Spark – join first row matching conditions

Question

I'm looking for a way to join the two following Spark Datasets:

# city_visits:
person_id         city                timestamp
-----------------------------------------------
        1        Paris      2017-01-01 00:00:00
        1    Amsterdam      2017-01-03 00:00:00
        1     Brussels      2017-01-04 00:00:00
        1       London      2017-01-06 00:00:00
        2       Berlin      2017-01-01 00:00:00
        2     Brussels      2017-01-02 00:00:00
        2       Berlin      2017-01-06 00:00:00
        2      Hamburg      2017-01-07 00:00:00

# ice_cream_events:
person_id      flavour                timestamp
-----------------------------------------------
        1      Vanilla      2017-01-02 00:12:00
        1    Chocolate      2017-01-05 00:18:00
        2   Strawberry      2017-01-03 00:09:00
        2      Caramel      2017-01-05 00:15:00

So that for each row in city_visits, the row in ice_cream_events with same person_id and next timestamp value is joined, leading to this output:

person_id       city            timestamp  ic_flavour          ic_timestamp
---------------------------------------------------------------------------
        1      Paris  2017-01-01 00:00:00     Vanilla   2017-01-02 00:12:00
        1  Amsterdam  2017-01-03 00:00:00   Chocolate   2017-01-05 00:18:00
        1   Brussels  2017-01-04 00:00:00   Chocolate   2017-01-05 00:18:00
        1     London  2017-01-06 00:00:00        null                  null
        2     Berlin  2017-01-01 00:00:00  Strawberry   2017-01-03 00:09:00
        2   Brussels  2017-01-02 00:00:00  Strawberry   2017-01-03 00:09:00
        2     Berlin  2017-01-06 00:00:00        null                  null
        2    Hamburg  2017-01-07 00:00:00        null                  null

Closest solution I've had so far is the following, however this obviously joins every row in ice_cream_events that matches the conditions, not just the first one:

val cv = city_visits.orderBy("person_id", "timestamp")
val ic = ice_cream_events.orderBy("person_id", "timestamp")
val result = cv.join(ic, ic("person_id") === cv("person_id")
                         && ic("timestamp") > cv("timestamp"))

Is there a (preferably efficient) way to specify that the join is desired only on the first matching ice_cream_events row and not all of them?

Join like this and [filter later](https://stackoverflow.com/a/33878701/1560062) is probably the best you can do out of the box. If `ice_cream_events` is large, but small enough to fit in memory, you can create an udf, and search over optimized structure (binary tree, binary search over sorted list), but I wouldn't bother unless you experience significant performance degradation. — zero323, Sep 16 '17 at 13:00
@zero323 thanks, that's helpful – though I was hoping for a method similar to SQL's `JOIN LATERAL` which doesn't seem to have a Spark equivalent — Jivan, Sep 16 '17 at 14:22

shabbir hussain · Answer 1 · 2018-04-24T13:17:15.077

A request please include sc.parallalize code in questions. It makes it easier to answer.

val city_visits = sc.parallelize(Seq((1, "Paris", "2017-01-01 00:00:00"),(1, "Amsterdam", "2017-01-03 00:00:00"),(1, "Brussels", "2017-01-04 00:00:00"),(1, "London", "2017-01-06 00:00:00"),(2, "Berlin", "2017-01-01 00:00:00"),(2, "Brussels", "2017-01-02 00:00:00"),(2, "Berlin", "2017-01-06 00:00:00"),(2, "Hamburg", "2017-01-07 00:00:00"))).toDF("person_id", "city", "timestamp")
val ice_cream_events = sc.parallelize(Seq((1, "Vanilla", "2017-01-02 00:12:00"),(1, "Chocolate", "2017-01-05 00:18:00"),(2, "Strawberry", "2017-01-03 00:09:00"), (2, "Caramel", "2017-01-05 00:15:00"))).toDF("person_id", "flavour", "timestamp")

Solution 1:

As suggested in the comments you can first do the join which will create all possible row combinations.

val joinedRes = city_visits.as("C").
    join(ice_cream_events.as("I")
      , joinType = "LEFT_OUTER"
      , joinExprs =
        $"C.person_id" === $"I.person_id" &&
        $"C.timestamp"  <  $"I.timestamp"
    ).select($"C.person_id", $"C.city", $"C.timestamp", $"I.flavour".as("ic_flavour"), $"I.timestamp".as("ic_timestamp"))
joinedRes.orderBy($"person_id", $"timestamp").show

And then pick the first record using a groupBy clause.

import org.apache.spark.sql.functions._
val firstMatchRes =  joinedRes.
    groupBy($"person_id", $"city", $"timestamp").
    agg(first($"ic_flavour"), first($"ic_timestamp"))
firstMatchRes.orderBy($"person_id", $"timestamp").show

Now comes the trickier part. As I faced. The above join creates a ginormous upswell of data when doing the join operation. Spark has to wait till the join is finished to run the groupBy leading to memory issues.

Solution 2: (Probabilistic Approach)

Use stateful joins. For this, we maintain a state in every executor that will emit only one row per executor using local states within a bloom filter.

import org.apache.spark.sql.functions._
var bloomFilter      = breeze.util.BloomFilter.optimallySized[String](city_visits.count(), falsePositiveRate = 0.0000001)
val isFirstOfItsName = udf((uniqueKey: String, joinExprs:Boolean) => if (joinExprs) { // Only update bloom filter if all other expresions are evaluated to true. Dataframe evaluation of join clause order is not guranteed so we have to enforce this here.
    val res = bloomFilter.contains(uniqueKey)
    bloomFilter += uniqueKey
    !res
  } else false)

val joinedRes = city_visits.as("C").
    join(ice_cream_events.as("I")
      , joinType = "LEFT_OUTER"
      , joinExprs = isFirstOfItsName(
          concat($"C.person_id", $"C.city", $"C.timestamp"), // Unique key to identify first of its kind.
          $"C.person_id" === $"I.person_id" && $"C.timestamp"  <  $"I.timestamp")// All the other join conditions here.
    ).select($"C.person_id", $"C.city", $"C.timestamp", $"I.flavour".as("ic_flavour"), $"I.timestamp".as("ic_timestamp"))
joinedRes.orderBy($"person_id", $"timestamp").show

Finally to combine results from multiple executors.

val firstMatchRes =  joinedRes.
    groupBy($"person_id", $"city", $"timestamp").
    agg(first($"ic_flavour"), first($"ic_timestamp"))
