Specify correlation between varying intercepts with same level in different groups

Question

Say I have 2 factor variables foo and bar which both contain the same levels "a", "b", and "c". Is there any way to specify in lme4 (or any other package) a model with random intercepts for foo and bar with correlation between intercepts with the same level? In other words, I think the effect of "a" in foo should be correlated with "a" in bar (similar for "b" and "c"). Formally, this might look something like:

for each level k in ["a", "b", "c"].

Here is some code which estimates sigma^2_foo and sigma^2_bar:

library(lme4)

levs <- c("a", "b", "c")
n <- 1000

df <- data.frame(y = rpois(n, 3.14),
                 foo = sample(levs, n, TRUE),
                 bar = sample(levs, n, TRUE))

mod <- glmer(y ~ (1 | foo) + (1 | bar), df, poisson)

> mod
Formula: y ~ (1 | foo) + (1 | bar)
Random effects:
 Groups Name        Std.Dev.
 foo    (Intercept) 0.009668
 bar    (Intercept) 0.006739

but of course misses the correlation term rho. Is it possible to add this correlation structure to this model?

UPDATE

In hope that it is helpful to people who are familiar with Stan, in Stan a basic implementation of this random effects model would look like this:

data {
    int<lower = 1> num_data;
    int<lower = 1> num_levels;

    int<lower = 0> y[num_data];

    int<lower = 1, upper = num_levels> foo_ix[num_data];
    int<lower = 1, upper = num_levels> bar_ix[num_data];
}

parameters {
    real alpha;

    vector[num_levels] alpha_foo;
    vector[num_levels] alpha_bar;

    real<lower = 0.0> sigma_foo;
    real<lower = 0.0> sigma_bar;

    real<lower = -1.0, upper = 1.0> rho;
}

transformed parameters {
    matrix[2, 2] Sigma;
    Sigma[1, 1] = square(sigma_foo);
    Sigma[2, 1] = rho * sigma_foo * sigma_bar;
    Sigma[1, 2] = rho * sigma_foo * sigma_bar;
    Sigma[2, 2] = square(sigma_bar);
}

model {
    for (i in 1:num_levels) {
        [alpha_foo[i], alpha_bar[i]] ~ multi_normal([0.0, 0.0], Sigma);
    }

    y ~ poisson_log(alpha + alpha_foo[foo_ix] + alpha_bar[bar_ix]);
}

Answer 1

Your model does not have fixed effects and that's why you don't get the correlation matrix. According to your description, you are referring to an interaction between foo and bar at some levels. To add such interaction, you need to add the foo:bar term to the model as a fixed effect, as follows:

mod <- glmer(y ~ (1 | foo) + (1 | bar) + foo:bar, df, poisson)
summary(mod)

This will give the following output:

Generalized linear mixed model fit by maximum likelihood (Laplace Approximation) [glmerMod]
 Family: poisson  ( log )
Formula: y ~ (1 | foo) + (1 | bar) + foo:bar
   Data: df

     AIC      BIC   logLik deviance df.resid
  3962.1   4016.1  -1970.1   3940.1      989

Scaled residuals:
    Min      1Q  Median      3Q     Max
-1.8572 -0.6665 -0.0947  0.5406  3.8695

Random effects:
 Groups Name        Variance Std.Dev.
 foo    (Intercept) 0        0
 bar    (Intercept) 0        0
Number of obs: 1000, groups:  foo, 3; bar, 3

Fixed effects:
            Estimate Std. Error z value Pr(>|z|)
(Intercept)  1.07131    0.05882  18.212   <2e-16 ***
fooa:bara    0.16682    0.07692   2.169   0.0301 *
foob:bara    0.04549    0.08039   0.566   0.5715
fooc:bara   -0.08801    0.08464  -1.040   0.2984
fooa:barb    0.08196    0.08370   0.979   0.3275
foob:barb    0.05421    0.08006   0.677   0.4983
fooc:barb    0.08886    0.07712   1.152   0.2492
fooa:barc   -0.02109    0.07884  -0.268   0.7891
foob:barc    0.12437    0.07720   1.611   0.1072
---
Signif. codes:  0 ‘***’ 0.001 ‘**’ 0.01 ‘*’ 0.05 ‘.’ 0.1 ‘ ’ 1

Correlation of Fixed Effects:
          (Intr) foo:br fob:br foc:br fo:brb fb:brb fc:brb fo:brc
fooa:bara -0.765
foob:bara -0.732  0.560
fooc:bara -0.695  0.531  0.509
fooa:barb -0.703  0.537  0.514  0.488
foob:barb -0.735  0.562  0.538  0.511  0.516
fooc:barb -0.763  0.583  0.558  0.530  0.536  0.560
fooa:barc -0.746  0.571  0.546  0.519  0.524  0.548  0.569
foob:barc -0.762  0.583  0.558  0.530  0.535  0.560  0.581  0.569

Of course, as you might have seen, the interaction here happens between all the levels together (not conditioned as you desire). I hope you can obtain my answer as an initial step to get your desired solution. I'll also try to figure it out for you and will update my answer once I find something useful. My first impression is that you need to modify your dataframe in a way that you can control the interactions between same-level intercepts.

---

[UPDATE]

You can add an interaction variable manually, something like the following:

df <- transform(df,foo_bar.inter=interaction(foo,bar, sep = ":"))

and then you may keep only a with a, b with b, and c with c as follows:

df$foo_bar.inter[df$foo != df$bar] <- NA

You may give it a try and let me know if you need any further help.

Best of luck.
