Excel-VBA: Generate sheet with predetermined table header

Question

I have sheet named "raw" and I want to filter it using button function. in "raw" sheet, there this table which have random header. what I want to do is that when I click the button, then new sheet "filter" will be generate with table where the header is more organized.

I am able to create new sheet within button but generating organized table is harder. I want to ask is it possible to create this table? I am a VBA Learner and interest in learn more in VBA programming.

By the way, I have try to make table using

Dim Ws As Worksheet
Set Ws = ThisWorkbook.Sheets("Sheet_Name")

Ws.ListObjects.Add(xlSrcRange, Ws.Range("A$xx:$V$xx"), , xlYes).Name = "New_Table_Name"
Ws.ListObjects("New_Table_Name").TableStyle = "TableStyleLight1"

and still I cannot naming the column table header.

Answer 1

Create a new Standard VBA module and paste the code bellow

If Worksheets("Filter") already exists:

---

Option Explicit

Public Sub CopyTable()      'Worksheets("Filter") exists

    Const TBL_ID = "New_Table_Name"
    Dim ws1 As Worksheet, ws2 As Worksheet

    Set ws1 = ThisWorkbook.Worksheets("Raw")
    Set ws2 = ThisWorkbook.Worksheets("Filter")

    Application.ScreenUpdating = False
    ws1.ListObjects(1).Range.Copy
    With ws2
        .Cells(1).PasteSpecial Paste:=xlPasteAll
        .Cells(1).PasteSpecial Paste:=xlPasteColumnWidths
        .Cells(1).Select
        .ListObjects(1).Name = TBL_ID
        MoveTableCols ws2, TBL_ID       'calls 3rd Sub **************
    End With
    Application.ScreenUpdating = True
End Sub

---

This will create a new Worksheet called "Filter"

---

Public Sub CopyWs()         'Creates a new Worksheets("Filter")

    Const TBL_ID = "New_Table_Name"
    Dim ws1 As Worksheet, ws2 As Worksheet, wsCount As Long

    Application.ScreenUpdating = False
    With ThisWorkbook
        Set ws1 = .Worksheets("Raw")
        ws1.Copy After:=.Worksheets(.Worksheets.Count)
        wsCount = .Worksheets.Count
        Set ws2 = .Worksheets(wsCount)
    End With
    ws2.Name = "Filter"
    ws2.ListObjects(1).Name = TBL_ID
    MoveTableCols ws2, TBL_ID           'calls 3rd Sub **************
    Application.ScreenUpdating = True
End Sub

---

The Sub bellow is called by both Subs above, and reorganizes the new table

---

'Called by CopyTable() and CopyWs() Subs

Private Sub MoveTableCols(ByRef ws As Worksheet, ByVal tblId As String)

    Dim arr As Variant

    With ws
        .Rows(4).Delete Shift:=xlUp 'To delete rows based on criteria use Autofilter

        .ListObjects(tblId).ListColumns.Add Position:=6

        arr = .ListObjects(tblId).ListColumns(1).DataBodyRange
        .ListObjects(tblId).ListColumns(6).DataBodyRange = arr

        arr = .Cells(1)
        .Columns(1).Delete Shift:=xlToLeft
        .Cells(5) = arr
    End With
End Sub

---

As Vityata mentioned, the Macro Recorder will generate the code for all your manual actions, you'll just need to improve it be removing all Activate and Select statements

Note: A table cannot have 2 identical headers so moving a column involves creating a new column, copying the data from the initial column, then "remembering" the header name, deleting the initial column, and renaming the header for the new column to the initial header name

Answer 2

As far as you are studying VBA for 3 days, it is a really good idea to start using the Macro recorder for tasks like this, at least to have a starting point. This is a simple example from the Macro Recorder:

Sub Makro1()
'
' Makro1 Makro
'

'
    Cells.Clear
    ActiveSheet.ListObjects.Add(xlSrcRange, Range("$A$1:$E$13"), , xlNo).Name = _
        "Table1"
    Range("Table1[#All]").Select
    ActiveSheet.ListObjects("Table1").TableStyle = "TableStyleLight9"
    Range("Table1[[#Headers],[Column1]]").Select
    ActiveCell.FormulaR1C1 = "Header1"
    Range("Table1[[#Headers],[Column2]]").Select
    ActiveCell.FormulaR1C1 = "Second Header"
    Range("Table1[[#Headers],[Column3]]").Select
    ActiveCell.FormulaR1C1 = "Third Header"
    Range("Table1[[#Headers],[Column4]]").Select
    ActiveCell.FormulaR1C1 = "Forth Header"
    Range("Table1[[#Headers],[Column5]]").Select
    ActiveCell.FormulaR1C1 = "Fifth Header"
    Range("A2").Select
End Sub

Play a bit, see how it works, use F8. After some time, you can look for a way to avoid the .Select and ActiveSheet. This is some example that can be automized further with a loop, based on the number of the header rows. However, it does not use ActiveSheet and Select:

Option Explicit

Sub TestMe()

    Dim ws As Worksheet
    Set ws = ThisWorkbook.Worksheets(1)
    Dim tbl As ListObject

    With ws
        .Cells.Clear
        .ListObjects.Add(xlSrcRange, .Range("A1:E10"), , xlNo).Name = "MyFirstTable"
        Set tbl = .ListObjects(1)

        tbl.HeaderRowRange.Cells(1, 1) = "SomeHeader1"
        tbl.HeaderRowRange.Cells(1, 2) = "SomeHeader2"
        tbl.HeaderRowRange.Cells(1, 3) = "SomeHeader3"
        tbl.HeaderRowRange.Cells(1, 4) = "SomeHeader4"
        tbl.HeaderRowRange.Cells(1, 5) = "SomeHeader5"
    End With

End Sub

E.g., if you want to loop through the header and hive some values, then this is the content of the With ws:

With ws
    .Cells.Clear
    .ListObjects.Add(xlSrcRange, .Range("A1:E10"), , xlNo).Name = "MyFirstTable"
    Set tbl = .ListObjects(1)

    Dim myCell  As Range
    For Each myCell In tbl.HeaderRowRange.Cells
        myCell = "SomeHeader " & myCell.Column
    Next myCell
End With
