EditText height changes according to the text size

Question

If I change the textsize in editext, the height of edittext changes accordingly. I want the size of edittext to be same and I want a smaller sized hint or text to be in it. What should I do? Following is the code and I am also posting the screenshot of this layout :

  <RelativeLayout
            android:id="@+id/normal"
            android:layout_width="match_parent"
            android:layout_height="wrap_content"
            android:background="#4594e4"
            android:orientation="horizontal">

            <ImageView
                android:id="@+id/set"
                android:layout_width="wrap_content"
                android:layout_height="75dp"
                android:layout_marginTop="05dp"
                android:padding="5dp"
                android:src="@drawable/bari" />

            <EditText
                android:id="@+id/etOrigin"
                android:layout_width="match_parent"
                android:layout_height="wrap_content"
                android:layout_marginRight="@dimen/_35sdp"
                android:layout_marginTop="@dimen/_10sdp"
                android:layout_toEndOf="@+id/set"
                android:layout_toRightOf="@+id/set"
                android:background="#5fa7f1"
                android:inputType="textPersonName"
                android:text="My Location"
                android:textColor="#434343"
                android:textIsSelectable="true" />

            <EditText
                android:id="@+id/etDestination"
                android:layout_width="match_parent"
                android:layout_height="wrap_content"
                android:layout_below="@+id/etOrigin"
                android:layout_marginRight="@dimen/_35sdp"
                android:layout_marginTop="@dimen/_5sdp"
                android:layout_toEndOf="@+id/set"
                android:layout_toRightOf="@+id/set"
                android:background="#5fa7f1"
                android:inputType="textPersonName"
                android:onClick="wow"
                android:text="Where to go ?"
                android:textColor="#fff"
                android:textColorHint="#fff" />

            <ImageView
                android:id="@+id/swipe"
                android:layout_width="30dp"
                android:layout_height="27dp"
                android:layout_alignParentEnd="true"
                android:layout_centerVertical="true"
                android:layout_marginRight="@dimen/_5sdp"
                android:background="@drawable/flip" />

        </RelativeLayout>

Screenshot of the layout before changing:

Screenshot of the layout before changing

Screenshot of layout after changing textsize:

Screenshot of layout after changing textsize

Possible duplicate of [How to make Edittext size stay put? Android](https://stackoverflow.com/questions/2522369/how-to-make-edittext-size-stay-put-android) — Rohan Kandwal, Feb 22 '18 at 08:34

score 4 · Answer 1 · answered Feb 22 '18 at 07:43

Try using android:minHeight and android:maxHeight attributes :

                            <EditText
                            android:id="@+id/etUserName"
                            android:layout_width="match_parent"
                            android:layout_height="wrap_content"
                            android:hint="@string/hint_username"
                            android:imeOptions="actionNext"
                            android:inputType="textPersonName"
                            android:maxLines="1"
                            android:gravity="center_vertical"
                            android:minHeight="?actionBarSize"
                            android:maxHeight="?actionBarSize"
                            android:textColor="@color/textPrimary"
                            android:textSize="12sp"/>

                            <EditText
                            android:id="@+id/etUserEmail"
                            android:layout_width="match_parent"
                            android:layout_height="wrap_content"
                            android:hint="@string/hint_username"
                            android:imeOptions="actionNext"
                            android:inputType="textEmailAddress"
                            android:maxLines="1"
                            android:gravity="center_vertical"
                            android:minHeight="?actionBarSize"
                            android:maxHeight="?actionBarSize"
                            android:textColor="@color/textPrimary"
                            android:textSize="14sp"/>

Wc mate! Thanks for your appreciation as well – Deep Patel Feb 23 '18 at 04:29 — Deep Patel, Feb 23 '18 at 04:29
Thanks! `minHeight` is enough. – CoolMind Nov 23 '18 at 10:23 — CoolMind, Nov 23 '18 at 10:23

Abhinav Gupta · Accepted Answer · 2018-06-01T07:29:55.257

3

Use padding for this :-

         <EditText
            android:id="@+id/etOrigin"
            android:layout_width="match_parent"
            android:layout_height="wrap_content"
            android:padding="12dp"
            android:layout_marginRight="@dimen/_35sdp"
            android:layout_marginTop="@dimen/_10sdp"
            android:layout_toEndOf="@+id/set"
            android:layout_toRightOf="@+id/set"
            android:background="#5fa7f1"
            android:inputType="textPersonName"
            android:text="My Location"
            android:textColor="#434343"
            android:textIsSelectable="true" />

edited Jun 01 '18 at 07:29

answered Feb 22 '18 at 07:42

Abhinav Gupta

2,225
1
14
30

How does it work? I think, it simply adds padding, but doesn't set a height for any font size. – CoolMind Nov 23 '18 at 09:19
@CoolMind it was handle by android – Abhinav Gupta Nov 23 '18 at 10:00
@AbhinavGupta, it only adds paddings. It doesn't set a height. So, if we change a text size, the EditText's height will change. – CoolMind Nov 23 '18 at 10:05
@CoolMind yes it will change because default textSize have 16sp if you increase more than 16sp height will change according to textsize .... – Abhinav Gupta Nov 23 '18 at 10:13

score 2 · Answer 3 · edited Feb 22 '18 at 07:47

2

Give fix height to the layout android:layout_height="75dp"

            <EditText
            android:id="@+id/etOrigin"
            android:layout_width="match_parent"
            android:layout_height="75dp"
            android:layout_marginRight="@dimen/_35sdp"
            android:layout_marginTop="@dimen/_10sdp"
            android:layout_toEndOf="@+id/set"
            android:layout_toRightOf="@+id/set"
            android:background="#5fa7f1"
            android:inputType="textPersonName"
            android:text="My Location"
            android:textColor="#434343"
            android:textIsSelectable="true"/>

edited Feb 22 '18 at 07:47

Hemant Parmar

3,924
7
25
49

answered Feb 22 '18 at 07:36

Ankita Chavan

64
7

Thats what i don't want to do actually. I want it to be adjustable on all devices – Kylo Ren Feb 22 '18 at 07:53
1

Then write style for it and give fix different height for every screen size. like for hdpi android:layout_height="75dp" for mdpi android:layout_height="60dp" xhdpi android:layout_height="90dp" – Ankita Chavan Feb 22 '18 at 08:40

score 2 · Answer 4 · answered Feb 22 '18 at 07:49

Here, try this third party library. Your TextView height would be fixed but your textView size will be adjusted

dependencies {
    compile 'me.grantland:autofittextview:0.2.+'
}

Enable any View extending TextView in code:

AutofitHelper.create(textView);

Enable any View extending TextView in XML:

<me.grantland.widget.AutofitLayout
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    >
    <Button
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:singleLine="true"
        />
</me.grantland.widget.AutofitLayout>

Use the built in Widget in code or XML:

<RootElement
    xmlns:autofit="http://schemas.android.com/apk/res-auto"
    ...
<me.grantland.widget.AutofitTextView
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    android:singleLine="true"
    android:maxLines="2"
    android:textSize="40sp"
    autofit:minTextSize="16sp"
    />

For more information, visit below link:

https://github.com/grantland/android-autofittextview

score 1 · Answer 5 · edited Aug 29 '18 at 15:22

1

You can explicitly set the height and size of your EditText view as well as the text in it.

To set the heigh of the EditText simply use :

android:layout_height="<height_you_want>dp"

And to set height of the text in your EditText view :

android:textSize="<height_you_want>sp"

And you can simultaneously view the changes in the preview tab of AndroidStudio.

edited Aug 29 '18 at 15:22

rf43

4,385
3
23
28

answered Feb 22 '18 at 07:44

zeekhuge

1,594
1
13
23

I know this but in that case if the device is of higher resolution or of bigger screensize, the layout height will remain same which i want to change according to the screensize. – Kylo Ren Feb 22 '18 at 09:33
1

In that case, you might wanna see [this](https://stackoverflow.com/questions/2025282/what-is-the-difference-between-px-dip-dp-and-sp). Just as a summary, the unit `dp` is `density independent pixel` and it would scale perfectly on screens with different pixel-densities, which mostly represent the size (resolution) of the screen – zeekhuge Feb 22 '18 at 09:44
1

And you can create different layouts for `mdpi`, `ldpi`, `hdpi`, `xhdpi` and `xxhdpi` if that is a big concern. Take a look [here](https://stackoverflow.com/questions/28507609/image-resolution-for-mdpi-hdpi-xhdpi-and-xxhdpi) – zeekhuge Feb 22 '18 at 09:46
I knew about mdpi and hdpi etc but didnt knew that dp is density independent. Thank you so much – Kylo Ren Feb 22 '18 at 12:25

score 0 · Answer 6 · answered Jun 30 '21 at 09:49

0

One Solution : include these two lines in your XML file

android:maxLines="1" android:singleLine="true"

answered Jun 30 '21 at 09:49

Akash Jaiswal

31
1
2

score 0 · Answer 7 · answered Aug 11 '21 at 00:55

Using the EditText inside of a ConstraintLayout will fix this.

...
<androidx.constraintlayout.widget.ConstraintLayout
    android:layout_width="0dp"
    android:layout_height="match_parent"
    android:layout_weight="17">
    <androidx.appcompat.widget.AppCompatEditText
        android:layout_width="match_parent"
        android:layout_height="0dp"
        app:layout_constraintTop_toTopOf="parent"
        app:layout_constraintBottom_toBottomOf="parent"
        app:layout_constraintHeight_percent="1"
        android:textSize="24sp"
        android:text="foo"
    />
</androidx.constraintlayout.widget.ConstraintLayout>
