ggplot: Stacked Barplot - geom_text labels messy

Question

I have grouped my data as desired and added up the quantities correctly.

Now I want to create a stacked bar plot in in which I would like to display the labels per Unit.

The summarized data looks like this:

To read it in R:

df <- structure(list(date = structure(c(17785, 17785, 17785, 17785,
17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785,
17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785,
17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785,
17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785,
17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785,
17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785,
17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785,
17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785,
17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785,
17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785,
17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785,
17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785,
17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785,
17785, 17785, 17785, 17785), class = "Date"), hour = structure(c(5L,
5L, 5L, 5L, 5L, 5L, 5L, 5L, 6L, 6L, 6L, 6L, 6L, 6L, 6L, 6L, 6L,
7L, 7L, 7L, 7L, 7L, 7L, 7L, 7L, 7L, 7L, 8L, 8L, 8L, 8L, 8L, 8L,
8L, 8L, 8L, 9L, 9L, 9L, 9L, 9L, 9L, 9L, 9L, 9L, 9L, 9L, 9L, 9L,
10L, 10L, 10L, 11L, 11L, 11L, 11L, 11L, 11L, 11L, 11L, 11L, 11L,
11L, 11L, 12L, 12L, 12L, 12L, 12L, 12L, 12L, 12L, 12L, 12L, 12L,
12L, 12L, 12L, 12L, 13L, 13L, 13L, 13L, 13L, 13L, 13L, 13L, 13L,
13L, 13L, 13L, 13L, 13L, 13L, 13L, 14L, 14L, 14L, 14L, 14L, 14L,
14L, 14L, 14L, 14L, 14L, 14L, 14L, 14L, 15L, 15L, 15L, 15L, 15L,
15L, 15L, 15L, 15L, 15L, 15L, 15L, 16L, 16L, 16L, 16L), .Label = c("00",
"02", "07", "08", "09", "10", "11", "12", "13", "14", "15", "16",
"17", "18", "19", "20", "21", "22"), class = "factor"), lGroup = structure(c(3L,
3L, 3L, 3L, 4L, 5L, 6L, 6L, 3L, 3L, 3L, 3L, 5L, 6L, 6L, 9L, 9L,
3L, 3L, 3L, 6L, 6L, 6L, 9L, 9L, 9L, 9L, 3L, 3L, 3L, 6L, 9L, 9L,
9L, 9L, 9L, 3L, 3L, 3L, 3L, 3L, 5L, 6L, 6L, 6L, 9L, 9L, 9L, 9L,
5L, 6L, 6L, 3L, 3L, 3L, 3L, 3L, 3L, 4L, 5L, 6L, 9L, 9L, 9L, 3L,
3L, 3L, 3L, 4L, 5L, 6L, 6L, 6L, 8L, 8L, 9L, 9L, 9L, 9L, 2L, 3L,
3L, 3L, 3L, 3L, 4L, 4L, 5L, 6L, 8L, 9L, 9L, 9L, 9L, 9L, 3L, 3L,
3L, 3L, 3L, 4L, 4L, 5L, 6L, 6L, 6L, 6L, 9L, 9L, 3L, 3L, 3L, 3L,
3L, 3L, 6L, 6L, 9L, 9L, 9L, 9L, 3L, 3L, 3L, 3L), .Label = c("AHX",
"A1", "A3", "B1", "C1", "C3", "E1", "E3", "E5", "Andere"), class = "factor"),
    unit = structure(c(2L, 3L, 5L, 6L, 3L, 3L, 3L, 5L, 3L, 5L,
    6L, 8L, 3L, 3L, 7L, 2L, 6L, 2L, 3L, 6L, 3L, 5L, 7L, 3L, 4L,
    5L, 6L, 3L, 5L, 6L, 3L, 2L, 3L, 4L, 5L, 6L, 3L, 5L, 6L, 8L,
    9L, 3L, 2L, 3L, 5L, 2L, 5L, 6L, 9L, 3L, 3L, 5L, 2L, 3L, 5L,
    6L, 8L, 9L, 3L, 3L, 3L, 2L, 4L, 6L, 2L, 3L, 5L, 6L, 3L, 3L,
    3L, 5L, 7L, 3L, 9L, 3L, 4L, 5L, 6L, 5L, 2L, 3L, 5L, 6L, 8L,
    3L, 4L, 3L, 3L, 3L, 2L, 3L, 4L, 6L, 9L, 3L, 5L, 6L, 7L, 8L,
    3L, 4L, 3L, 2L, 3L, 5L, 7L, 2L, 6L, 2L, 3L, 5L, 6L, 8L, 9L,
    3L, 7L, 2L, 4L, 5L, 6L, 3L, 5L, 6L, 9L), .Label = c("Andere",
    "Einzelartikel", "Bund", "BundGroesser6m", "EuroPal", "Pack",
    "Verschlag", "Rinnentransportkasten", "Sack"), class = "factor"),
    values = c(1, 1, 1, 7, 1, 2, 1, 1, 6, 3, 15, 1, 3, 3, 1,
    2, 2, 1, 9, 14, 3, 1, 1, 2, 1, 2, 1, 1, 2, 11, 1, 4, 1, 1,
    1, 6, 5, 2, 16, 1, 3, 3, 2, 11, 3, 2, 2, 1, 1, 1, 1, 1, 1,
    4, 2, 17, 1, 2, 2, 3, 7, 5, 2, 3, 1, 8, 1, 32, 4, 2, 1, 6,
    2, 1, 1, 2, 1, 1, 1, 4, 1, 5, 10, 33, 1, 9, 2, 2, 7, 2, 6,
    2, 3, 10, 2, 13, 8, 24, 1, 2, 5, 1, 7, 1, 13, 1, 1, 3, 4,
    3, 11, 7, 11, 3, 2, 1, 4, 2, 1, 2, 1, 7, 1, 7, 3)), row.names = c(NA,
-125L), class = c("grouped_df", "tbl_df", "tbl", "data.frame"
), groups = structure(list(date = structure(c(17785, 17785, 17785,
17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785,
17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785,
17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785,
17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785,
17785, 17785, 17785, 17785, 17785, 17785, 17785, 17785), class = "Date"),
    hour = structure(c(5L, 5L, 5L, 5L, 6L, 6L, 6L, 6L, 7L, 7L,
    7L, 8L, 8L, 8L, 9L, 9L, 9L, 9L, 10L, 10L, 11L, 11L, 11L,
    11L, 11L, 12L, 12L, 12L, 12L, 12L, 12L, 13L, 13L, 13L, 13L,
    13L, 13L, 13L, 14L, 14L, 14L, 14L, 14L, 15L, 15L, 15L, 16L
    ), .Label = c("00", "02", "07", "08", "09", "10", "11", "12",
    "13", "14", "15", "16", "17", "18", "19", "20", "21", "22"
    ), class = "factor"), lGroup = structure(c(3L, 4L, 5L, 6L,
    3L, 5L, 6L, 9L, 3L, 6L, 9L, 3L, 6L, 9L, 3L, 5L, 6L, 9L, 5L,
    6L, 3L, 4L, 5L, 6L, 9L, 3L, 4L, 5L, 6L, 8L, 9L, 2L, 3L, 4L,
    5L, 6L, 8L, 9L, 3L, 4L, 5L, 6L, 9L, 3L, 6L, 9L, 3L), .Label = c("AHX",
    "A1", "A3", "B1", "C1", "C3", "E1", "E3", "E5", "Andere"), class = "factor"),
    .rows = list(1:4, 5L, 6L, 7:8, 9:12, 13L, 14:15, 16:17, 18:20,
        21:23, 24:27, 28:30, 31L, 32:36, 37:41, 42L, 43:45, 46:49,
        50L, 51:52, 53:58, 59L, 60L, 61L, 62:64, 65:68, 69L,
        70L, 71:73, 74:75, 76:79, 80L, 81:85, 86:87, 88L, 89L,
        90L, 91:95, 96:100, 101:102, 103L, 104:107, 108:109,
        110:115, 116:117, 118:121, 122:125)), row.names = c(NA,
-47L), class = c("tbl_df", "tbl", "data.frame"), .drop = TRUE))

for my stacked barplot i use (among other things) this code:

ggplot(df, aes(x = hour, y = values, fill = unit, label = values)) +
  geom_bar(stat = "identity") +
  geom_text(stat = "identity", check_overlap = TRUE, hjust = -.2)

Which results in this:

Alternatively, I have already tried the following:

ggplot(df, aes(x = hour, y = values, fill = unit, label = values)) +
  geom_col(aes(fill = unit)) +
  geom_text(aes(label = values), position = position_stack(0.5))

which gives me an even worse result...

The result should look like this (here my polished plot manually filled with values for the larger units via powerpoint...)

Any suggestions on how I can fix this?

s__ · Answer 1 · 2019-11-14T07:55:44.130

You've to work before with your data a bit:

library(tidyverse)
library(RColorBrewer) # optional to have the palette red-blue

df %>%
    # group them
    group_by(hour, unit) %>%
    # summarise
    summarise(values = sum(values)) %>%
  ggplot( aes(x = hour, y = values, fill = unit, label = values)) +
  geom_bar(stat = "identity")  +
  geom_text(size = 3, position = position_stack(vjust = 0.5))+
  # here the option for the blue-red palette and light background
  scale_fill_manual(values = colorRampPalette(brewer.pal(11,"RdBu"))(8)) + theme_light() +
  # this is going to put the legend at the bottom
  theme(legend.position="bottom", legend.box = "horizontal") +
  # this is going to change the title legend, hoping not have made any mistake!
  guides(fill=guide_legend(title="Lagereinheiten"))

Ah, I'll have to group it up again and sum it up. Make sense, thank you! — fuul, Nov 14 '19 at 08:31
