How to get height of Image in Imageview?

Question

I have set an image in imageview. It is showing in center of the screen as I have make its parent layout (Relative layout) to match parent. Imageview height and width is also set to match parent.

I want to get the height and width of Image in imageview.

I have used :

int imagWidth = imageView.getWidth();
int imagHeight = imageView.getHeight();

but by this we are getting height and width of Imageview .

Here is my xml:

<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:id="@+id/rl_root"
    android:layout_width="match_parent"
    android:layout_height="match_parent">

    <ImageView
        android:id="@+id/imag"
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        android:adjustViewBounds="true"
        android:background="@android:color/black"
        android:src="@drawable/image2" />
</RelativeLayout>

Try this :- https://stackoverflow.com/questions/12463155/get-the-displayed-size-of-an-image-inside-an-imageview — Ashutosh Tripathi, Mar 10 '18 at 09:47
@YahyaMukhtar: I have updated my ques ..Plz check I want to get height of my image programmatically. — Pragya Mendiratta, Mar 10 '18 at 09:52
@AshutoshTripathi: I have already tried this. but It's not working. — Pragya Mendiratta, Mar 10 '18 at 09:53
check out this link hope this will help you [enter link description here](https://stackoverflow.com/questions/4680499/how-to-get-the-width-and-height-of-an-android-widget-imageview/4680660#4680660) — Anuj, Mar 10 '18 at 10:26

Ali · Answer 1 · 2018-03-10T10:30:18.157

1

Using ImageView.getDrawable().getInstrinsicWidth() and getIntrinsicHeight() will both return the original dimensions.
Getting the Drawable through ImageView.getDrawable() and casting it to a BitmapDrawable, then using BitmapDrawable.getBitmap().getWidth() and getHeight() also returns the original image and its dimensions.

try below code :

ImageView.getDrawable().getIntrinsicHeight()//original height of underlying image
ImageView.getDrawable().getIntrinsicWidth()//original width of underlying image
imageView.getMeasuredHeight();//height of imageView
imageView.getMeasuredWidth();//width of imageView

reference : Trying to get the display size of an image in an ImageView

edited Mar 10 '18 at 10:30

answered Mar 10 '18 at 09:50

Ali

3,346
4
21
56

what will be the result of your solution - px or dp ? – Pragya Mendiratta Mar 10 '18 at 10:02
get the original **dimensions.** of a Image – Ali Mar 10 '18 at 10:08
didn't get you...can u plz explain ? – Pragya Mendiratta Mar 10 '18 at 10:13
https://stackoverflow.com/questions/3855218/trying-to-get-the-display-size-of-an-image-in-an-imageview **Follow this link** for batter understanding – Ali Mar 10 '18 at 10:18
see my Update answer @PragyaMendiratta – Ali Mar 10 '18 at 10:33

Santanu Sur · Answer 2 · 2018-03-10T10:34:07.243

0

Try this :-

Bitmap b = ((BitmapDrawable)imageView.getDrawable()).getBitmap();
int w = b.getWidth();
int h = b.getHeight(); // height of your image

P.S :- h IS HEIGHT OF IMAGE ( Original Image Height )

Update

If you want to get the exact height of the image inside the imageView try this :-

int height = imageView.getDrawable().getIntrinsicHeight();
int height_in_dp = Math.round(height / (displayMetrics.xdpi / DisplayMetrics.DENSITY_DEFAULT));

height_in_dp is the height of the image in dp !!

edited Mar 10 '18 at 10:34

answered Mar 10 '18 at 09:50

Santanu Sur

10,997
7
33
52

getting my app crashed : ColorDrawable cannot be cast to android.graphics.drawable.BitmapDrawable – Pragya Mendiratta Mar 10 '18 at 09:59
@PragyaMendiratta please check updated the answer ..!! – Santanu Sur Mar 10 '18 at 10:17
I have edited my question with image. plz check my comment in @yahya mukhtar answer....... image height is greater than imageview with the code you have mentioned... – Pragya Mendiratta Mar 10 '18 at 10:19
@PragyaMendiratta updated the answer please check !! – Santanu Sur Mar 10 '18 at 10:34
@PragyaMendiratta please feel free to ask , if you didnt understand !! – Santanu Sur Mar 10 '18 at 10:37
@shantanu , what if image is not fit in imageView, . . for eg there's black space as shown in the pic posted by pragyaMendiratta , will this include that black space in height/width or not?? – Nirmal Prajapat Mar 10 '18 at 11:13
@NirmalPrajapat hii, it should not ...if its `fitXy` instead of `center crop` , it should work by taking the whole height and width !! – Santanu Sur Mar 10 '18 at 11:18
I'm not using scalType . . – Nirmal Prajapat Mar 10 '18 at 11:21
@shantanu: Even I tried your updated solution...its not giving accurate height of image – Pragya Mendiratta Mar 10 '18 at 11:23
which mobile are you using @PragyaMendiratta – Santanu Sur Mar 10 '18 at 11:24
without black spaces @NirmalPrajapat – Santanu Sur Mar 10 '18 at 11:26
@PragyaMendiratta if you are using large device try `displayMetrics.xxhdpi` instead of `displayMetrics.xdpi` – Santanu Sur Mar 10 '18 at 11:27
@shantanu : I have drawn a view of the same height - calculated according to your updated solution. plz check my updated post – Pragya Mendiratta Mar 10 '18 at 11:36
I am using moto g(2 gen) and I am not getting option of `displayMetrices.xxhdpi` @shantanu – Pragya Mendiratta Mar 10 '18 at 11:37
@SantanuSur: did u find any solution for this ? – Pragya Mendiratta Mar 12 '18 at 10:01
Nope if i find out..i will update the answer !! @PragyaMendiratta – Santanu Sur Mar 12 '18 at 10:01

Yahya Mukhtar · Answer 3 · 2018-03-10T10:02:08.020

0

Bitmap b =  ((BitmapDrawable) imag.getDrawable()).getBitmap();
int w = b.getWidth();
int h = b.getHeight();

edited Mar 10 '18 at 10:02

answered Mar 10 '18 at 09:56

Yahya Mukhtar

474
5
13

getting following error: ColorDrawable cannot be cast to android.graphics.drawable.BitmapDrawable – Pragya Mendiratta Mar 10 '18 at 10:00
@Pragya check it now. – Yahya Mukhtar Mar 10 '18 at 10:03
I am getting h= 882 and imageview (imagHeight) height with imageView.getHeight() = 672.......... – Pragya Mendiratta Mar 10 '18 at 10:17
according to this bitmap height.. image height is greater than imageview.. that's not right – Pragya Mendiratta Mar 10 '18 at 10:17
