Restrict width in ConstraintLayout by another view

Question

Is there a possibility (in ConstraintLayout) to let a view grow only as long as there is space for another view at his right?

The use case is to have a value and unit TextViews besides each other. The value TextView should be able to grow as long as there is space for the unit. If there is not enough space, the value should be cut.

I've tried it with chains and some other things but can't get it done. The value doesn't stop growing and then the unit is not visible anymore. Here's the current code:

<TextView
    android:id="@+id/value"
    android:layout_width="wrap_content"
    android:layout_height="wrap_content"
    android:layout_marginStart="8dp"
    android:lines="1"
    app:layout_constraintBaseline_toBaselineOf="@+id/unit"
    app:layout_constraintHorizontal_bias="0.0"
    app:layout_constraintHorizontal_chainStyle="packed"
    app:layout_constraintLeft_toLeftOf="parent"
    app:layout_constraintRight_toLeftOf="@id/unit"
    tools:text="12533939532" />

<TextView
    android:id="@+id/unit"
    android:layout_width="wrap_content"
    android:layout_height="wrap_content"
    android:layout_marginEnd="8dp"
    android:layout_marginStart="8dp"
    app:layout_constraintHorizontal_chainStyle="packed"
    app:layout_constraintLeft_toRightOf="@id/value"
    app:layout_constraintRight_toRightOf="parent"
    tools:text="km" />

Possible duplicate of [ConstraintLayout Chains and Text Ellipsis + Image on the Right](https://stackoverflow.com/questions/40410786/constraintlayout-chains-and-text-ellipsis-image-on-the-right) — tir38, Nov 28 '18 at 22:04

score 57 · Accepted Answer · edited Jan 14 '19 at 17:31

yes you can by using match_constraint (0dp) which equal to match_parent for other layout, so by using match_constraint we set weight for first view which will occupies all available space also add

app:layout_constraintWidth_default="wrap"

to apply default width behavior as wrap_content

here is code with change

<?xml version="1.0" encoding="utf-8"?>
<android.support.constraint.ConstraintLayout
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    xmlns:app="http://schemas.android.com/apk/res-auto">

        <TextView
            android:id="@+id/value"
            android:layout_width="0dp"
            app:layout_constraintWidth_default="wrap"
            android:layout_height="wrap_content"
            android:layout_marginStart="8dp"
            android:lines="1"
            app:layout_constraintBaseline_toBaselineOf="@+id/unit"
            app:layout_constraintHorizontal_bias="0.0"
            app:layout_constraintHorizontal_chainStyle="packed"
            app:layout_constraintLeft_toLeftOf="parent"
            app:layout_constraintRight_toLeftOf="@id/unit"
            tools:text="12533939532" />

        <TextView
            android:id="@+id/unit"
            android:layout_width="wrap_content"
            android:layout_height="wrap_content"
            android:layout_marginEnd="8dp"
            android:layout_marginStart="8dp"
            app:layout_constraintLeft_toRightOf="@id/value"
            app:layout_constraintRight_toRightOf="parent"
            tools:text="km" />

    </android.support.constraint.ConstraintLayout>

got some explanation from site

Better view dimension controls

The new available behaviors when a dimension is set to 0dp (MATCH_CONSTRAINT). As before, both endpoints (left/right or top/bottom) need to be connected to targets.

layout_constraintWidth_default = spread (default, similar to the previous behavior) layout_constraintWidth_default = wrap layout_constraintHeight_default = spread layout_constraintHeight_default = wrap

Wrap provides a significant new behaviour, with the widget resizing as if wrap_content was used, but limited by the connected constraints. A widget will thus not grow beyond the endpoints.

http://tools.android.com/recent/constraintlayoutbeta5isnowavailable

Didn't really get your explanation, but the code works, thanks! — mbo, Jun 07 '17 at 14:21
yeh, the main thing that layout_constraintWidth_default introduced in ConstraintLayout 1.0 to solve wrap_content problem which u was getting and there is no any official documentation for same. — Pavan, Jun 07 '17 at 14:28
This works, but only in a limited way. As long as the right-most View is lined up with `parent` (as in `app:layout_constraintRight_toRightOf="parent"`) this is fine. If it's up against another View, then everything gets over-written. Sigh. — SMBiggs, Aug 10 '19 at 05:31
