How to capture whole Barcode value on Winform without using TextChanged event?

Question

When a barcode is scanned on form1, I make a call to database to get the item for this barcode and open form2 with pre-populated data.

If I use text changed event then it makes as many times as numbers in one barcode.

I cannot check length of the barcode as it may be different each time.

which event I should use to make only one call when Barcode is scanned?

I tried TextChanged, KeyPress, KeyDown events but they all are being called multiple times.

    private void txt_Barcode_TextChanged(object sender, EventArgs e)
    {
        con.Open();
        GenerateInvoice gn = new GenerateInvoice();
        string query = "SELECT * FROM dbo.Inventory WHERE Barcode = '" + txt_Barcode.Text + "' ";

        SqlCommand cmd = new SqlCommand(query, con);
        SqlDataReader dr = cmd.ExecuteReader();


        while (DR1.Read())
        {
            gn.txt_Barcode.Text = dr["Barcode"].ToString();
            gn.txt_ProductName.Text = dr["ProductName"].ToString();
            gn.txt_Price.Text = dr["SellingPrice"].ToString();
            gn.txt_QTY.Text = 1.ToString();
            gn.txt_Total.Text = dr["SellingPrice"].ToString();

        }
        con.Close();
    }

I am open to use textbox to capture barcode on form1 (I will hide it on UI)

A barcode scanner sends an Enter key when the code is complete. Plus, most scanners can be configured to also send a prefix, a suffix or both along with the barcode (to identify the scanner that sent the barcode, for example). Use the KeyDown event. E.g., `if (e.KeyCode == Keys.Enter) { e.SuppressKeyPress = true; //( process) }` — Jimi, Mar 29 '19 at 05:10
Also, your code's sql side leaves a bit to be desired. Get rid of the hard-coded query, use parameterization, look into proper resource cleanup with `using()` blocks. — Tanveer Badar, Mar 29 '19 at 05:17
As you are using the barcode scanner like a keyboard and ideally only want to fire the event once you could look at this: (debouncing and throttling) https://stackoverflow.com/questions/25991367/difference-between-throttling-and-debouncing-a-function — Bacon, Mar 29 '19 at 07:52

TheGeneral · Answer 1 · 2019-03-29T21:08:00.837

This is a result of the scanner in WedgeMode. basically it acts as a keyboard and every character scanned creates a text changed event.

There are many solves.

You could use an api supplied by the company you bought the scanner off, instead of wedgemode

However, a simple solve is to put a prefix and suffix (like the ascii codes, STX and ETX ) on the scanner (there are usually settings for this supplied by the scanner), that way you know when you have complete bar-code data.

When you see a valid barcode, then you make one event, not an event for each character scanned.

Jeremy Thompson · Answer 2 · 2019-03-29T08:00:01.373

You'll probably see a few of my answers on this topic.

Improve Barcode search in a Textbox C#

distinguish between the scanner and the keyboard

Barcode scanner with a WPF application

If I was to do it again and the first time was a long time ago, I'd opt for RawInput's and determine which device is the BarCode scanner. Using prefix and suffix are reliable although they vary depending on the device. Capturing the raw input abstracts this hardware implementation.

Code Project article and download: Using Raw Input from C# to handle multiple keyboards

See how I can get input from any source so I dont even need the user to put a cursor on a textbox or use Form.KeyPreview I can get the input filtered by device.

score 0 · Answer 3 · answered Mar 29 '19 at 06:02

You could try to let the event wait for 1 second, or long enough to finish scanning

private async void txt_Barcode_TextChanged(object sender, EventArgs e)
{
    await Task.Delay(1000);
    con.Open();
    GenerateInvoice gn = new GenerateInvoice();
    string query = "SELECT * FROM dbo.Inventory WHERE Barcode = '" + txt_Barcode.Text + "' ";

    SqlCommand cmd = new SqlCommand(query, con);
    SqlDataReader dr = cmd.ExecuteReader();


    while (DR1.Read())
    {
        gn.txt_Barcode.Text = dr["Barcode"].ToString();
        gn.txt_ProductName.Text = dr["ProductName"].ToString();
        gn.txt_Price.Text = dr["SellingPrice"].ToString();
        gn.txt_QTY.Text = 1.ToString();
        gn.txt_Total.Text = dr["SellingPrice"].ToString();

    }
    con.Close();
}

While this will work it will fire a dB call every text change event and sometimes the barcode input gets cut off, best to at least test the length of txt_Barcode before the dB call. — Jeremy Thompson, Feb 07 '23 at 23:19
