PANIC: Cannot find AVD system path. Please define ANDROID_SDK_ROOT (in windows 10)

Question

While running an app on the virtual device (AVD) created on Android studio (in Windows 10), I am getting an error and panic.

Emulator: PANIC: Cannot find AVD system path. Please define ANDROID_SDK_ROOT Emulator: Process finished with exit code 1

While I have already defined my ANDROID_SDK_ROOT in the environment variables.

Can anyone please tell me how to resolve this problem?

Was having the same issue. This [post](https://stackoverflow.com/questions/39645178/panic-broken-avd-system-path-check-your-android-sdk-root-value/44386974#44386974) helped to fix this issue. Refer to the answer given by [Oleg Cherr](https://stackoverflow.com/users/4899346/oleg-cherr) titled "Incomplete/corrupted SDK stucture" — Temp September, Mar 21 '18 at 11:45
I faced same issue yesterday and i solved it ..now today it occurs as same as ..stuck yaar:( — Ajay Mistry, May 30 '18 at 11:35
Possible duplicate of [How to resolve 'Emulator: PANIC: Cannot find AVD system path. Please define ANDROID\_SDK\_ROOT'](https://stackoverflow.com/questions/47329799/how-to-resolve-emulator-panic-cannot-find-avd-system-path-please-define-andr) — nitarshs, Jun 17 '19 at 16:55
This fixed it for me https://betamode.de/2018/11/16/android-emulator-panic-broken-avd-system-path-check-your-android_sdk_root-value/ — Günter Zöchbauer, Apr 01 '20 at 06:12

score 36 · Answer 1 · edited Dec 16 '19 at 08:51

36

Open Android Studio and under the Tools you will find the AVD manager. Click on it and ensure that you have a valid virtual device with the SDK downloaded (click "download" in the Actions column if shown). Then ensure that the correct virtual device is selected on the toolbar.

edited Dec 16 '19 at 08:51

Aniruddh Parihar

3,072
3
21
39

answered Oct 01 '19 at 17:40

Nuno Fonseca

377
3
2

2

This was my problem, fresh install of Android Studio on a Mac but it didn't install AVD stuff at all. After that I was able to launch a simulator and run a sample app. – Kendall Helmstetter Gelner Feb 20 '20 at 04:40

score 32 · Answer 2 · answered Aug 01 '18 at 14:03

32

define ANDROID_SDK_ROOT as environment variable where your SDK is residing, default path would be "C:\Program Files (x86)\Android\android-sdk" and restart computer to take effect.

answered Aug 01 '18 at 14:03

niketan

812
11
13

5

restart was not necessary in my case ... win 10 pro – Stefan Michev Dec 28 '19 at 10:28
1

I have to add till the `bin` folder as ANDROID_SDK_ROOT – user2720864 Mar 04 '20 at 15:17

score 15 · Answer 3 · answered Feb 08 '19 at 09:36

15

Go to Control Panel>>System and Security>>System>>Advance system settings>>Environment Variables then set variable value of ANDROID_HOME set it like this "C:\Users\username\AppData\Local\Android\sdk" set username as your pc name, then restart your android studio. after that you can create your AVD again than the error will gone than it will start the virtual device.

answered Feb 08 '19 at 09:36

Cevin Ways

984
11
13

2

The OP asked for ANDROID_SDK_ROOT not ANDROID_HOME – jsnfwlr May 24 '19 at 01:23
4

I had to define both ANDROID_SDK_ROOT and ANDROID_HOME to "C:\Users\username\AppData\Local\Android\sdk". – andreibosco Aug 08 '19 at 00:09
1

I think this happened to me because I was following a tutorial and installed the SDK from the command line, then it got installed in a different location when installed Android Studio. So, this solution worked for me. – Alex Russell Nov 22 '19 at 05:43
1

@jsnfwlr I set ANDROID_HOME "...Local\Android\Sdk and add Path ";%ANDROID_HOME%\platform-tools" – Minato Mar 12 '20 at 07:21

score 10 · Answer 4 · edited Jun 20 '20 at 09:12

My problem was solved by creating a Windows user without an accent or special characters and reinstalling android studio on that user. Another change is to change the environment variables:

Left Click in My Computer > Advanced System Settings> Advanced > Environment Variables

ANDROID_HOME = c:\my_sdk_path

ANDROID_SDK_ROOT = c:\my_sdk_path

JAVA_HOME = c:\program files\Java\yourJavaPath

the default path of SDK is c:\users\youruser\AppData\LocalAndroid\sdk

Add in Path Variable the values:

%ANDROID_HOME%\platform-tools

%ANDROID_HOME%\tools

After changes, restart windows and try again!

score 6 · Answer 5 · answered Dec 19 '19 at 16:33

For those coming here with a Mac:

I had the same issue and the problem was, I created an emulator with API Level 29 but removed that SDK and installed 28 instead. The emulator that was not able to be launched anymore.

Therefore check the AVD Manager if your emulator really can be launched.

score 3 · Answer 6 · answered Jan 24 '20 at 14:19

Check C:\Users\User path. Change User directory name (may be something different name) from your alphabet to English alphabet. Warning: it is dangerous operation, learn it before changing. Android Studio can not access to AVD throw users\Your alphabet name\.android.

score 2 · Answer 7 · answered Aug 17 '19 at 15:19

2

create environment variable like in the screenshot and make sure to replace with your sdk path in my case it was C:\Users\zeesh\AppData\Local\Android\sdk replace zeesh with your username and make sure to restart android studio to take effect.

answered Aug 17 '19 at 15:19

Zeeshan Mehdi

1,241
1
17
18

score 2 · Answer 8 · answered Sep 04 '19 at 18:33

2

Android Studio Picture

Make sure you have an Android Virtual Device selected to output the app to. In the picture I put on this post you can see I selected the Android Virtual Device "Nexus 5" as the output device. Doing this removed the error for me.

answered Sep 04 '19 at 18:33

Kevin Barreiro

39
6

score 1 · Answer 9 · answered Feb 13 '20 at 05:29

Try to use the argument: -sysdir <Your_SDK_DIR> and then check whether the error message displayed.

See also: https://android.googlesource.com/platform/external/qemu/+/1a15692cded92d66dea1a51389a3c4b9e3b3631a/android/emulator/main-emulator.cpp

Check out these clip you will find out the reason:

// Sanity checks.
if (avdName) {
    if (!isCpuArchSupportedByRanchu(avdArch)) {
        APANIC("CPU Architecture '%s' is not supported by the QEMU2 emulator, (the classic engine is deprecated!)",
               avdArch);
    }
    std::string systemPath = getAvdSystemPath(avdName, sysDir);
    if (systemPath.empty()) {
        const char* env = getenv("ANDROID_SDK_ROOT");
        if (!env || !env[0]) {
            APANIC("Cannot find AVD system path. Please define "
                   "ANDROID_SDK_ROOT\n");
        } else {
            APANIC("Broken AVD system path. Check your ANDROID_SDK_ROOT "
                   "value [%s]!\n",
                   env);
        }
    }
}

Then if you see emulator: ERROR: can't find SDK installation directory, please check this solution. Android emulator errors with "emulator: ERROR: can't find SDK installation directory"

score 1 · Answer 10 · answered Oct 08 '21 at 10:45

If you experience this error when upgrading from one version of Android Studio to another and you have non-english characters in your home directory, the following could help.

Even though the error message are pointing at ANDROID_SDK_ROOT in my case non-english characters in the user folder which holds the avd-folder caused the problem (C:\Users\Björn\.android\avd).

In this case a simple solution is to create a new avd-folder outside of the user folder and define an environment variable named ANDROID_AVD_HOME which points to the new folder (for instance C:\andoid\avd) and restart Android Studio.

score 0 · Answer 11 · answered Feb 16 '20 at 06:22

0

In Korean version of Windows 10, this problem happened because my Windows user name was in Korean not in English. After the user name was made again in English, the problem was cleared.

answered Feb 16 '20 at 06:22

bigbell

19
2

score -2 · Answer 12 · answered Aug 02 '20 at 19:56

I had the same problem when I was trying to move the android studio to another Drive as it was taking a lot of space in my C(Windows drive) Drive, Here's what fixed my problem:-

Copy the C:\Users\ #YourUserName\ .android folder to another drive,
Go to start environment variable make a new variable named ANDROID_SDK_HOME and add the path of the new location like mine is F:\Android AVD( don't add .android to it )
Then add ANDROID_SDK_HOME to the existing Path variable.
Open android studio, go to configure --> AVD manager and you'll see that you've successfully moved to a new location.

score -3 · Answer 13 · answered Dec 21 '18 at 04:17

Find the ANDROID_HOME path values from environment variable. In my case it is like C:\Users\RuwanPr\AppData\Local\Android\Sdk. If this value not found please add ANDROID_HOME value as your sdk path. (To go to environment variable right click on my computer -> Properties -> Advance System Settings -> Environment Variable ) Then open cmd on windows and go to sdk folder and then go to tools folder Type emulator -list-avds in comd. It will shows avd name list. Then type emulator -avd avd-name. Ex - think avd-name shows as J2_Api_22 emulator -avd J2_Api_22

score -3 · Answer 14 · edited Jun 25 '20 at 13:01

-3

Update Android emulator alone from SDK tool

edited Jun 25 '20 at 13:01

codetiger

2,650
20
37

answered Jun 25 '20 at 07:17

Pradeep Kumar

1
1
