geom_bar not displaying mean values

Question

I'm currently trying to plot mean values of a variable pt for each combination of species/treatments in my experiments. This is the code I'm using:

ggplot(data = data, aes(x=treat, y=pt, fill=species)) +
 geom_bar(position = "dodge", stat="identity") +
 labs(x = "Treatment",
      y = "Proportion of Beetles on Treated Side",
      colour = "Species") +
 theme(legend.position = "right")

As you can see, the plot seems to assume the mean of my 5N and 95E treatments are 1.00, which isn't correct. I have no idea where the problem could be here.

Welcome to Stack Overflow! You should provide a [reproducible example](https://stackoverflow.com/questions/5963269/how-to-make-a-great-r-reproducible-example) — M--, Jan 21 '20 at 18:09
@akash87 [link](https://1drv.ms/u/s!AjSCWBxDTEdkyy7Vv0YsCpFbge6q?e=OAKHk1) is the dataset — Sam Marchetti, Jan 21 '20 at 18:19
The link in @M--'s comment has suggestions for how to include a sample of data in the post rather than at a third party site — camille, Jan 21 '20 at 18:22

score 1 · Accepted Answer · answered Jan 21 '20 at 18:40

Took a stab at what you are asking using tidyverse and ggplot2 which is in tidyverse.

dat %>%
  group_by(treat, species) %>%
  summarise(mean_pt = mean(pt)) %>%
  ungroup() %>%
  ggplot(aes(x = treat, y = mean_pt, fill = species, group = species)) +
  geom_bar(position = "dodge", stat = "identity")+
  labs(x = "Treatment",
       y = "Proportion of Beetles on Treated Side",
       colour = "Species") +
  theme(legend.position = "right") +
  geom_text(aes(label = round(mean_pt, 3)), size = 3, hjust = 0.5, vjust = 3, position =  position_dodge(width = 1))

dat is the actual dataset. and I calculated the mean_pt as that is what you are trying to plot. I also added a geom_text piece just so you can see what the results were and compare them to your thoughts.

score 0 · Answer 2 · answered Jan 21 '20 at 18:39

From my understanding, this won't plot the means of your y variable by default. Have you calculated the means for each treatment? If not, I'd recommend adding a column to your dataframe that contains the mean. I'm sure there's an easier way to do this, but try:

data$means <- rep(NA, nrow(data))
for (x in 1:nrow(data)) {
    #assuming "treat" column is column #1 in your data fram
    data[x,ncol(data)] <- mean(which(data[,1]==data[x,1]))
}

Then try replacing

geom_bar(position = "dodge", stat="identity")

with

geom_col(position = "dodge")

If your y variable already contains means, simply switching geom_bar to geom_col as shown should work. Geom_bar with stat = "identity" will sum the values rather than return the mean.
