stacked density plot with gg plot in R

Question

I fail to plot correcly my stacked density chart

here is my data structure

Classes ‘tbl_df’, ‘tbl’ and 'data.frame':   8517 obs. of  3 variables:
 $ time  : num  -500 -499 -498 -497 -496 -495 -494 -493 -492 -491 ...
 $ series: Factor w/ 17 levels "V1","V2","V3",..: 1 1 1 1 1 1 1 1 1 1 ...
 $ value : num  0.0788 0.0625 0.0455 0.0323 0.0426 ...

and here is my code

ggplot(data=data,aes(x=time, group=data$series, fill=data$series)) +
    geom_density(adjust=1.5, position="fill")

but it plots me horizontal lines

Instead I would like it plots me something like that

If anyone has any idea? I would appreciate. Thanks

here is my data structure

dput(head(data))
    structure(list(time = c(-500, -499, -498, -497, -496, -495),
        series = structure(c(1L, 1L, 1L, 1L, 1L, 1L), .Label = c("V1",
        "V2", "V3", "V4", "V5", "V6", "V7", "V8", "V9", "V10", "V11",
        "V12", "V13", "V14", "V15", "V16", "V17"), class = "factor"),
        value = c(0.0787576635451054, 0.0625, 0.0455255463892602,
        0.0322986577181208, 0.0426306596802365, 0.0369765758489718
        )), row.names = c(NA, -6L), class = c("tbl_df", "tbl", "data.frame"
    ))

How can I plot y value? ,this command aes(x=time,y = value, group=series, fill=series) returns me Warning message: Removed 8192 rows containing missing values (position_stack). — nico dm, Jul 26 '18 at 14:46
Copy exactly the output from `dput()` and update your question above, not here in the comments, thanks. — RLave, Jul 26 '18 at 15:01
https://stackoverflow.com/questions/5963269/how-to-make-a-great-r-reproducible-example see here for any questions, it's a guide for a reproducible example. — RLave, Jul 26 '18 at 15:01

score 0 · Answer 1 · answered Jul 26 '18 at 15:17

0

Does this work for you?

ggplot(data, aes(x=time, fill = series)) +
  geom_density(adjust=1.5, position="fill")

My bad, initially I got the wrong idea, you were almost there.

Just remove data$.

answered Jul 26 '18 at 15:17

RLave

8,144
3
21
37

score 0 · Answer 2 · answered Jul 26 '18 at 15:17

For the sake of illustrating it with multiple factors, I changed it a tad.

df <- structure(list(time = c(-500, -499, -498, -497, -496, -495),
           series = structure(c(1L, 1L, 2L, 2L, 3L, 3L), .Label = c("V1",
                                                                    "V2", "V3", "V4", "V5", "V6", "V7", "V8", "V9", "V10", "V11",
                                                                    "V12", "V13", "V14", "V15", "V16", "V17"), class = "factor"),
           value = c(0.0787576635451054, 0.0625, 0.0455255463892602,
                     0.0322986577181208, 0.0426306596802365, 0.0369765758489718
           )), row.names = c(NA, -6L), class = c("tbl_df", "tbl", "data.frame"
           ))


ggplot(df, aes(x = time)) +
  geom_density(stat = "density", aes(fill = series), position = "stack") # or fill if you want proportions

this is it but with my datas it stil produce me horizontal lines — nico dm, Jul 26 '18 at 15:26
This is basically the same code of mine. I get the same result. — RLave, Jul 26 '18 at 15:27
I'm not sure why you're getting lines with the same data you provided. If the data are all proportionally equal, you'd see the first image in your question. In your `str(data)` it lists 8517 observations. Are you running this on your larger set? — Anonymous coward, Jul 26 '18 at 17:37
