30

enter image description here

I have tried to hard code the row height in the table view cell. After running the program it looks like only one line. I suspect it is because of the height of the row of the table view.

Could you please tell me what went wrong in here?

Krunal
  • 77,632
  • 48
  • 245
  • 261
Agung Laksana
  • 781
  • 1
  • 12
  • 26
  • no issue seems with height, have you also set height from delegate method in code? If so remove that method. – Tushar Sharma Oct 02 '17 at 04:47
  • what is your label line number? it should be 0 and what about your constraint set ? would you share with that on the other hand did you set for dynamic constraint table view height? – Nazmul Hasan Oct 02 '17 at 05:00
  • 1
    You can check my answer hope this will help you https://stackoverflow.com/a/36574334/1776470 – iVarun Oct 02 '17 at 06:16

8 Answers8

53

In Xcode 9, tableview automatically create estimated cells based on Autolayout. Since you have not provide autolayout, that's why you are getting this.

You need to disable estimated and automatic cell size by selecting tableview and uncheck the two options:

enter image description here

Give value you want to Row height, and cell will be created accordingly.

Hope this can help.

idmean
  • 14,540
  • 9
  • 54
  • 83
Irfan
  • 5,070
  • 1
  • 28
  • 32
9

Add this code in your UITableViewDelegate

func tableView(_ tableView: UITableView, heightForRowAt indexPath: IndexPath) -> CGFloat {
    return 100
}
Leo
  • 336
  • 3
  • 6
  • 5
    No, do not do this. If all rows have the same height it is better to simply set the table view's `rowHeight` property once in `viewDidLoad`. Only implement this delegate method if different rows have different heights. – rmaddy Oct 02 '17 at 04:44
  • @rmaddy As per apple doc, delegate have better performance then property. – dahiya_boy Oct 02 '17 at 06:03
  • 5
    @dahiya_boy You misread the documentation. The documentation for `UITableView rowHeight` and `UITableViewDelegate heightForRowAt` clearly state that the delegate method is a performance issue. It is far more efficient to set the `rowHeight` property than use the delegate method assuming all rows have the same height. – rmaddy Oct 02 '17 at 06:06
3

Ensure following steps to make, auto dimension effective for cell/row height layout. (Here is sample code for UILabel and how to set content specific height for table cell.)

  • Assign and implement dataSource and delegate
  • Assign UITableViewAutomaticDimension to rowHeight & estimatedRowHeight
  • Implement delegate/dataSource methods (i.e. heightForRowAt and return a value UITableViewAutomaticDimension to it)

-

@IBOutlet weak var table: UITableView!

override func viewDidLoad() {
    super.viewDidLoad()

    // Don't forget to set dataSource and delegate for table
    table.dataSource = self
    table.delegate = self

    // Set automatic dimensions for row height
    // Swift 4.2 onwards
    table.rowHeight = UITableView.automaticDimension
    table.estimatedRowHeight = UITableView.automaticDimension


    // Swift 4.1 and below
    table.rowHeight = UITableViewAutomaticDimension
    table.estimatedRowHeight = UITableViewAutomaticDimension

}



// UITableViewAutomaticDimension calculates height of label contents/text
func tableView(_ tableView: UITableView, heightForRowAt indexPath: IndexPath) -> CGFloat {
    // Swift 4.2 onwards
    return UITableView.automaticDimension

    // Swift 4.1 and below
    return UITableViewAutomaticDimension
}

For label instance in UITableviewCell

  • Set number of lines = 0 (& line break mode = truncate tail)
  • Set all constraints (top, bottom, right left) with respect to its superview/ cell container.
  • Optional: Set minimum height for label, if you want minimum vertical area covered by label, even if there is no data.

enter image description here

Krunal
  • 77,632
  • 48
  • 245
  • 261
3

Set row height as well as estimated row height as Automatic in viewDidLoad() as

table.rowHeight = UITableViewAutomaticDimension
table.estimatedRowHeight = UITableViewAutomaticDimension

In heightForRowAt: set height as UITableViewAutomaticDimension as

func tableView(_ tableView: UITableView, heightForRowAt indexPath: IndexPath) -> CGFloat {
    return UITableViewAutomaticDimension
}

Note: Set number of lines of label long restaurant name as 0.

luckyShubhra
  • 2,731
  • 1
  • 12
  • 19
3

You can manually do it in your tableviewdelegate:

override func tableView(_ tableView: UITableView, heightForRowAt indexPath: IndexPath) -> CGFloat {
    return 100
}
gannonbarnett
  • 1,638
  • 1
  • 16
  • 28
1
  1. Set number of lines to 0
  2. Set
   yourTableView.rowHeight = UITableView.automaticDimension and
   yourTableView.estimatedRowHeight =  UITableView.automaticDimension

  1. return UITableView.automaticDimension in tableView(_:heightForRowAt:) delegate method

  2. Set all constraints . Bottom constraint is important to increase table view cell height .

Your all set to go

ajmccall
  • 2,024
  • 23
  • 42
Abhishek B
  • 157
  • 8
0

If you want the cells to occupy space according to its content, you need to return UITableViewAutomaticDimension in the table view delegate methods heightForRowAt: and estimatedHeightForRowAt:

Mansi
  • 628
  • 1
  • 8
  • 18
  • you can also use: yourTable.rowHeight = UITableViewAutomaticDimension yourTable.estimatedRowHeight = UITableViewAutomaticDimension – Mansi Oct 02 '17 at 14:33
0

Following this guide which worked for me, you have to add a bunch of constraints and then the rowheight is calculated automatically.

In short, what I did: (adding and modifying constraints are the two rightmost buttons bottom right of the storyboard view)I at first selected all views in the prototype cell, deleted all constraints (there is a nice option on the rightmost button), then added all missing constraints (another nice option there) and last I chose the second button from the right and clicked all the red lines. You can do this while having all views selected at the same time. And then it worked.

findusl
  • 2,454
  • 8
  • 32
  • 51
