I have run numpy.histogram() on a bunch of subsets of a larger datasets. I want to separate the calculations from the graphical output, so I would prefer not to call matplotlib.pyplot.hist() on the data itself.

In principle, both of these functions take the same inputs: the raw data itself, before binning. The numpy version just returns the nbin+1 bin edges and nbin frequencies, whereas the matplotlib version goes on to make the plot itself.

So is there an easy way to generate the histograms from the numpy.histogram() output itself, without redoing the calculations (and having to save the inputs)?

To be clear, the numpy.histogram() output is a list of nbin+1 bin edges of nbin bins; there is no matplotlib routine which takes those as input.

tdy
  • 36,675
  • 19
  • 86
  • 83
Andrew Jaffe
  • 26,554
  • 4
  • 50
  • 59
  • 3
    Have you tried [matplotlib bar](http://matplotlib.org/api/pyplot_api.html#matplotlib.pyplot.bar)? – obachtos May 16 '17 at 14:01

2 Answers2

23

You can plot the output of numpy.histogram using plt.bar.

import matplotlib.pyplot as plt
import numpy as np; np.random.seed(1)

a = np.random.rayleigh(scale=3,size=100)
bins = np.arange(10)

frq, edges = np.histogram(a, bins)

fig, ax = plt.subplots()
ax.bar(edges[:-1], frq, width=np.diff(edges), edgecolor="black", align="edge")

plt.show()

enter image description here

seriousdev
  • 7,519
  • 8
  • 45
  • 52
ImportanceOfBeingErnest
  • 321,279
  • 53
  • 665
  • 712
  • Ya know, maybe you just caught me at a bad time, and I'm down with work-arounds, but it seems weird that plt.hist cannot take in the output from np.histogram. What if you want to rescale the y-axis? np.histogram's output makes that easy, then you could plot it easy. What if you want histtype=u'step' ? now I have to figure that out in bar. All of these work-arounds would just be solved if these two things that should work together did... Anyways, +1 lol – kηives Apr 21 '18 at 19:47
  • @kηives `plt.hist` is a wrapper for `np.histogram`. Since `np.histogram` does not take the output of a previous call to `np.histogram`, the same is true for `plt.hist`. The question is hence: Do you want to plot something you would obtain via `np.histogram`? If yes, use `plt.hist`, if no (e.g. because you need to manipulate the data), don't use `plt.hist`. This makes sense, because if you manipulate the data, it's not a histogram any more, so the `hist` function is not responible any more. To plot a step function, use `plt.step(...)`. – ImportanceOfBeingErnest Apr 21 '18 at 23:04
  • how would you write such a figure to disk? – 3pitt Jun 17 '18 at 14:16
3

New in matplotlib 3.4.0

It's no longer necessary to manually reconstruct a bar chart, as there's now a built-in method:

Use the new plt.stairs method for the common case where you know the values and edges of the steps, for instance when plotting the output of np.histogram.

Note that stairs are plotted as lines by default, so use fill=True for a solid histogram:

a = np.random.RandomState(1).rayleigh(3, size=100)

counts, edges = np.histogram(a, bins=range(10))
plt.stairs(counts, edges, fill=True)

If you want a more conventional "bar" aesthetic, combine with plt.vlines:

plt.stairs(counts, edges, fill=True)
plt.vlines(edges, 0, counts.max(), colors='w')

If you don't need the counts and edges, just unpack np.histogram directly into plt.stairs:

plt.stairs(*np.histogram(a), fill=True)

And as usual, there is an ax.stairs counterpart:

fig, ax = plt.subplots()
ax.stairs(*np.histogram(a), fill=True)
tdy
  • 36,675
  • 19
  • 86
  • 83
  • 1
    Is it possible to have each of the bars with its own edgecolor? (I.e., which goes in between the bars, all the way down to the axis, as in the example in the other answer.) – Andrew Jaffe Jan 25 '22 at 21:20
  • @AndrewJaffe I added an option with [`vlines`](https://matplotlib.org/stable/api/_as_gen/matplotlib.pyplot.vlines.html), but that will [only look good with white](https://i.stack.imgur.com/dmwOp.png). If you want any other edgecolor (e.g., black), `bar` is probably still the way to go. – tdy Jan 26 '22 at 09:44
