Sticky header no event scroll on the content using Angular

Question

I'm trying to set two sticky divs (one header, one sidenav) using Angular Material. Sticky divs works except from scrolling event when I scroll down into my content.

And when I scroll down, I have something like this :

My problem is : When I scroll down, I haven't any scroll event from Angular. If I change style.scss file by setting a value to height css property, all sticky div doesn't work anymore BUT I have my scroll event from Angular.

It's getting to my nerve :( Any idea to solve this problem ? Thank you very much !

style.scss

html, body {
    min-height: auto; // sticky header doesn't work but scroll event Angular OK
    // height: 100%; // sticky header works but scroll event Angular NOK
}

body {
    margin: 0;
    font-family: Roboto, "Helvetica Neue", sans-serif;
}

STICKY HEADER CODE :

app.component.html

<div class="app-wrapper">
    <router-outlet></router-outlet>
</div>

app.component.scss

.app-wrapper {
    min-height: 100%;
    overflow-x: hidden;
}

.my-toolbar {
    position: sticky;
    position: -webkit-sticky; /* For macOS/iOS Safari */
    top: 0; /* Sets the sticky toolbar to be on top */
}

app-main.component.html

<mat-toolbar color="primary" class="my-toolbar">
    <mat-toolbar-row>
        <div fxFlex fxLayoutAlign="flex-start">
            <mat-icon routerLink="/home">home</mat-icon>
        </div>
        <h1>My title</h1>
    </mat-toolbar-row>
</mat-toolbar>

<router-outlet></router-outlet>

app-main.scss

.app-toolbar {
    position: sticky;
    position: -webkit-sticky; /* For macOS/iOS Safari */
    top: 0; /* Sets the sticky toolbar to be on top */
}

STICKY MENU

app-content.html

<div fxLayout="column">
    <img fxFlex="10" src="assets/test.jpg"  alt="menu picture" />

    <div class="categories nav-menu color-primary">
        <app-horizontal-nav
            [navItems]="categories$ | async">
        </app-horizontal-nav>
    </div>

   <!-- content -->
   <app-products></app-products>
</div>

app-content.scss

.nav-menu {
    position: sticky;
    position: -webkit-sticky; /* For macOS/iOS Safari */
    top: 50px; // for the first sticky header
}

EDIT :

Here a stackblitz demo : https://stackblitz.com/edit/angular-9-0-0-rc-1-zhoy51 in style.scss, change height from auto to 100% and sticky headers will works. BUT none scroll event from scrolledToDirective are fired.

This Q related to your issue? https://stackoverflow.com/questions/487073/how-to-check-if-element-is-visible-after-scrolling. You should use some Utility Function (Dedect scroll into view / Window.innerHeight and so on is part of Javascript/Web APIs Core - Not specific to angular). Or for "very complex" trigger ideas you should use a third-party plugin like this one: WayPoints.js - http://imakewebthings.com/waypoints/ - package: https://www.npmjs.com/package/angular-waypoints — Ezra Siton, Apr 14 '20 at 08:24
You talk about a sidenav in your question. Where is it? Is it important at all? — julianobrasil, Apr 14 '20 at 08:48
1. I'm going to add a stackblitz demo 2. I think it's more a css problem or how the html page is built but not sure. 3. Actually, the sidenav is my sticky menu. — Joe Allen, Apr 14 '20 at 09:33
Demo link : https://stackblitz.com/edit/angular-9-0-0-rc-1-zhoy51 in style.scss, change height from auto to 100% and sticky headers will works. — Joe Allen, Apr 14 '20 at 10:33

yurzui · Accepted Answer · 2020-04-14T14:54:54.220

7

You have the following rule on your main wrapper:

.app-wrapper {
    height: 100%; // doesn't have any effect since parent's(app-root) height is 0
    overflow-x: hidden; <== remove this
}

Once you set 100% to the body you moved scroll to that wrapper.

You should remove overflow-x: hidden; and it should work. But there will be still a small issue with horizontal scroll which is caused by material mat-chip-list, so add overflow: hidden there:

.nav-menu {
    ...
    overflow: hidden;  <==== this one
}

Forked Stackblitz

edited Apr 14 '20 at 14:54

answered Apr 14 '20 at 12:34

yurzui

205,937
32
433
399

Thank you very much for your help but I have a last question, how the nav-menu could move to right or left depends on active item ? Thank you again :) – Joe Allen Apr 14 '20 at 12:44
Do you mean how to highlight active menu item while scrolling? – yurzui Apr 14 '20 at 12:57
I would like my sticky menu (with mat-chips) shift to right or left to still see the active category, for example, if one scrolls down the items list, I would like to see the according nav item be fully displayed – Joe Allen Apr 14 '20 at 13:23
You can use `transform: translateX` rule on `mat-chips-list` element to shift items https://monosnap.com/file/MKSEhmQe5IDohPSDoICMZxkj11Yq6j – yurzui Apr 14 '20 at 13:32
I'm not sure if it's the solution. When I have too many nav items, I can scroll to the right. But it's not automatic if the user scrolls down the content, the active item is not shown. If the user scrolls down, the nav-menu scroll automatically on active nav-item. Hope I was more understandable – Joe Allen Apr 14 '20 at 14:01
You need to make it automatic so that when user scrolls menu is scrolled to that active item – yurzui Apr 14 '20 at 14:03
yep exactly :) but when I tried transform solution, I have got the menu cutted 100px from right border (tested on mobile) – Joe Allen Apr 14 '20 at 14:11
It will be cut anyway. There is another way: use mat-tab-nav-bar like here https://stackblitz.com/edit/angular-zywvjy?file=src/app/app.component.ts – yurzui Apr 14 '20 at 14:20
Here's an example https://stackblitz.com/edit/angular-9-0-0-rc-1-s68vgh?file=src%2Fapp%2Fpages%2Fcontent%2Fcontent.component.scss and I will share preview in my answer – yurzui Apr 14 '20 at 14:49
It's a good solution for desktop but not exactly what I want for my mobile web app. Is it possible to remove chevrons ? Morever, how could it active automatically nav item when user scrolls down (if the user sees item 4, nav item 4 is active) ? Thank you very much for your help ! – Joe Allen Apr 14 '20 at 16:11
If you checked my demo https://stackblitz.com/edit/angular-9-0-0-rc-1-s68vgh?file=src%2Fapp%2Fpages%2Fcontent%2Fcontent.component.scss then you might notice that active item changes depending on scroll position. Yes, you can remove chevrons. Anyway, we moved far from the original question – yurzui Apr 14 '20 at 16:20

score 0 · Answer 2 · answered Apr 19 '20 at 23:42

0

Add simply this <body style="height: 100vh!important;" to your index.html.

answered Apr 19 '20 at 23:42

Nadhir Houari

390
4
10
