I made a heatmap using ggplot2 package. I want to add some text on the top of the graph using the annotate function. For some reason the text were "covered" by some portions. What can I do to show the full label?

The sample data is like this:

data <- data.frame("group" = c("grp1", "grp2", "grp3", "grp4"), "pct"  = runif(100, min = 0, max = 100))

  data <- data %>%
  group_by(group) %>%
  mutate(id = row_number())

Code for graph is like this:

ggplot(data, aes(x=id, y=group, fill = pct)) +
  geom_tile() +
  theme_minimal() +
  annotate("text", x = 3, y = 4.7, size = 3.2,label = "Morning") +
  annotate("text", x = 7, y = 4.7, size = 3.2,label = "Afternoon") +
  annotate("text", x = 12, y = 4.7, size=  3.2, label = "Evening") +
  annotate("text", x = 17, y = 4.7, size = 3.2, label = "Night") +
  theme(plot.margin = unit(c(0.3, 0.45, 0.3, 0.45), "cm"))

The figure is attached here. enter image description here You can see that the morning, afternoon, evening, and night text could not be displayed fully. I tried adding the margins using the plot.margin command, but did not work. Any idea on how to fix that?

Thanks!!

mandy
  • 483
  • 9
  • 20
  • 1
    Try expanding the y scale to make room for the annotation. Also [see here](https://stackoverflow.com/questions/5963269/how-to-make-a-great-r-reproducible-example) on making an R question that's easy to answer—people could provide better help if you post more of the stuff we need to reproduce the issue (i.e. the data) and less of the stuff we don't need for the issue (theme & styling stuff) – camille Aug 07 '18 at 20:54
  • Thanks for the suggestions! I edited my question as you suggested. Expanding the y scale is hard to achieve because the y scale is decided by number of groups in the data set. – mandy Aug 07 '18 at 21:50

1 Answers1

2

plot.margin sets the margins around the outside of the plot, whereas you need to make more space inside the plot. @Camille has the right idea: you need to expand the y-axis. Luckily it's simple: just pass the expand argument to scale_y_discrete.

expand just adds extra space to the sides of the axis, so it doesn't matter that your data is discrete (unlike using ylim). If you want to define the extra space in more detail (for example, to only add space to the top), passing expand_scale to the expand argument (thanks @Camille!) lets you define the extra space on each of the 4 sides individually. It also lets you add either an absolute or relative amount of space. The syntax is a bit weird, so check ?expand_scale to see the argument names:

ggplot(data, aes(x=id, y=group, fill = pct)) +
    geom_tile() +
    theme_minimal() +
    annotate("text", x = 3, y = 4.7, size = 3.2,label = "Morning") +
    annotate("text", x = 7, y = 4.7, size = 3.2,label = "Afternoon") +
    annotate("text", x = 12, y = 4.7, size=  3.2, label = "Evening") +
    annotate("text", x = 17, y = 4.7, size = 3.2, label = "Night") +
    scale_y_discrete(expand = expand_scale(mult = c(0, 0.3)))

enter image description here

divibisan
  • 11,659
  • 11
  • 40
  • 58
  • Just to add to this: the most recent `ggplot2` added `expand_scale`, which you can use to expand by an addition and/or multiplication term for more fine-tuned & intuitive adjustment – camille Aug 07 '18 at 22:22
  • Thanks! how can I just add extra space above instead of adding space to both above and the bottom? (I want the number id stay at the original place). – mandy Aug 07 '18 at 23:03
  • I've updated the answer. `expand_scale` gives you more control. @camille Thanks for the suggestion! – divibisan Aug 07 '18 at 23:13
