Very simple question: I love writing R notebooks/markdowns, and with something like highlight: tango I can give background color to codes when I knit my notebook to pdfs.

However, I don't know how to give colored backgrounds or colored fonts to printed outputs in R. For example, suppose I have the following chunk.

```{r, echo = FALSE}
writeLines("Help")
```

I'd like to see the word Help to be highlighted, say in red font with gray background. How can I achieve this?

Many thanks in advance.

Kim
  • 4,080
  • 2
  • 30
  • 51

3 Answers3

11

with kableExtra, you can format your texts in R using text_spec

---
output: pdf_document
---

```{r}
library(kableExtra)
options(knitr.table.format = "latex")
```

`r text_spec("Help", color = "red")`

`r text_spec("Help Help", background = "#D05A6E", color = "white", bold = T)`

`r text_spec("Hello", font_size = 20)`

`r text_spec("World", angle = 180)`

You get enter image description here

Same goes for HTML enter image description here

See more in the Cell/Text Specification of the package vignette.

Community
  • 1
  • 1
Hao
  • 7,476
  • 1
  • 38
  • 59
6

For PDF output, below are some latex commands to get colored text and shading. (For additional shading options, see this answer at the Tex Stack Exchange site.) However, I'm not sure how to get the output from writeLines shaded. Enclosing the code chunk in a \shaded environment causes an error. Hopefully someone will come along with a solution that works with code chunk output.

---
output: pdf_document
header-includes:
  - \usepackage{xcolor}
  - \usepackage{framed}
---

```{r setup, include=FALSE}
knitr::opts_chunk$set(echo = FALSE)
```

\colorlet{shadecolor}{gray!10}

\color{red}

```{r}
writeLines("help")
```

\begin{shaded}

Red text with a gray background.

\end{shaded}

Red text.

\color{black}

Black text.

\colorlet{shadecolor}{red!10}

\begin{shaded}

Black text with a red background.

\end{shaded}

\colorlet{shadecolor}{red!90}

\begin{shaded}

Black text with a darker red background.

\end{shaded}

And here's the resulting PDF document:

enter image description here

eipi10
  • 91,525
  • 24
  • 209
  • 285
  • Ah, just one additional question---is there a way to put a background to the printed "## help" part as well? The technique doesn't seem to work when you move the ```\begin{shaded}``` right below ```writeLines("help")``` to above it. – Kim Nov 15 '17 at 06:37
  • Yes, I noted in my answer that I'm not sure how to print chunk output with a background, because enclosing the code chunk in a `\shaded` environment causes an error. I'm working on this and will come back with a solution if I find one. – eipi10 Nov 15 '17 at 06:42
  • Ooh, I missed that in my excitement. Excuse me. But thanks again for the current solution---I can work the other way around and shade texts while leaving prints, because all I wished to do was clearly show blocks of code prints and blocks of texts apart. – Kim Nov 15 '17 at 06:44
1

For a way within R, my huxtable package lets you set background and text colour for tables. I don't know of any within-R package that does it for plain text (maybe crayon?)

library(huxtable)
ht <- hux(c("Red", "Blue"), c("White bg", "Black bg"))
text_color(ht)[, 1] <- c("red", "blue")
background_color(ht)[, 2] <- c("white", "black")
to_latex(ht) # or just print within a rmarkdown document
