Proper implementation of ViewPager2 in Android

Question

I came to know about ViewPager2 and tried to implement it, but didn't find any proper example.

Can anyone tell me how can I use it.

I am looking for proper usage, not an example.

Here is explanation and example check it : http://michaelevans.org/blog/2019/02/07/hands-on-with-viewpager2/ — Mehul Kabaria, Feb 12 '19 at 05:32
Whoever given close votes for `recommend or find a book, tool, software library, tutorial or other off-site resource` Please read carefully that I am not looking for example. — Pratik Butani, Feb 12 '19 at 05:57
There is an official sample: https://github.com/googlesamples/android-viewpager2 — Albert Vila Calvo, Sep 18 '19 at 09:33
@NikunjParadva Answer of Nilesh Rathod is much appreciated and also looks like blog post. The question is just simple. — Pratik Butani, Jun 11 '20 at 07:31

AskNilesh · Accepted Answer · 2019-11-25T12:15:13.887

UPDATE 7

Check : Migrate from ViewPager to ViewPager2

Check : Create swipe views with tabs using ViewPager2

UPDATE 6

Check out my answer if you want to implement Carousel using View Pager2

UPDATE 5

How to use TabLayout with ViewPager2

SAMPLE CODE

Use below dependencies

implementation 'com.google.android.material:material:1.1.0-alpha08'
implementation 'androidx.viewpager2:viewpager2:1.0.0-beta02'

SAMPLE CODE

XMl layout

<?xml version="1.0" encoding="utf-8"?>
<androidx.coordinatorlayout.widget.CoordinatorLayout
        xmlns:android="http://schemas.android.com/apk/res/android"
        xmlns:app="http://schemas.android.com/apk/res-auto"
        xmlns:tools="http://schemas.android.com/tools"
        android:layout_width="match_parent"
        android:layout_height="match_parent">

    <com.google.android.material.appbar.AppBarLayout
            android:layout_width="match_parent"
            android:layout_height="wrap_content"
            android:theme="@style/ThemeOverlay.AppCompat.Dark.ActionBar">

        <androidx.appcompat.widget.Toolbar
                android:id="@+id/toolbar"
                android:layout_width="match_parent"
                android:layout_height="?attr/actionBarSize"
                android:background="?attr/colorPrimary"
                app:layout_scrollFlags="scroll|enterAlways"
                app:popupTheme="@style/ThemeOverlay.AppCompat.Light"/>

        <com.google.android.material.tabs.TabLayout
                android:id="@+id/tabs"
                android:layout_width="match_parent"
                android:layout_height="wrap_content"/>
    </com.google.android.material.appbar.AppBarLayout>

    <androidx.viewpager2.widget.ViewPager2
            android:id="@+id/viewpager"
            app:layout_anchor="@id/tabs"
            app:layout_anchorGravity="bottom"
            android:layout_width="match_parent"
            android:layout_height="match_parent"
    />


</androidx.coordinatorlayout.widget.CoordinatorLayout>

Activity

import androidx.appcompat.app.AppCompatActivity
import android.os.Bundle
import kotlinx.android.synthetic.main.activity_main.*
import com.google.android.material.tabs.TabLayoutMediator

import com.google.android.material.tabs.TabLayout


class MainActivity : AppCompatActivity() {

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        setContentView(R.layout.activity_main)

//        setSupportActionBar(toolbar)
        viewpager.adapter = AppViewPagerAdapter(supportFragmentManager, lifecycle)

        TabLayoutMediator(tabs, viewpager, object : TabLayoutMediator.OnConfigureTabCallback {
            override fun onConfigureTab(tab: TabLayout.Tab, position: Int) {
                // Styling each tab here
                tab.text = "Tab $position"
            }
        }).attach()


    }
}

OUTPUT

TabLayout with ViewPager2

From Docs

ViewPager2

New features

Right-to-left (RTL) layout support
Vertical orientation support
notifyDataSetChanged fully functional

API changes

FragmentStateAdapter replaces FragmentStatePagerAdapter
RecyclerView.Adapter replaces PagerAdapter
registerOnPageChangeCallback replaces addPageChangeListener

SAMPLE CODE

add the latest dependencies for ViewPager2

implementation 'androidx.viewpager2:viewpager2:1.0.0-alpha01'

layout

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:orientation="vertical"
    tools:context=".MainActivity">

    <androidx.viewpager2.widget.ViewPager2
        android:id="@+id/view_pager"
        android:layout_width="match_parent"
        android:layout_height="match_parent" />

</LinearLayout>

activity

import android.os.Bundle;
import androidx.appcompat.app.AppCompatActivity;
import androidx.viewpager2.widget.ViewPager2;

import java.util.ArrayList;

public class MyActivity extends AppCompatActivity {

    ViewPager2 myViewPager2;
    MyAdapter MyAdapter;
    private ArrayList<String> arrayList = new ArrayList<>();

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_my);

        myViewPager2 = findViewById(R.id.view_pager);

        arrayList.add("Item 1");
        arrayList.add("Item 2");
        arrayList.add("Item 3");
        arrayList.add("Item 4");
        arrayList.add("Item 5");

        MyAdapter = new MyAdapter(this, arrayList);


        myViewPager2.setOrientation(ViewPager2.ORIENTATION_VERTICAL);

        myViewPager2.setAdapter(MyAdapter);
    }
}

MyAdapter

import android.content.Context;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;
import android.widget.TextView;
import androidx.annotation.NonNull;
import androidx.recyclerview.widget.RecyclerView;

import java.util.ArrayList;

public class MyAdapter extends RecyclerView.Adapter<MyAdapter.MyViewHolder> {

    private Context context;
    private ArrayList<String> arrayList = new ArrayList<>();

    public MyAdapter(Context context, ArrayList<String> arrayList) {
        this.context = context;
        this.arrayList = arrayList;
    }

    @NonNull
    @Override
    public MyViewHolder onCreateViewHolder(@NonNull ViewGroup parent, int viewType) {
        View view = LayoutInflater.from(context).inflate(R.layout.list_item, parent, false);
        return new MyViewHolder(view);
    }

    @Override
    public void onBindViewHolder(@NonNull MyViewHolder holder, int position) {
        holder.tvName.setText(arrayList.get(position));
    }

    @Override
    public int getItemCount() {
        return arrayList.size();
    }

    public class MyViewHolder extends RecyclerView.ViewHolder {
        TextView tvName;

        public MyViewHolder(@NonNull View itemView) {
            super(itemView);
            tvName = itemView.findViewById(R.id.tvName);
        }
    }
}

New features

now we need to use ViewPager2.OnPageChangeCallback() to get Swipe event of ViewPager2

SAMPLE CODE

    myViewPager2.registerOnPageChangeCallback(new ViewPager2.OnPageChangeCallback() {
        @Override
        public void onPageScrolled(int position, float positionOffset, int positionOffsetPixels) {
            super.onPageScrolled(position, positionOffset, positionOffsetPixels);
        }

        @Override
        public void onPageSelected(int position) {
            super.onPageSelected(position);

            Log.e("Selected_Page", String.valueOf(position));
        }

        @Override
        public void onPageScrollStateChanged(int state) {
            super.onPageScrollStateChanged(state);
        }
    });

we can set Orientation using myViewPager2.setOrientation()

SAMPLE CODE

For HORIZONTAL Orientation use

myViewPager2.setOrientation(ViewPager2.ORIENTATION_HORIZONTAL);

For VERTICAL Orientation use

myViewPager2.setOrientation(ViewPager2.ORIENTATION_VERTICAL);

We can use notifyDataSetChanged same as we are using in RecyclerView.Adapter

SAMPLE CODE to add new item

    btnAdd.setOnClickListener(new View.OnClickListener() {
        @Override
        public void onClick(View view) {
            arrayList.add("New ITEM ADDED");
            MyAdapter.notifyDataSetChanged();
        }
    });

SAMPLE CODE to remove new item

    btnRemove.setOnClickListener(new View.OnClickListener() {
        @Override
        public void onClick(View view) {
            arrayList.remove(3);
            MyAdapter.notifyItemRemoved(3);
        }
    });

UPDATE

Try this if you want to use `Fragment` with `ViewPager2`

First create a ViewPagerFragmentAdapter class which extends FragmentStateAdapter

import java.util.ArrayList;
import androidx.annotation.NonNull;
import androidx.fragment.app.Fragment;
import androidx.fragment.app.FragmentManager;
import androidx.viewpager2.adapter.FragmentStateAdapter;

public class ViewPagerFragmentAdapter extends FragmentStateAdapter {

    private ArrayList<Fragment> arrayList = new ArrayList<>();

    public ViewPagerFragmentAdapter(@NonNull FragmentManager fragmentManager) {
        super(fragmentManager);
    }

    @NonNull
    @Override
    public Fragment getItem(int position) {
        return arrayList.get(position);
    }

    public void addFragment(Fragment fragment) {
        arrayList.add(fragment);
    }

    @Override
    public int getItemCount() {
        return arrayList.size();
    }
}

Now use like this in your activity

import androidx.annotation.Nullable;
import androidx.appcompat.app.AppCompatActivity;
import androidx.viewpager2.widget.ViewPager2;
import neel.com.bottomappbar.R;

public class MainActivity extends AppCompatActivity {

    ViewPager2 myViewPager2;
    ViewPagerFragmentAdapter myAdapter;

    @Override
    protected void onCreate(@Nullable Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        myViewPager2 = findViewById(R.id.view_pager);

        myAdapter = new ViewPagerFragmentAdapter(getSupportFragmentManager());

        // add Fragments in your ViewPagerFragmentAdapter class
        myAdapter.addFragment(new FragmentOne());
        myAdapter.addFragment(new Fragmenttwo());
        myAdapter.addFragment(new FragmentThree());

        // set Orientation in your ViewPager2
        myViewPager2.setOrientation(ViewPager2.ORIENTATION_VERTICAL);

        myViewPager2.setAdapter(myAdapter);

    }

}

for more information check this

UPDATE 2

Version 1.0.0-alpha02

New features

Ability to disable user input (setUserInputEnabled, isUserInputEnabled)

API changes

ViewPager2 class final

Bug fixes

FragmentStateAdapter stability fixes

SAMPLE CODE to disable swiping in viewpager2

myViewPager2.setUserInputEnabled(false);// SAMPLE CODE to disable swiping in viewpager2


myViewPager2.setUserInputEnabled(true);//SAMPLE CODE to enable swiping in viewpager2

UPDATE 3

Version 1.0.0-alpha03

New features

Ability to programmatically scroll ViewPager2: fakeDragBy(offsetPx).

API changes

FragmentStateAdapter now requires a Lifecycle object. Two utility constructors added to obtain it from the host FragmentActivity or the host Fragment

SAMPLE CODE

ViewPagerFragmentAdapter

import java.util.ArrayList;
import androidx.annotation.NonNull;
import androidx.fragment.app.Fragment;
import androidx.fragment.app.FragmentManager;
import androidx.lifecycle.Lifecycle;
import androidx.viewpager2.adapter.FragmentStateAdapter;

public class ViewPagerFragmentAdapter extends FragmentStateAdapter {

    private ArrayList<Fragment> arrayList = new ArrayList<>();


    public ViewPagerFragmentAdapter(@NonNull FragmentManager fragmentManager, @NonNull Lifecycle lifecycle) {
        super(fragmentManager, lifecycle);
    }

    @NonNull
    @Override
    public Fragment getItem(int position) {
        return arrayList.get(position);
    }

    public void addFragment(Fragment fragment) {
        arrayList.add(fragment);
    }

    @Override
    public int getItemCount() {
        return arrayList.size();
    }
}

MainActivity code

import android.os.Bundle;
import androidx.annotation.Nullable;
import androidx.appcompat.app.AppCompatActivity;
import androidx.viewpager2.widget.ViewPager2;
import neel.com.bottomappbar.R;

public class MainActivity extends AppCompatActivity {

    ViewPager2 myViewPager2;
    ViewPagerFragmentAdapter myAdapter;

    @Override
    protected void onCreate(@Nullable Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        myViewPager2=findViewById(R.id.view_pager);
        myAdapter = new ViewPagerFragmentAdapter(getSupportFragmentManager(), getLifecycle());

        // add Fragments in your ViewPagerFragmentAdapter class
        myAdapter.addFragment(new FragmentOne());
        myAdapter.addFragment(new Fragmenttwo());
        myAdapter.addFragment(new FragmentThree());

        myViewPager2.setOrientation(ViewPager2.ORIENTATION_VERTICAL);

        myViewPager2.setAdapter(myAdapter);
    }
}

UPDATE 4

Version 1.0.0-alpha05 New features

ItemDecorator introduced with a behaviour consistent with RecyclerView.
MarginPageTransformer introduced to provide an ability to create space between pages (outside of page inset).
CompositePageTransformer introduced to provide an ability to combine multiple PageTransformers

API changes

FragmentStateAdapter#getItem method renamed to FragmentStateAdapter#createFragment - previous method name has proven to be a source of bugs in the past.
OFFSCREEN_PAGE_LIMIT_DEFAULT value changed from 0 to -1. No need for a client code change if the OFFSCREEN_PAGE_LIMIT_DEFAULTconstant used.

SAMPLE CODE

Activity code

import androidx.annotation.NonNull;
import androidx.annotation.Nullable;
import androidx.appcompat.app.AppCompatActivity;
import androidx.fragment.app.Fragment;
import androidx.recyclerview.widget.RecyclerView;
import androidx.viewpager2.widget.MarginPageTransformer;
import androidx.viewpager2.widget.ViewPager2;
import neel.com.bottomappbar.R;

public class MainActivity extends AppCompatActivity {

    ViewPager2 myViewPager2;
    ViewPagerFragmentAdapter myAdapter;
    private ArrayList<Fragment> arrayList = new ArrayList<>();

    @Override
    protected void onCreate(@Nullable Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        myViewPager2 = findViewById(R.id.myViewPager2);

        // add Fragments in your ViewPagerFragmentAdapter class
        arrayList.add(new FragmentOne());
        arrayList.add(new Fragmenttwo());
        arrayList.add(new FragmentThree());

        myAdapter = new ViewPagerFragmentAdapter(getSupportFragmentManager(), getLifecycle());
        // set Orientation in your ViewPager2
        myViewPager2.setOrientation(ViewPager2.ORIENTATION_HORIZONTAL);

        myViewPager2.setAdapter(myAdapter);

        myViewPager2.setPageTransformer(new MarginPageTransformer(1500));


    }
}

ViewPagerFragmentAdapter

import java.util.ArrayList;
import androidx.annotation.NonNull;
import androidx.fragment.app.Fragment;
import androidx.fragment.app.FragmentManager;
import androidx.lifecycle.Lifecycle;
import androidx.viewpager2.adapter.FragmentStateAdapter;

public class ViewPagerFragmentAdapter extends FragmentStateAdapter {

    private ArrayList<Fragment> arrayList = new ArrayList<>();


    public ViewPagerFragmentAdapter(@NonNull FragmentManager fragmentManager, @NonNull Lifecycle lifecycle) {
        super(fragmentManager, lifecycle);
    }

    @NonNull
    @Override
    public Fragment createFragment(int position) {
        switch (position) {
            case 0:
                return new FragmentOne();
            case 1:
                return new Fragmenttwo();
            case 2:
                return new FragmentThree();

        }
        return null;
    }

    @Override
    public int getItemCount() {
        return 3;
    }
}

Awesome, I didn't get time for blogpost but I will do for sure. — Pratik Butani, Mar 12 '19 at 09:43
@PratikButani we have new updates for `ViewPager2` using `Version 1.0.0-alpha02` — AskNilesh, Mar 16 '19 at 06:00
Every time when I read you comment, again refreshing me to write blog :D — Pratik Butani, Mar 16 '19 at 06:17
[Early Introduction of ViewPager2](https://blog.usejournal.com/early-introduction-of-viewpager2-ff38c60d2169) by @BirjuVachhani , check this, it might be useful — Ravi, Mar 29 '19 at 10:37
Nice detailed description for ViewPager2, But please make a edit for, this version of ViewPager2 is released for Android X Only. so you need to add Android X dependecy to compile the project successfully. — Ramkesh Yadav, May 14 '19 at 14:36
Is it possible to use `PagerTitleStrip` or `PagerTabStrip` with ViewPager2 or maybe there is an alternative? — guillaume, May 15 '19 at 10:07
Hi @NileshRathod. In update 4, is there a way to use `ArrayList` object to create fragments dynamically in `ViewPagerFragmentAdapter`? — mrisek, Jun 21 '19 at 06:19
@mrisek yes that is possible please [contact me](https://stackoverflow.com/users/7666442/nilesh-rathod?tab=profile) i will send u sample code — AskNilesh, Jun 21 '19 at 06:24
@MahmoudAyman check this post https://stackoverflow.com/a/45518240/7666442 — AskNilesh, Jun 26 '19 at 06:44
How to destroy views like `PagerAdapter`'s `destroyItem` function in the custom `RecyclerView.Adapter`? — Phani Rithvij, Dec 24 '19 at 12:20
I tried overriding `onViewRecycled` as `override fun onViewRecycled(holder: ViewHolder) { (holder.itemView as ViewGroup).removeAllViews() super.onViewRecycled(holder) }` it worked — Phani Rithvij, Dec 24 '19 at 12:26
@PhaniRithvij no need to destroyItem inside `RecyclerView.Adapter` why you want to destroy item inside it ? — AskNilesh, Dec 24 '19 at 12:37
Because I'm getting multiple views laid on top of each other. As I'm doing a `holder.view.addView(view_c)` in `onBindViewHolder` — Phani Rithvij, Dec 24 '19 at 12:50
Wouldn't the list of fragments you have in `ViewPagerFragmentAdapter` prevent recycling? — Saurabh, Jan 28 '20 at 22:54
How to wrap height of Android ViewPager2 to height of current item? — Chirag Patel, Mar 03 '20 at 05:54
I think you are still using the old adapter as the new adapter is FragmentStatePagerAdapter — Amir Dora., Mar 24 '20 at 08:08
@AmirDora nop, I haven't updated my answer after Nov 25 '2019 — AskNilesh, Mar 24 '20 at 08:10
Please update it, because the new lifecycle feature BEHAVIOR_RESUME_ONLY_CURRENT_FRAGMENT can be used only with FragmentStatePagerAdapter — Amir Dora., Mar 24 '20 at 08:18
Hi @NileshRathod, it is possible to create ViewPager2 inside a Fragment that can host other Fragments instead of using Activity? — Ally, Apr 18 '20 at 05:37
I have trouble injecting viewPage2 in my fragment which is basically homeFrag, lemme debug my code and figure what I'm missing. Thanks @NileshRathod — Ally, Apr 18 '20 at 09:00
@Ali I am using viewpager with TabLayout in fragment, I am not able to swipe the screen. it's stuck on 1st fragment, how can I solve this issue — iamkdblue, May 02 '20 at 20:26
@kdblue have you tred to set the viewpager.isUserInputEnabled = true — Ally, May 04 '20 at 00:55
@Ali I solved, it was happening because of swipe refresh layout. — iamkdblue, May 04 '20 at 10:08
@iamkdblue i am also facing the same issue, but i wanna keep the swipe refresh layout, do u have any idea how to fix it? — Aldor, Jul 09 '20 at 09:58
@Nilesh Rathod I also have a viewpager2 and tablyout inside a fragment but it isn't swiping. — Aldor, Jul 09 '20 at 10:25
@Aldor can you please share your code let me check your code — AskNilesh, Jul 09 '20 at 10:36
@Aldor which artifact version you're using in your app build.gradle dependency? — Ally, Jul 09 '20 at 10:57
@Nilesh Rathod here is the link to my question. I have the code there as well . https://stackoverflow.com/questions/62810129/viewpager2-with-tablayout-inside-a-fragment-shows-no-swipe-effect-in-kotlin — Aldor, Jul 09 '20 at 12:22
@NileshRathod, you have created an arraylist of fragments but you're not calling them anywhere? — input, Aug 20 '20 at 00:51
nice and detailed post but can u add how to handle lifecycles in viewpager2 as I am not able to find any solution.. ? — Mohit Yadav, Jul 06 '21 at 15:31
All answers are here, thanks a lot,I wish the google documentation team can pick a leaf of how an API migration manual ought to look like — m'hd semps, Dec 16 '21 at 16:21
That's a lot of knowledge for such a thing, I'm missing a simple TabLayout constructor where you can simply pass the array of fragments with titles and be done. — David, Jun 20 '22 at 21:24
In the last example ViewPagerFragmentAdapter has an arraylist but it's not used. Can we do return arraylist[position] in createFragment() ? — Muhammad Hanzilah, Apr 14 '23 at 11:34

score 14 · Answer 2 · edited Jan 15 '20 at 16:33

Actually now there is an official samples repo for ViewPager2 (linked below)

https://github.com/android/views-widgets-samples/tree/master/ViewPager2

Repo contains following samples (Quoting from the repo readme below)

Samples

ViewPager2 with Views - shows how to set up a ViewPager2 with Views as pages

ViewPager2 with Fragments - shows how to set up a ViewPager2 with Fragments as pages

ViewPager2 with a Mutable Collection (Views) - demonstrates usage of ViewPager2 with Views as pages and mutations in a page adapter

ViewPager2 with a Mutable Collection (Fragments) - demonstrates usage of ViewPager2 with Fragments as pages, and mutations in a page adapter

ViewPager2 with a TabLayout (Views) - shows how to set up a ViewPager2 with Views as pages, and link it to a TabLayout

Simple example of ViewPager2 with Fragments in Kotlin

activity_main.xml

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:orientation="vertical"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    tools:context=".MainActivity">

    <androidx.viewpager2.widget.ViewPager2
        android:id="@+id/pager2_container"
        android:layout_width="match_parent"
        android:layout_height="0dp"
        android:layout_weight="1"/>

</LinearLayout>

MainActivity.kt

class MainActivity : AppCompatActivity() {

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        setContentView(R.layout.activity_main)


        val viewPager2 = findViewById<ViewPager2>(R.id.pager2_container)

        val fragmentList = arrayListOf(
            FirstFragment.newInstance(),
            SecondFragment.newInstance(),
            ThirdFragment.newInstance()
        )
        viewPager2.adapter = ViewPagerAdapter(this, fragmentList)
   }
}

FirstFragment.kt (SecondFragment.kt and ThirdFragment.kt looks similar to FirstFragment.kt)

class FirstFragment : Fragment() {

    override fun onCreateView(
        inflater: LayoutInflater, container: ViewGroup?,
        savedInstanceState: Bundle?
    ): View? {
        return inflater.inflate(R.layout.fragment_first, container, false)
    }

    companion object{
        fun newInstance() = FirstFragment()
    }
}

ViewPagerAdapter.kt

class ViewPagerAdapter(fa:FragmentActivity, private val fragments:ArrayList<Fragment>): FragmentStateAdapter(fa) {

    override fun getItemCount(): Int = fragments.size

    override fun createFragment(position: Int): Fragment = fragments[position]

}

Some other useful resources:

API reference: https://developer.android.com/reference/androidx/viewpager2/widget/ViewPager2
Training: https://developer.android.com/training/animation/screen-slide-2
Release notes: https://developer.android.com/jetpack/androidx/releases/viewpager2
Medium article by a GDE : Exploring the ViewPager2

How can we use this type of implementation with ViewBinding? — Maulik Dodia, Dec 31 '20 at 20:31
@MaulikDodia nothing special is needed use as usual, please see the docs : https://developer.android.com/topic/libraries/view-binding — user158, Jan 04 '21 at 00:47

score 7 · Answer 3 · edited Jun 20 '20 at 09:12

Use of ViewPager2 in Android

As mentioned on Developer Site

API changes

FragmentStateAdapter replaces FragmentStatePagerAdapter

RecyclerView.Adapter replaces PagerAdapter

registerOnPageChangeCallback replaces addPageChangeListener

In Simple Words they make it View Pager adapter work like Recycle View Adapter.

Note:- We don't need to use fragment in View Pager 2. It is fully depend on RecyclerView.Adapter inflate layout.

Here is sample gitHub repo Link

Example:-

MainActivity.class

public class MainActivity extends AppCompatActivity {

    private ViewPager2 mPager;

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);
        getSupportActionBar().setTitle("View Pager 2");
        mPager = findViewById(R.id.pager);
        mPager.setAdapter(new MyViewPagerAdapter(this));
    }

    @Override
    public boolean onCreateOptionsMenu(Menu menu) {
        getMenuInflater().inflate(R.menu.main, menu);
        return super.onCreateOptionsMenu(menu);
    }

    @Override
    public boolean onOptionsItemSelected(MenuItem item) {
        if (R.id.change == item.getItemId()) {
            mPager.setOrientation(mPager.getOrientation() != ViewPager2.ORIENTATION_VERTICAL ? ViewPager2.ORIENTATION_VERTICAL : ViewPager2.ORIENTATION_HORIZONTAL);
        }
        return super.onOptionsItemSelected(item);
    }
}

activity_main.xml

<?xml version="1.0" encoding="utf-8"?>
<android.support.constraint.ConstraintLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    tools:context=".MainActivity">

    <androidx.viewpager2.widget.ViewPager2
        android:id="@+id/pager"
        android:layout_width="match_parent"
        android:layout_height="match_parent" />

</android.support.constraint.ConstraintLayout>

MyViewPagerAdapter.class

public class MyViewPagerAdapter extends RecyclerView.Adapter<MyHolder> {

    private Context context;

    public MyViewPagerAdapter(Context context) {
        this.context=context;
    }

    @NonNull
    @Override
    public MyHolder onCreateViewHolder(@NonNull ViewGroup parent, int viewType) {
        return new MyHolder(LayoutInflater.from(context).inflate(R.layout.cell_item, parent, false));
    }

    @Override
    public void onBindViewHolder(@NonNull MyHolder holder, int position) {
      holder.mText.setText("Page "+(position+1));
    }

    @Override
    public int getItemCount() {
        return 10;
    }
}

cell_item.xml

<?xml version="1.0" encoding="utf-8"?>
<android.support.constraint.ConstraintLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="match_parent"
    android:layout_height="match_parent">

    <TextView
        android:id="@+id/text"
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        android:gravity="center"
        android:text="Page 1"
        android:textSize="20sp" />

</android.support.constraint.ConstraintLayout>

MyHolder.class

class MyHolder extends RecyclerView.ViewHolder {

    public TextView mText;

    public MyHolder(@NonNull View itemView) {
        super(itemView);
        mText = itemView.findViewById(R.id.text);
    }
}

output:

@ysfcyln yes you can use `Fragment` with `ViewPager2` please check [my above answer](https://stackoverflow.com/a/54643817/7666442) i have added sample code for `How use Fragment with ViewPager2` — AskNilesh, Mar 12 '19 at 07:58
https://github.com/sushildlh/ViewPager2. See also https://medium.com/swlh/android-viewpager2-tablayout-3099aae2f396 for new info. :) — CoolMind, Aug 01 '19 at 15:27
Here is the repo -> https://github.com/android/views-widgets-samples/tree/master/ViewPager2 — androidStud, Oct 15 '19 at 23:48

Mohamed AbdelraZek · Answer 4 · 2020-02-24T11:35:53.040

Here is what I did to implemet ViewPager2 with TabLayout with 3 Fragment full Examble:

Layout contains ViewPager2 with TabLayout:

 <LinearLayout
        xmlns:android="http://schemas.android.com/apk/res/android"
        android:layout_width="0dp"
        android:layout_height="0dp"
        android:orientation="vertical"
        app:layout_constraintBottom_toBottomOf="parent"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintStart_toStartOf="parent"
        app:layout_constraintTop_toBottomOf="@+id/include3">

        <com.google.android.material.tabs.TabLayout
            android:id="@+id/tab_layout"
            android:layout_width="match_parent"
            android:background="@color/colorPrimary"
            app:tabTextColor="@color/tab_dismiss_color"
            app:tabSelectedTextColor="@color/green"
            android:layout_height="wrap_content" />

        <View
            android:layout_width="match_parent"
            android:layout_height="1dp"
            android:layout_gravity="bottom"
            android:background="#e4e4e4" />

        <androidx.viewpager2.widget.ViewPager2
            android:id="@+id/pager"
            android:layout_width="match_parent"
            android:layout_height="0dp"
            android:layout_weight="1" />
    </LinearLayout>

init ViewPager2 and set Tabs Name:

 @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_report);
        ButterKnife.bind(this);
        actionBarTitleId.setText(R.string.reports);

        viewPager.setAdapter(new ViewPagerAdapter(this));

        new TabLayoutMediator(tabLayout, viewPager, (tab, position) -> {
            switch (position) {
                case 0:
                    tab.setText(R.string.financial_duty_str);
                    break;
                case 1:
                    tab.setText(R.string.financial_unpaid_str);
                    break;
                case 2:
                    tab.setText(R.string.financial_paid_str);
                    break;

            }
        }).attach();

    }

ViewPager2 adapter :

public class ViewPagerAdapter extends FragmentStateAdapter {


    public ViewPagerAdapter(@NonNull FragmentActivity fragmentActivity) {
        super(fragmentActivity);
    }

    @NonNull
    @Override
    public Fragment createFragment(int position) {
        switch (position) {
            case 0:
                return new FinancialFragment();
            case 1:
                return new FinancialUnPaidFragment();
            case 2:
                return new FinancialPaidFragment();
            default:
                return null;

        }
    }

    @Override
    public int getItemCount() {
        return 3;
    }

dependency used:

implementation "androidx.viewpager2:viewpager2:1.0.0"
implementation 'com.google.android.material:material:1.1.0-alpha10'

How did you solve switching between tabs? For example when I chose 1 then 1 and 2 is loaded. Somehow skips from 1 to 2... — Josef, Dec 13 '21 at 20:01

Thracian · Answer 5 · 2020-09-24T05:26:07.203

How to use it explained very clearly. Let me give small but very crucial tips and details about ViewPager2 especially if it's inside a fragment about how to prevent memory leaks

Don't use the constructor that takes fragment especially if you are using TabLayout.

public FragmentStateAdapter(@NonNull Fragment fragment) {
    this(fragment.getChildFragmentManager(), fragment.getLifecycle());
}

because it has risk of memory leak as described here

instead use the one takes FragmentManager and LifeCycle. And don't send lifeCycle of fragment as argument, use viewLifeCycleOwner's lifecycle because viewLifeCycleOwner represents life cycle of fragment's view.

 class NavigableFragmentStateAdapter(
    fragmentManager: FragmentManager,
    lifecycle: Lifecycle
) : FragmentStateAdapter(fragmentManager, lifecycle) {


}

and set adapter with in onCreateView

viewPager.adapter =
            NavigableFragmentStateAdapter(childFragmentManager, viewLifecycleOwner.lifecycle)

If you are using TabLayout when ViewPager2 is inside a fragment do not forget to detach TabLayout and set adapter of ViewPager2 as

detach TabLayoutMediator since it causing memory leaks when it's in a fragment

https://stackoverflow.com/questions/61779776/leak-canary-detects-memory-leaks-for-tablayout-with-viewpager2

ViewPager2 inside a fragment leaks after replacing the fragment it's in by Navigation Component navigate

TabLayoutMediator(tabLayout, viewPager2, tabConfigurationStrategy).detach()
viewPager2.adapter = null

inside onDestroyView method of Fragment

If you wish to use pages of ViewPager as navHostFragment with navigation components to navigate back to child fragments register FragmentTransactionCallback in FragmentStateAdapter as

private val fragmentTransactionCallback =
    object : FragmentStateAdapter.FragmentTransactionCallback() {
        override fun onFragmentMaxLifecyclePreUpdated(
            fragment: Fragment,
            maxLifecycleState: Lifecycle.State
        ) = if (maxLifecycleState == Lifecycle.State.RESUMED) {

            // This fragment is becoming the active Fragment - set it to
            // the primary navigation fragment in the OnPostEventListener
            OnPostEventListener {
                fragment.parentFragmentManager.commitNow {
                    setPrimaryNavigationFragment(fragment)
                }
            }
        } else {
            super.onFragmentMaxLifecyclePreUpdated(fragment, maxLifecycleState)
        }
    }

init {
    // Add a FragmentTransactionCallback to handle changing
    // the primary navigation fragment
    registerFragmentTransactionCallback(fragmentTransactionCallback)
}

Also if you wish to see some samples how to use ViewPager2 with navigation components, dynamic feature modules and combining with BottomNavigationView you can check out the tutorials in this github repo.

Martin Zeitler · Answer 6 · 2021-12-11T23:08:45.373

Just in case one may want to listen for ViewPager2.OnPageChangeCallback events:

private final ViewPager2.OnPageChangeCallback onPageChangeListener = new ViewPager2.OnPageChangeCallback() {

    /**
     * This method will be invoked when the current page is scrolled, either as part
     * of a programmatically initiated smooth scroll or a user initiated touch scroll.
     * @param position             Position index of the first page currently being displayed.
     *                             Page position+1 will be visible if positionOffset is nonzero.
     * @param positionOffset       Value from [0, 1) indicating the offset from the page at position.
     * @param positionOffsetPixels Value in pixels indicating the offset from position.
     */
    @Override
    public void onPageScrolled(int position, float positionOffset, int positionOffsetPixels) {
        super.onPageScrolled(position, positionOffset, positionOffsetPixels);
    }

    /**
     * This method will be invoked when a new page becomes selected.
     * Animation is not necessarily complete.
     * @param position             Position index of the first page currently being displayed.
     *                             Page position+1 will be visible if positionOffset is nonzero.
     */
    @Override
    public void onPageSelected (int position) {
        super.onPageSelected(position);
        if (position == 2) { // SomeFragment
            Log.d(LOG_TAG, "ViewPager2.onPageSelected( " + position + " )");
            SomePagerAdapter adapter = (SomePagerAdapter) viewpager.getAdapter();
            if (adapter != null) {
                SomeFragment fragment = (SomeFragment) adapter.getItem(position);
                fragment.onLateInit();
            }
        }
    }
};

To be applied with ViewPager2.registerOnPageChangeCallback():

viewpager.registerOnPageChangeCallback(this.onPageChangeListener);

The FragmentStateAdapter needs to hold an ArrayList<Fragment> mItems, so that one can access the instances, which are being constructed ahead of time. SomeFragment exposes method public void onLateInit(), because @Override public void onViewCreated(@NonNull View view, @Nullable Bundle savedInstanceState) can possibly not be used (depends on the Fragment).

public Fragment getItem(int position) {
    return this.mItems.get(position);
}

Alike this one one work around the issue, what the Fragment is being constructed long before one might be able to properly initialize it's view, eg. with data entered in the previous one Fragment. It might not be the optimum for a large amount of Fragment (...), but for a few it works pretty well.

Amr · Answer 7 · 2022-01-03T23:13:36.347

here is kotlin version implementation of @sushildlh answer in Kotlin.
in this code I am implementing viewpager2 with recyclerview to view images. also i am using viewbinding

food_details.xml

<androidx.constraintlayout.widget.ConstraintLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    tools:context=".presentation.recipeitem.RecipeDetailsFragment">


    <androidx.viewpager2.widget.ViewPager2
        android:id="@+id/viewPager2"
        android:layout_width="0dp"
        android:layout_height="300dp"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintStart_toStartOf="parent"
        app:layout_constraintTop_toTopOf="parent"
        tools:src="@tools:sample/avatars" />
...

the fragment which inflates this xml

@AndroidEntryPoint
class RecipeDetailsFragment : Fragment(R.layout.fragment_recipe_details) {

private val viewModel: RecipeItemViewModel by viewModels()
private val viewBinding: FragmentRecipeDetailsBinding by viewBinding()

override fun onViewCreated(view: View, savedInstanceState: Bundle?) {
    super.onViewCreated(view, savedInstanceState)
    bindRecipeData(//object of data that is to be desplayed)
}

private fun bindRecipeData(recipeDetailedInfo: RecipeDetailedInfo?) {
    recipeDetailedInfo?.let {
        with(viewBinding) {
            viewPager2.adapter = ViewPagerAdapter(it.images)
            viewPager2.setPageTransformer(ZoomOutPageTransformer())
            lifecycleScope.launchWhenCreated {
                delay(500)
                viewPager2.setCurrentItem(if (it.images.size >= 2) 1 else 0, true)
            }
        }
    }
}....

in the fragment i am creating object of the adapter and sending directly list of strings that contains the images URLs

here is the viewpager adapter which is basically a normal recyclerview adapter

import android.view.LayoutInflater
import android.view.ViewGroup
import androidx.recyclerview.widget.RecyclerView
import com.blogspot.soyamr.recipes2.databinding.ImageviewBinding
import com.squareup.picasso.Picasso

class ViewPagerAdapter(private val images: List<String>) :
    RecyclerView.Adapter<ViewPagerAdapter.ImageViewHolder>() {


    class ImageViewHolder(private val imageViewBinding: ImageviewBinding) :
        RecyclerView.ViewHolder(imageViewBinding.root) {
        fun bind(imageLink: String) {
            Picasso.get().load(imageLink).into(imageViewBinding.root)
        }

        companion object {
            fun from(parent: ViewGroup): ImageViewHolder {
                val itemBinding =
                    ImageviewBinding.inflate(LayoutInflater.from(parent.context), parent, false)
                return ImageViewHolder(itemBinding)
            }
        }
    }

    override fun onCreateViewHolder(parent: ViewGroup, viewType: Int): ImageViewHolder {
        return ImageViewHolder.from(parent)
    }

    override fun onBindViewHolder(holder: ImageViewHolder, position: Int) {
        holder.bind(images[position])
    }

    override fun getItemCount(): Int = images.size

}

in the recyclerview i am inflating this imageview.xml

<?xml version="1.0" encoding="utf-8"?>
<com.google.android.material.imageview.ShapeableImageView xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="match_parent" android:layout_height="match_parent"
    android:scaleType="centerCrop"
    android:theme="@style/roundedImageView"
    />

you use your complex xml view if needed

EverCpp · Answer 8 · 2021-10-24T03:43:41.190

Simple example with two differente fragments, usin tabs. Main layout:

<?xml version="1.0" encoding="utf-8"?>
<androidx.constraintlayout.widget.ConstraintLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:id="@+id/mainConstraintLayout"
    android:layout_width="match_parent"
    android:layout_height="match_parent">

    <androidx.viewpager2.widget.ViewPager2
        android:id="@+id/mainViewPager"
        android:layout_width="match_parent"
        android:layout_height="0dp"
        app:layout_constraintBottom_toBottomOf="parent"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintStart_toStartOf="parent"
        app:layout_constraintTop_toBottomOf="@+id/mainTabLayout">

    </androidx.viewpager2.widget.ViewPager2>

    <com.google.android.material.tabs.TabLayout
        android:id="@+id/mainTabLayout"
        android:layout_width="match_parent"
        android:layout_height="@dimen/toolbar_height"
        android:background="@color/brown_normal"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintStart_toStartOf="parent"
        app:layout_constraintTop_toTopOf="parent"
        app:tabIndicatorColor="@color/yellow_light"
        app:tabIndicatorHeight="3dp"
        app:tabSelectedTextColor="@color/yellow_light"
        app:tabTextColor="@color/yellow_normal"
        tools:ignore="SpeakableTextPresentCheck" />
</androidx.constraintlayout.widget.ConstraintLayout>

Adapter:

public class MainToolsAdapter extends FragmentStateAdapter
{
    // The quantity of tab is fixed
    private static final int FRAGMENT_COUNT = 2;
    // Titles for each tab
    private final String[] titles = new String[FRAGMENT_COUNT];

    public MainToolsAdapter(@NonNull FragmentManager fragmentManager, @NonNull Lifecycle lifecycle, Context context)
    {
        super(fragmentManager, lifecycle);
        // Load titles for tab from resourses
        titles[0] = context.getResources().getString(R.string.tab_1);
        titles[1] = context.getResources().getString(R.string.tab_2);
    }

    @NonNull
    @Override
    public Fragment createFragment(int position)
    {
        // Create fragments according to position
        if(position == 0)
        {
            return new FragmentTabOne();
        }
        return new FragmentTabTwo();
    }

    @Override
    public int getItemCount()
    {
        return FRAGMENT_COUNT;
    }

    public String getItemTitle(int position)
    {
        if(position == 0)
        {
            return titles[0];
        }
        return titles[1];
    }
}

Main activity OnCreate:

@Override
protected void onCreate(Bundle savedInstanceState)
{
    super.onCreate(savedInstanceState);
    setContentView(R.layout.activity_main);

    // Create adapter for ViewPager
    mainToolsAdapter = new MainToolsAdapter(getSupportFragmentManager(), getLifecycle(), this);

    // Set adapter to the ViewPager
    viewPager = findViewById(R.id.mainViewPager);
    viewPager.setAdapter(mainToolsAdapter);

    tabLayout = findViewById(R.id.mainTabLayout);

    // Create the TabLayoutMediator to asociate ViewPager2 to TabLayout
    TabLayoutMediator tabLayoutMediator = new TabLayoutMediator(tabLayout, viewPager, true, new TabLayoutMediator.TabConfigurationStrategy()
    {
        @Override
        public void onConfigureTab(@NonNull TabLayout.Tab tab, int position)
        {
            // When a tab is created this is called, then we can set tab properties, in this case the text
            tab.setText(mainToolsAdapter.getItemTitle(position));
        }
    });
    // After configure we need to realice attach then Tab and ViewPager2 are asociated
    tabLayoutMediator.attach();
}

gradle:

plugins {
    id 'com.android.application'
}

android {
    compileSdk 30

    defaultConfig {
        applicationId "com.xxxx.yyyy"
        minSdk 19
        targetSdk 30
        versionCode 1
        versionName "1.0"

        testInstrumentationRunner "androidx.test.runner.AndroidJUnitRunner"
    }

    buildTypes {
        release {
            minifyEnabled false
            proguardFiles getDefaultProguardFile('proguard-android-optimize.txt'), 'proguard-rules.pro'
        }
    }
    compileOptions {
        sourceCompatibility JavaVersion.VERSION_1_8
        targetCompatibility JavaVersion.VERSION_1_8
    }
}

dependencies
{
    implementation fileTree(include: ['*.jar', '*.aar'], dir: 'libs')

    implementation 'androidx.appcompat:appcompat:1.3.1'
    implementation 'com.google.android.material:material:1.4.0'
    implementation 'androidx.constraintlayout:constraintlayout:2.1.1'
    testImplementation 'junit:junit:4.13.2'

    androidTestImplementation 'androidx.test.ext:junit:1.1.3'
    androidTestImplementation 'androidx.test.espresso:espresso-core:3.4.0'
}

That's quite a lot of code, with no explanation! Some comments and/or supporting text would be useful especially to help people understand, and derive their own solutions — Andrew, Oct 23 '21 at 10:01

Alexei · Answer 9 · 2019-10-23T16:49:05.677

Here my solution (Android Studio 3.6):

In app/build.gradle:

dependencies {
    implementation fileTree(dir: 'libs', include: ['*.jar'])
    implementation('com.crashlytics.sdk.android:crashlytics:2.10.1@aar') { transitive = true; }
    implementation 'androidx.appcompat:appcompat:1.1.0'
    implementation 'androidx.constraintlayout:constraintlayout:1.1.3'
    implementation 'com.google.android.material:material:1.1.0-beta01'
    implementation 'org.altbeacon:android-beacon-library:2.16.3'
    implementation 'androidx.localbroadcastmanager:localbroadcastmanager:1.0.0'
    implementation 'androidx.viewpager2:viewpager2:1.0.0-beta05'

    testImplementation 'junit:junit:4.12'
    androidTestImplementation 'androidx.test.ext:junit:1.1.1'
    androidTestImplementation 'androidx.test.espresso:espresso-core:3.2.0'
    implementation "androidx.core:core-ktx:+"
    implementation "org.jetbrains.kotlin:kotlin-stdlib-jdk7:$kotlin_version"
}

Here my activity:

import android.os.Bundle;

import androidx.annotation.Nullable;
import androidx.appcompat.app.AppCompatActivity;
import androidx.fragment.app.Fragment;
import androidx.viewpager2.widget.ViewPager2;

import java.util.ArrayList;
import java.util.List;

import com.myproject.android.R;
import com.myproject.android.adapter.CustomFragmentStateAdapter;
import com.myproject.android.ui.fragment.BluetoothPageFragment;
import com.myproject.android.ui.fragment.QrPageFragment;

public class QRBluetoothSwipeActivity extends AppCompatActivity {
    private ViewPager2 myViewPager2;
    private CustomFragmentStateAdapter myAdapter;

    @Override
    protected void onCreate(@Nullable Bundle savedInstanceState) {
        // Make sure this is before calling super.onCreate
        setTheme(R.style.AppTheme); // show splash screen
        super.onCreate(savedInstanceState);
        setContentView(R.layout.qr_bluetooth_swipe_activity);
        init();
    }

    private void init() {
        List<Fragment> fragmentList = new ArrayList<Fragment>();
        QrPageFragment m1 = new QrPageFragment();
        BluetoothPageFragment m2 = new BluetoothPageFragment();
        myViewPager2 = findViewById(R.id.viewPager2);
        fragmentList.add(m2);
        fragmentList.add(m1);
        myAdapter = new CustomFragmentStateAdapter(this, fragmentList);
        myViewPager2.setAdapter(myAdapter);
    }
}

Here layout:

<?xml version="1.0" encoding="utf-8"?>
<androidx.constraintlayout.widget.ConstraintLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    tools:context=".ui.actviity.SplashDelayActivity">

    <androidx.viewpager2.widget.ViewPager2
        android:id="@+id/viewPager2"
        android:layout_width="match_parent"
        android:layout_height="match_parent" />

</androidx.constraintlayout.widget.ConstraintLayout>

Here my CustomFragmentStateAdapter

import androidx.fragment.app.Fragment;
import androidx.fragment.app.FragmentActivity;
import androidx.viewpager2.adapter.FragmentStateAdapter;

import org.jetbrains.annotations.NotNull;

import java.util.ArrayList;
import java.util.List;

public class CustomFragmentStateAdapter extends FragmentStateAdapter {
    private List<Fragment> listFragment = new ArrayList<>();

    public CustomFragmentStateAdapter(FragmentActivity fa, List<Fragment> list) {
        super(fa);
        listFragment = list;
    }

    @NotNull
    @Override
    public Fragment createFragment(int position) {
        return listFragment.get(position);
    }

    @Override
    public int getItemCount() {
        return 2;
    }
}

And here my fragments:

import android.os.Bundle;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;

import androidx.annotation.Nullable;
import androidx.fragment.app.Fragment;

import com.myproject.android.R;

public class BluetoothPageFragment extends Fragment {

    @Nullable
    @Override
    public View onCreateView(LayoutInflater inflater, ViewGroup container, Bundle savedInstanceState) {
        return inflater.inflate(R.layout.bluetooth_page_fragment, container, false);
    }

}

and second fragment:

import android.os.Bundle;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;

import androidx.annotation.Nullable;
import androidx.fragment.app.Fragment;

import com.myproject.android.R;

public class QrPageFragment extends Fragment {

    @Nullable
    @Override
    public View onCreateView(LayoutInflater inflater, ViewGroup container, Bundle savedInstanceState) {
        return inflater.inflate(R.layout.qr_page_fragment, container, false);
    }

}

And as result now I use androidx.viewpager2.widget.ViewPager2 with my custom fragments.

And it's work!!!

Nice.

P.S. Another implement:

public class CustomFragmentStateAdapter extends FragmentStateAdapter {
    private ArrayList<Fragment> arrayList = new ArrayList<>();

    public CustomFragmentStateAdapter (FragmentActivity fa) {
        super(fa);
    }

    public void addFragment(Fragment fragment) {
        arrayList.add(fragment);
    }

    @Override
    public int getItemCount() {
        return arrayList.size();
    }

    @NonNull
    @Override
    public Fragment createFragment(int position) {
        // return your fragment that corresponds to this 'position'
        return arrayList.get(position);
    }
}

And use like this (in activity):

 myViewPager2 = findViewById(R.id.viewPager2);
        myAdapter = new CustomFragmentStateAdapter (this);
        myAdapter.addFragment(new QrPageFragment());
        myAdapter.addFragment(new BluetoothPageFragment());
        myViewPager2.setAdapter(myAdapter);

I have used it, with recyclerview of images inside FragmentPageAdapter and its too slow as a pig running with horses. — Gilberto Ibarra, Feb 26 '20 at 07:27
This is **not** correct. `createFragment` callback of the `FragmentStateAdapter` should (as the method says) **`create`** a `Fragment`. And not give a one that has already been created and is lying around. By using your approach you're messing up with `FragmentManager's` operation. — Bartek Lipinski, Mar 11 '20 at 16:46
@BartekLipinski. So how i "can dynamically modify the fragment collection at runtime, and ViewPager2 will correctly display the modified collection." as [documentation](https://developer.android.com/training/animation/vp2-migration#modifiable-fragments) say? — ramaral, May 08 '20 at 14:03
@BartekLipinski, I created a list of 4 fragments and then in `createFragment` returned an item by position. Everything works as expected, no need to recreate a fragment each time. But the adapter is called this way: `val adapter = object : FragmentStateAdapter(childFragmentManager, viewLifecycleOwner.lifecycle)`. — CoolMind, Jan 15 '23 at 23:44
Just the fact that it "works as expected", doesn't mean that it "works as it should". `FragmentManager` is quite a complex piece of machinery (~4k lines of code) and by not following its API, you **might** experience some edge-cases and uncertain behavior. — Bartek Lipinski, Jan 16 '23 at 16:13
I am doin the same but I noticed some duplication of fragment on orientation change if I use viewpager.setCurrentItem(savedIndex) in onCreate() . Did anyone face this problem? — Muhammad Hanzilah, Apr 14 '23 at 11:38

score 0 · Answer 10 · answered Dec 24 '20 at 14:13

0

I first created a view pager, then migrated to view pager 2 using the instructions given in: https://developer.android.com/training/animation/vp2-migration

answered Dec 24 '20 at 14:13

Sociopath

15
4

score 0 · Answer 11 · answered Feb 11 '21 at 14:59

This is the correct implementation!

typealias FragmentBuilder = () -> Fragment

class MyAdapter(
    fragmentManager: FragmentManager,
    lifecycle: Lifecycle
) : FragmentStateAdapter(fragmentManager, lifecycle) {

    private val fragmentBuilders = mutableListOf<FragmentBuilder>()

    fun add(fragmentBuilder: FragmentBuilder) {
        fragmentBuilders.add(fragmentBuilder)
    }

    /**
     * Dynamic replacement of fragments
     */
    fun set(position: Int, fragmentBuilder: FragmentBuilder) {
        fragmentBuilders[position] = fragmentBuilder
    }

    override fun getItemCount() = fragmentBuilders.size

    override fun createFragment(position: Int) = fragmentBuilders[position].invoke()

}

Don't even thank)

can u help me with lifecycle implementation as I am not able to find any resource regarding handling lifecycles..... — Mohit Yadav, Jul 06 '21 at 15:33

score 0 · Answer 12 · answered Feb 23 '23 at 13:10

In Kotlin FragmentStateAdapter with ViewPager2 The primary reason to migrate is that ViewPager2 is receiving active development support and ViewPager is not. However, ViewPager2 also offers several other specific advantages. FragmentStateAdapter in ViewPager2 is a little bit different than in ViewPager as follows: 1] Instead of implementing getCount(), implement getItemCount() 2] Instead of implementing getItem(int position), implement createFragment(int position) 3] Constructor signature is different by adding Lifecycle argument which should be included in super as well So replace your ViewPagerFragmentAdapter with below

Kotlin PagerAdapter

class SurveyPagerAdapter(
private val fragmentList: MutableList< Fragment>,
fragment: FragmentManager,
lifecycle: Lifecycle) : FragmentStateAdapter(fragment,lifecycle){
override fun getItemCount(): Int = fragmentList.size
override fun createFragment(position: Int): Fragment {
    return fragmentList[position]
}
fun getFragmentName(position: Int) = fragmentList[position]
fun addFragment(fragment: Fragment) {
    fragmentList.add(fragment)
    notifyDataSetChanged()
}}

Kotlin Activity *Just put on method in onCreate() *

private fun setUpViewPager(){

    val fragmentList : MutableList< Fragment> = mutableListOf()
    fragmentList.add(SurveyPageOneFragment.newInstance(true))
    fragmentList.add(SurveyPageTwoFragment.newInstance(true))
    fragmentList.add(SurveyPageThreeFragment.newInstance(true))
    fragmentList.add(SurveyPageFourFragment.newInstance(true))
    fragmentList.add(SurveyPageFiveFragment.newInstance(true))

    surveyPagerAdapter = SurveyPagerAdapter(fragmentList,supportFragmentManager,lifecycle)
    binding.viewPager.adapter = surveyPagerAdapter
    binding.dotsIndicator.attachTo(binding.viewPager)

}

Kotlin Fragment

class SurveyPageOneFragment : Fragment() {
override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    arguments?.let {
    }
}
override fun onCreateView(
    inflater: LayoutInflater, container: ViewGroup?,
    savedInstanceState: Bundle?
): View? {
    return inflater.inflate(R.layout.fragment_survey_page_one, container, false)
}
companion object {
    @JvmStatic
    fun newInstance(isMyBoolean: Boolean) = SurveyPageOneFragment().apply {
        val fragment = SurveyPageOneFragment()
        arguments = Bundle().apply {
            putBoolean("REPLACE WITH A STRING CONSTANT", isMyBoolean)
        }
        fragment.arguments
        return fragment
    }
}}

xml code in viewPager2

<androidx.viewpager2.widget.ViewPager2
                android:id="@+id/view_pager"
                android:layout_width="match_parent"
                android:layout_height="match_parent"
                android:layoutDirection="ltr"/>

Dot indicator lib//kotlin dot indicator implementation 'com.tbuonomo:dotsindicator:4.3'

<com.tbuonomo.viewpagerdotsindicator.DotsIndicator
                android:id="@+id/dots_indicator"
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                app:dotsColor="@color/colorSurveyEditGreenLight"
                app:dotsCornerRadius="8dp"
                app:dotsSize="16dp"
                app:dotsSpacing="4dp"
                app:dotsWidthFactor="2.5"
                app:selectedDotColor="@color/white"
                app:progressMode="true"
                />

Papa Yev · Answer 13 · 2022-05-01T16:19:25.853

I personally used ViewPager2 inside of a Fragment. This is how I do it. Example code on GitHub [https://github.com/codebyjames/Example-Using-ViewPager2-Slide-Page-Adapter]

First in onCreate

        // pager adapter
        val pagerAdapter = ScreenSlidePageAdapter(this@ManagerFragment)
        viewPager.adapter = pagerAdapter
        viewPager.setPageTransformer(ZoomOutPageTransformer())

Adapter for the ViewPager

class ScreenSlidePageAdapter(val fragment: Fragment): FragmentStateAdapter(fragment) {

val fragments = listOf(WalkThroughFragment(), PermissionsFragment(), DatastoreFragment())

override fun getItemCount(): Int {
    return fragments.size
}

override fun createFragment(position: Int): Fragment {
    return fragments[position]
}

}

Transformation for ViewPager2 - optional

class ZoomOutPageTransformer : ViewPager2.PageTransformer {

override fun transformPage(view: View, position: Float) {
    view.apply {
        val pageWidth = width
        val pageHeight = height
        when {
            position < -1 -> { // [-Infinity,-1)
                // This page is way off-screen to the left.
                alpha = 0f
            }
            position <= 1 -> { // [-1,1]
                // Modify the default slide transition to shrink the page as well
                val scaleFactor = Math.max(MIN_SCALE, 1 - Math.abs(position))
                val vertMargin = pageHeight * (1 - scaleFactor) / 2
                val horzMargin = pageWidth * (1 - scaleFactor) / 2
                translationX = if (position < 0) {
                    horzMargin - vertMargin / 2
                } else {
                    horzMargin + vertMargin / 2
                }

                // Scale the page down (between MIN_SCALE and 1)
                scaleX = scaleFactor
                scaleY = scaleFactor

                // Fade the page relative to its size.
                alpha = (MIN_ALPHA +
                        (((scaleFactor - MIN_SCALE) / (1 - MIN_SCALE)) * (1 - MIN_ALPHA)))
            }
            else -> { // (1,+Infinity]
                // This page is way off-screen to the right.
                alpha = 0f
            }
        }
    }
}

}

My ManagerFragment layout (which contains the ViewPager2)

<androidx.viewpager2.widget.ViewPager2
    android:id="@+id/viewPager"
    android:layout_width="match_parent"
    android:layout_height="match_parent" />

Proper implementation of ViewPager2 in Android

13 Answers13

UPDATE 7

UPDATE 6

UPDATE 5

New features

UPDATE

Try this if you want to use `Fragment` with `ViewPager2`

UPDATE 2

UPDATE 3

UPDATE 4

Linked

Related

Proper implementation of ViewPager2 in Android

13 Answers13

UPDATE 7

UPDATE 6

UPDATE 5

New features

UPDATE

Try this if you want to use Fragment with ViewPager2

UPDATE 2

UPDATE 3

UPDATE 4

Linked

Related

Try this if you want to use `Fragment` with `ViewPager2`
