I am not asking what is null pointer exception here.I have debugged the project and saw where my null pointer is coming.My flow for project is:
My Api is:
package com.cache.api;
@Path("/myresource")
public class MyResource  {
    @Inject
    private CacheHelper cacheHelper;
    @Inject
    private DtoPlan dtoPlan;
    @GET
    @Path("/putAllInDto")
    @Produces(MediaType.APPLICATION_JSON)
    public String putAllInDto() throws Exception {
       CachePlan cf=CacheFactory.getPlan(PlanChooser.DTO);
       cf.putInCache(); //data are loaded in DtoPlanImpl Class
        MemberDTO md=cf.getMemberDtos();  //data comes from here with cf object
    //    MemberDTO md1=dtoPlan.getMemberDto();  //java.lang.NullPointerException when I use dtoPlan.memberDto();
//
//        System.out.println(md.getMemberName());
        return "insertedindto";
    }
}
The cachePlan interface is:
package com.cache.plan;
    public interface CachePlan {
        public  void putInCache() throws ExecutionException, InterruptedException ;
        public MemberDTO getMemberDtos() throws ExecutionException, InterruptedException ;
        }
My DtoPlanImpl.java class is.Here I needed to implement new interface DtoPlan.
package com.cache.impl;
    @Stateless
    public class DtoPlanImpl implements CachePlan,DtoPlan
    {
        private CacheManager cacheManager;
        private Cache<String,MemberDTO> memberCache;
        private static final String CACHE_MEMBER_DTO_PARAMETER="cache_member_dto_type";
        private MemberService memberService = CDI.current().select(MemberService.class).get();
        public DtoPlanImpl(){
            System.getProperties().setProperty("java -Dnet.sf.ehcache.use.classic.lru", "true");
            cacheManager= CacheManagerBuilder
                    .newCacheManagerBuilder().build();
            cacheManager.init();
        }
        @Override
        public void putInCache()  {
            System.out.println("putting data from dto");
            memberCache = cacheManager
                    .createCache("cacheOfMemberCache", CacheConfigurationBuilder
                            .newCacheConfigurationBuilder(
                                    String.class,MemberDTO.class,
                                    ResourcePoolsBuilder.heap(1000000000)).withExpiry(Expirations.timeToLiveExpiration
                                    (Duration.of(60000,
                                    TimeUnit.SECONDS))));
            memberCache.put(CACHE_MEMBER_DTO_PARAMETER,memberService.getMemberDTO());
            MemberDTO mD=memberCache.get(CACHE_MEMBER_DTO_PARAMETER);
            System.out.println(mD.getMemberName());
         }
        @Override
        public MemberDTO getMemberDtos() {
            MemberDTO mD=memberCache.get(CACHE_MEMBER_DTO_PARAMETER);
            return mD;
        }
        @Override
        public MemberDTO getMemberDto() throws ExecutionException, InterruptedException {
            MemberDTO mD=memberCache.get(CACHE_MEMBER_DTO_PARAMETER);
             return mD;
        }
    }
My DtoPlan interface is:
public interface DtoPlan {
    public MemberDTO getMemberDto() throws ExecutionException, InterruptedException;
}
So what is the problem is that when i use CacheFactory cf as:
MemberDTO md=cf.getMemberDtos();  //data comes from here with cf object
But when I use:
 MemberDTO md1=dtoPlan.getMemberDto();  //java.lang.NullPointerException
I debugged the program and visualized from where the null pointer excpetion is coming:
Its coming from this Class DtoPlanImpl at line  MemberDTO mD=memberCache.get(CACHE_MEMBER_DTO_PARAMETER);:
@Override
    public MemberDTO getMemberDto() throws ExecutionException, InterruptedException {
        MemberDTO mD=memberCache.get(CACHE_MEMBER_DTO_PARAMETER);
         return mD;
    }
The memberCache is being null here where I call from dtoPlan.getMemberDto();, but when I call from cf.getMemberDtos();,I am getting data.
