How to build trapezoid shape in xml android?

Question

I want to build this shape with bottom line and text inside it i'm confused little bit how to achieve this i tired some code but don't get required thing.

so far i have tried this code

shape.xml

<?xml version="1.0" encoding="UTF-8"?>
<layer-list xmlns:android="http://schemas.android.com/apk/res/android" >

    <!-- Colored rectangle-->
    <item>
        <shape android:shape="rectangle">
            <size
                android:width="100dp"
                android:height="40dp" />
            <solid android:color="#13a89e" />
        </shape>
    </item>


    <!-- This rectangle for the right side -->
    <!-- Their color should be the same as layout's background -->
    <item
        android:right="-100dp"
        android:left="100dp"
        android:top="-100dp"
        android:bottom="-100dp">
        <rotate
            android:fromDegrees="45">
            <shape android:shape="rectangle">
                <solid android:color="#ffffff" />
            </shape>
        </rotate>
    </item>

</layer-list>

it provide the following result.

i also need yellow line below this shape.

thanks for help.

Looks like you are almost there. Put another rectangle below the first one (with a low height). Make another tilted rectangle for the left side. Make both tilted rectangle a little smaller. And do something about the colors ... — kalabalik, Sep 30 '17 at 08:54
i have tried to put the same white shape on left but i don't know how to do this — Nouman Ch, Sep 30 '17 at 08:55
This post helped me a lot in creating a trapezium view https://arkapp.medium.com/trapezium-view-for-android-584799c7e849 — abdul rehman, Nov 29 '20 at 09:50

kalabalik · Accepted Answer · 2018-08-30T12:05:35.917

Here is your XML:

<?xml version="1.0" encoding="UTF-8"?>
<layer-list xmlns:android="http://schemas.android.com/apk/res/android" >

<!-- Colored rectangle-->
<item>
    <shape android:shape="rectangle">
        <padding android:top="35dp"/>
        <size android:width="200dp" android:height="40dp" />
        <solid android:color="#13a89e" />
    </shape>
</item>
<!-- Darker colored line-->
<item>
    <shape android:shape="line">
        <size android:width="100dp"/>
        <stroke android:width="4dp" android:color="#123456" />
    </shape>
</item>


<!-- This rectangle for the right side -->
<!-- Their color should be the same as layout's background -->
<item
    android:right="-200dp"
    android:left="200dp"
    android:top="-200dp"
    android:bottom="-200dp">
    <rotate android:fromDegrees="45">
        <shape android:shape="rectangle">
           <padding android:top="-35dp"/>
           <solid android:color="#ffffff" />
        </shape>
    </rotate>
</item>
<!-- This rectangle for the left side -->
<item
    android:right="200dp"
    android:left="-200dp"
    android:top="-200dp"
    android:bottom="-200dp">
    <rotate android:fromDegrees="-45">
        <shape android:shape="rectangle">
            <padding android:top="-35dp"/>
            <solid android:color="#ffffff" />
        </shape>
    </rotate>
</item>

And this is what it renders to:

Here is my TextView XML:

<?xml version="1.0" encoding="utf-8"?>
<android.support.constraint.ConstraintLayout xmlns:android="http://schemas.android.com/apk/res/android"
xmlns:app="http://schemas.android.com/apk/res-auto"
xmlns:tools="http://schemas.android.com/tools"
android:layout_width="match_parent"
android:layout_height="match_parent"
tools:context="io.kalabalik.tilted.MainActivity">

<TextView
    android:layout_width="wrap_content"
    android:layout_height="wrap_content"
    android:background="@drawable/box"
    android:text="Your Text!"
    android:textColor="#000000"
    android:gravity="center_horizontal|bottom"
    android:paddingBottom="10dp"
    app:layout_constraintBottom_toBottomOf="parent"
    app:layout_constraintLeft_toLeftOf="parent"
    app:layout_constraintRight_toRightOf="parent"
    app:layout_constraintTop_toTopOf="parent" />
</android.support.constraint.ConstraintLayout>

i used this with textview as backgorund its not showing anything. — Nouman Ch, Sep 30 '17 at 09:35
Let us [continue this discussion in chat](http://chat.stackoverflow.com/rooms/155652/discussion-between-nouman-ch-and-kalabalik). — Nouman Ch, Sep 30 '17 at 09:51

score 5 · Answer 2 · answered Sep 30 '17 at 09:02

5

I highly recommend create custom text view for do that it would be more flexible and under control. You need to create path object and with that object you will define your view corners. And if you want view as text you need to override onDraw(Canvas canvas) function you will call canvas.draw(path, paint) method. If you need not only for text field you should override any view group class but for view groups you should override onDispatchDraw function to do that.

You can create your shape like below example

    // you can define all points
    Point topLeft = new Point(0,0);
    Point topRight = new Point(getWidth(),0); // your view width
    //...

    //cover your corner points
    Path path = new Path();
    path.moveTo(topLeft.x, topLeft.y);
    path.lineTo(topRight.x, topRight.y);
    path.lineTo(bottomRight.x, bottomRight.y);
    path.lineTo(shapeBottomRight.x, shapeBottomRight.y);
    path.lineTo(shapeTop.x, shapeTop.y);
    path.lineTo(shapeBottomLeft.x, shapeBottomLeft.y);
    path.lineTo(bottomLeft.x, bottomLeft.y);
    path.lineTo(topLeft.x, topLeft.y);

    canvas.draw(path, paint);

answered Sep 30 '17 at 09:02

gokhan

627
1
6
16

sorry gokhan i don't have any idea working with custom views can you please help in how can i use this code. – Nouman Ch Sep 30 '17 at 09:06
@NoumanCh for to do that you can create custom view or view groups. For simplicity you can extend frame layout with default constructors. You need to override onDispatch function for draw your intended shape like my example. You can try path object for rectangle. define four corner and call canvas.draw(yourPath, paint) with paint object you can define your color border with etc. Finall go to xml layout and put your created layout thats all you will see your shape – gokhan Sep 30 '17 at 09:13
i need to put this above code in onDispatch method? – Nouman Ch Sep 30 '17 at 09:15
@NoumanCh If your view type of view group(FrameLayout, LinearLayout ..) you will use onDispatch or your view type of view(Textview, ImageView ...) you will use onDraw – gokhan Sep 30 '17 at 09:19
you dont need a custom `View` for that at all, what you need instead is a custom `Drawable` – pskink Sep 30 '17 at 09:32
@pskink would you like to add an answer – Shubham AgaRwal Feb 21 '19 at 09:11

score 2 · Answer 3 · answered Nov 29 '20 at 15:27

This post helped me a lot in creating a trapezium view https://arkapp.medium.com/trapezium-view-for-android-584799c7e849

<com.arkapp.trapeziumview.TrapeziumCustomView
        android:id="@+id/trapeziumCustomView"
        android:layout_width="match_parent"
        android:layout_height="350dp"
        android:layout_margin="16dp"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintStart_toStartOf="parent"
        app:layout_constraintTop_toTopOf="parent"
        app:shapeColor="@color/teal_200"
        app:edgeRadius="18"
        app:slopeLength="88"
        app:slopeType="bottomRight" />

With the help of this I was able to create a custom view with one edge as a slope

score 1 · Answer 4 · answered Aug 11 '20 at 10:58

<vector xmlns:android="http://schemas.android.com/apk/res/android"
xmlns:aapt="http://schemas.android.com/aapt"
android:width="28dp"
android:height="5dp"
android:viewportWidth="800"
android:viewportHeight="304">
<path

    android:pathData="M215,41.4c0,0.2 -22.9,58.3 -51,129.1 -28,70.8 -51,129.8 -51,131.1l0,2.4 296.1,-0c281.6,-0 296.1,-0.1 295.6,-1.8 -0.2,-0.9 -11.9,-31 -25.9,-66.7 -14.1,-35.8 -36.9,-94.1 -50.9,-129.8l-25.3,-64.7 -193.8,-0c-106.6,-0 -193.8,0.2 -193.8,0.4z">
    <aapt:attr name="android:fillColor">
        <gradient
            android:endX="50"
            android:endY="99"
            android:startX="50"
            android:startY="1"
            android:type="linear">
            <item
                android:color="#FFFFFF"
                android:offset="0.0" />
            <item
                android:color="#AAA8A8"
                android:offset="0.8" />
            <item
                android:color="#AAA8A8"
                android:offset="1.0" />
        </gradient>
    </aapt:attr>
</path>
