CSS Flexbox float elements

Question

I'm trying to float two elements at the right of a "figure" element using flex but it end up floating just div1 at the right of figure and div2 is moved bellow, if I make div1 and div2 narrow enough, they are floated inline at the right of figure.

This is the CSS:

.container {
  display: flex;
  flex-wrap: wrap;
  align-items: flex-start;
}

Desired Result:

Actual Result:

Answer 1

How it works?

First, you make a flex-container (flexc in this case) and apply the display:flex property on it which aligns the elements by default in row alignment. If you want an element to preserve its dimensions set it to flex:0 0 auto; else you can make use of flex:1; which shrinks or grows as the browser is resized.

Then to align the contents in column (div1 and div2) you can just wrap then in a different container and since div isn't an inline container, and the flex property doesn't have any effect on any other than the direct children of the flex parent, they are aligned in seperate lines.

.flexc {
  display: flex;
  justify-content: flex-start;
}

#fig {
  flex: 0 0 auto;
  width: 200px;
  height: 200px;
  background: gray;
  text-align: center;
  color: white;
  margin: 10px;
  border: 2px solid black;
}

#d1,
#d2 {
  width: 200px;
  height: 50px;
  background: purple;
  text-align: center;
  color: white;
  margin: 10px;
  border: 2px solid black;
}

<div class="flexc">
  <div id="fig">Figure</div>
  <div class="col">
    <div id="d1">div1</div>
    <div id="d2">div2</div>
  </div>
</div>

Without altering the html:

.flexc {
  display: flex;
  flex-direction:column;
  position:relative;
}

#fig {
  flex: 0 0 auto;
  width: 200px;
  height: 200px;
  background: gray;
  text-align: center;
  color: white;
  margin: 10px;
  border: 2px solid black;
}

#d1,
#d2 {
  position:absolute;
  left:250px;
  width: 200px;
  height: 50px;
  background: purple;
  text-align: center;
  color: white;
  margin: 10px;
  border: 2px solid black;
}
#d2{
top:70px;
}

<div class="flexc">
  <div id="fig">Figure</div>
    <div id="d1">div1</div>
    <div id="d2">div2</div>
</div>

Answer 2

Not sure what your HTML looks like, but display: flex is best used on the container wrapping all the elements you want aligned. Imagine it to be the largest box that you put smaller boxes inside.

Codepen example demonstrating this: https://codepen.io/corviday/pen/VyYdar

Following this hierarchy with .container as your largest box, since you want two columns, you can divide it further into two smaller boxes (.left in red and .right in blue in this case).

From there you would need to group div1/div2 together to float the way you'd like, and would be the items that fill the box .right.

Answer 3

You can use Bootstrap to resolve or put div1 and div2 in one div main to drop div main

Bootstrap exemple

<div class='container'>
  <div class="col-md-12">
    <div class="col-md-6">
      1 text
    </div>
    <div class="col-md-6">
        <div class="col-md-6">
          2 text
        </div>
        <div class="col-md-6">
          3 text
        </div>
    </div>
  </div>
</div>

Answer 4

I think the best layout engine to use for your use case is hinted at in your description of the problem: Floats.

Here is a solution that doesn't require you to alter your html.

<div class="container">
  <div class="medium-box">figure</div>
  <div class="small-box">div 1</div>
  <div class="small-box">div 2</div>
</div>

.container{
  width: 500px;
}

.medium-box {
  height: 200px;
  width: 200px;
  margin: 10px;
  background: grey;
  float:left
}

.small-box {
  float:left;
  height: 30px;
  width: 200px;
  background: blue;
  margin: 10px;
}

https://codepen.io/stacyvlasits/pen/aVPZbY
