How to create a graph varying point size?

Question

I have the following dataframe:

               Madrugada  Mañana  Tarde  Noche
Lunes              1       2      3      4
Martes             5       6      7      8
Miércoles          9      10     11     12
Jueves            13      14     15     16
Viernes           17      18     19     20
Sábado            21      22     23     24
Domingo           25      26     27     28

Created with:

 import pandas as pd
index = ['Lunes', 'Martes', 'Miércoles', 'Jueves', 'Viernes', 'Sábado', 'Domingo']
columns = ['Madrugada','Mañana', 'Tarde', 'Noche']
Cuadro = pd.DataFrame(index=index, columns=columns)

Cuadro.loc['Lunes'] = pd.Series({'Madrugada':1, 'Mañana':2, 'Tarde':3,
          'Noche':4})
Cuadro.loc['Martes'] = pd.Series({'Madrugada':5, 'Mañana':6, 'Tarde':7,
          'Noche':8})
Cuadro.loc['Miércoles'] = pd.Series({'Madrugada':9, 'Mañana':10, 'Tarde':11,
          'Noche':12})
Cuadro.loc['Jueves'] = pd.Series({'Madrugada':13, 'Mañana':14, 'Tarde':15,
          'Noche':16})
Cuadro.loc['Viernes'] = pd.Series({'Madrugada':17, 'Mañana':18, 'Tarde':19,
          'Noche':20})
Cuadro.loc['Sábado'] = pd.Series({'Madrugada':21, 'Mañana':22, 'Tarde':23,
          'Noche':24})
Cuadro.loc['Domingo'] = pd.Series({'Madrugada':25, 'Mañana':26, 'Tarde':27,
          'Noche':28})
print(Cuadro)

How may I create a graph like:

                      Data Usage:

|Midnight          o
|
|Night                                                             OOO
|                                                                      OOO
|Afternoon
|
|            o          O     O          (   )
|Morning__________________________________________________________________

              M      T       W           Th         F          Sat          Sun

Where the size of the points is dependant on the value of the cell? Thanking you in advance for any help or recommendation... Jose

You can add a list of sizes to matplotlib's `scatter`: https://stackoverflow.com/questions/14827650/pyplot-scatter-plot-marker-size — user8408080, Nov 21 '18 at 02:12
Thank you for the suggestion, How that could be implemented to create a graph with varying point size (dependant on the value of the cell) as described above? — José Luis Martínez, Nov 21 '18 at 02:32

score 3 · Accepted Answer · answered Nov 21 '18 at 04:28

3

data.csv

Day,Midnight,Morning,Afternoon,Night
Monday,4.002900,30.905096,25.193066,23.704473
Tuesday,22.074967,16.407200,50.409445,27.396373
Wednesday,18.875000,28.415111,22.205521,25.744592
Thursday,12.470333,16.265086,15.390797,81.988800
Friday,NaN,33.658050,23.814764,20.096790
Saturday,12.647037,16.545295,25.620673,14.903473
Sunday,4.975500,19.023320,21.215298,45.440120

code.py

import pandas as pd
import matplotlib.pyplot as plt

df = pd.read_csv("data.csv")
fig, ax = plt.subplots()
ax.scatter(df['Day'], ['Midnight']*7, s=20*df['Midnight'])
ax.scatter(df['Day'], ['Morning']*7, s=20*df['Morning'])
ax.scatter(df['Day'], ['Afternoon']*7, s=20*df['Afternoon'])
ax.scatter(df['Day'], ['Night']*7, s=20*df['Night'])
plt.ylabel('Time of Day')
plt.xlabel('Day of the Week')
plt.show()

Resulting Plot

answered Nov 21 '18 at 04:28

Conner

30,144
8
52
73

It was exactly what I was needing to finish my project – José Luis Martínez Nov 21 '18 at 12:58
If it helped you can designate an accepted answer with the check mark to the left of my answer. Cheers :) – Conner Nov 21 '18 at 13:45
How did you learn to graph like that? Would you please, be so kind as to give me some advice on where to get Matplotlib graphing tips? Thanking you in advance...Jose – José Luis Martínez Nov 21 '18 at 19:29
Practice and reading the documentation; honestly I haven't found any great resources but maybe I should create one. – Conner Nov 22 '18 at 13:31
Looking forward to read it whenever published, please let us know to be able to get better at Ploting with Matplolib...Thanks! – José Luis Martínez Nov 22 '18 at 15:11
