Autolayout not working for my nib when added subview

Question

I've created an xib and loaded the nib in my viewDidLayOutSubviews:

I then added the subview:

override func viewDidLayoutSubviews() {
    super.viewDidLayoutSubviews()

    if (myCustomView == nil) {

        myCustomView = Bundle.main.loadNibNamed("Help", owner: self, options: nil)?.first as? HelpView
        self.view.addSubview(myCustomView!)
    }
}

My constraints are all set up correctly in my xib (toggling between devices look okay), however when I launch the app on a different device the autolayout is not updated. How do I fix this? Thank you!

Edit:

Toggled for iPhone 7, but launching for iPhone 7 Plus

Toggled for iPhone 7 Plus, launching for iPhone 7 Plus

Can you share a screenshot of your xib and the device on which layouts are break. — ankit, Apr 25 '17 at 05:34
@GirishM hmm... that doesn't work.. I'm 100% sure my constraints are set up correctly. However I do realise that toggling the right device for the xib and launching to the same device works okay, but this doesn't solve the issue. — iamhx, Apr 25 '17 at 05:34
@ankit the trailing space is not sticked towards the right side which is causing the space. In iPad the space is even larger. — iamhx, Apr 25 '17 at 05:46
Let us [continue this discussion in chat](http://chat.stackoverflow.com/rooms/142564/discussion-between-ankit-and-iamhx). — ankit, Apr 25 '17 at 05:54

score 1 · Answer 1 · answered Apr 25 '17 at 05:54

1

Your constraints may be setup correctly in your nib, but you don't have any constraints when you call self.view.addSubview(myCustomView!), so the frame is just going to be whatever it is in the nib file. You need to constraint myCustomView to self.view. Give it equal width, center X, equal top and a fixed height (or use the intrinsic height) and it should be fine. Make sure you turn off translatesAutoresizingMaskIntoConstraints.

answered Apr 25 '17 at 05:54

Josh Homann

15,933
3
30
33

I've never added constraints programmatically, how do I achieve this? – iamhx Apr 25 '17 at 07:36
Use NSLayoutAnchor and set the constraints as outlined above. I have an example here: http://stackoverflow.com/questions/26180822/swift-adding-constraints-programmatically/40184218#40184218 – Josh Homann Apr 25 '17 at 17:11

score 0 · Answer 2 · answered Apr 25 '17 at 08:53

just add this line below

self.view.addSubview(myCustomView!)

myCustomView.translatesAutoresizingMaskIntoConstraints = false;
//Views to add constraints to
let views = Dictionary(dictionaryLiteral: ("myCustomView",myCustomView))

//Horizontal constraints
let horizontalConstraints = NSLayoutConstraint.constraintsWithVisualFormat("H:|[myCustomView]|", options: nil, metrics: nil, views: views)
self.view.addConstraints(horizontalConstraints)

//Vertical constraints
let verticalConstraints = NSLayoutConstraint.constraintsWithVisualFormat("V:|[myCustomView(SpecifyFixedHeight)]|", options: nil, metrics: nil, views: views)
self.view.addConstraints(verticalConstraints)
